INTRODUCTION
EAU10113
Welcome to the Yamaha world of motorcycling!
As the owner of the XC125, you are benefi ting from Yamaha’s vast experience and newest technology regarding the de-
sign and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
Please take the time to read this manual thoroughly, so as to enjoy all advantages of your XC125. The Owner's Manual
does not only instruct you in how to operate, inspect and maintain your scooter, but also in how to safeguard yourself
and others from trouble and injury.
In addition, the many tips given in this manual will help keep your scooter in the best possible condition. If you have any
further questions, do not hesitate to contact your Yamaha dealer.
The Yamaha team wishes you many safe and pleasant rides. So, remember to put safety fi rst!
Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most
current product information available at the time of printing, there may be minor discrepancies between your scooter and
this manual. If there is any question concerning this manual, please consult a Yamaha dealer.
EWA12411
WARNING
Please read this manual carefully and completely before operating this scooter.
4P9-F8199-E5_CS.indd 34P9-F8199-E5_CS.indd 3
2011/09/06 14:18:392011/09/06 14:18:39
Process BlackProcess Black

IMPORTANT MANUAL INFORMATION
EAU10133
Particularly important information is distinguished in this manual by the following notations:QThis is the safety alert symbol. It is used to alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoid possible injury
or death.
WARNING
A WARNING indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
NOTICE
A NOTICE indicates special precautions that must be taken to avoid damage to the
vehicle or other property.
TIP
A TIP provides key information to make procedures easier or clearer.
*Product and specifi cations are subject to change without notice.
4P9-F8199-E5_CS.indd 44P9-F8199-E5_CS.indd 4
2011/09/06 14:18:392011/09/06 14:18:39
Process BlackProcess Black

IMPORTANT MANUAL INFORMATION
EAUT1390
XC125
OWNER’S MANUAL
©2011 by Yamaha Motor Taiwan Co., Ltd.
1st edition, October 2011
All rights reserved.
Any reprinting or unauthorized use
without the written permission of
Yamaha Motor Taiwan Co., Ltd.
is expressly prohibited.
Printed in Taiwan.
4P9-F8199-E5_CS.indd 54P9-F8199-E5_CS.indd 5
2011/09/06 14:18:392011/09/06 14:18:39
Process BlackProcess Black

TABLE OF CONTENTSSAFETY INFORMATION .................... 1-1
Further safe-riding points ................. 1-5
DESCRIPTION .................................... 2-1
Left view ........................................... 2-1
Right view ......................................... 2-2
Controls and instruments ................. 2-3
INSTRUMENT AND CONTROL FUNC-
TIONS .................................................. 3-1
Main switch/steering lock ................. 3-1
Keyhole cover .................................. 3-2
Indicator and warning lights ............. 3-2
Speedometer .................................... 3-3
Multi-function display ........................ 3-3
Handlebar switches .......................... 3-5
Front brake lever .............................. 3-6
Rear brake lever ............................... 3-6
Fuel tank cap .................................... 3-7
Fuel .................................................. 3-7
Catalytic converters .......................... 3-9
Kickstarter ........................................ 3-9
Seat ................................................ 3-10
Storage compartments ................... 3-10
Sidestand ....................................... 3-11
Ignition circuit cut-off system .......... 3-12
FOR YOUR SAFETY - PRE-OPERATION
CHECKS ............................................. 4-1OPERATION AND IMPORTANT RIDING
POINTS ............................................... 5-1
Starting the engine ........................... 5-1
Starting off ........................................ 5-2
Acceleration and deceleration .......... 5-2
Braking ............................................. 5-2
Tips for reducing fuel consumption .. 5-3
Engine break-in ................................ 5-3
Parking ............................................. 5-4
PERIODIC MAINTENANCE AND AD-
JUSTMENT ......................................... 6-1
Owner’s tool kit ................................. 6-2
Periodic maintenance chart for the
emission control system ............... 6-3
General maintenance and lubrication
chart .............................................. 6-4
Removing and installing panels ....... 6-7
Checking the spark plug ................... 6-8
Engine oil and oil strainer ............... 6-10
Final transmission oil ...................... 6-12
Air fi lter and V-belt case air fi lter
elements ..................................... 6-13
Checking the throttle grip free
play ............................................. 6-15
Valve clearance .............................. 6-15
Tires ............................................... 6-16
Cast wheels .................................... 6-17
Checking the brake lever free
play ............................................. 6-18Adjusting the rear brake lever free
play ............................................. 6-18
Checking the front brake pads and
rear brake shoes ......................... 6-19
Checking the brake fl uid level ........ 6-19
Changing the brake fl uid ................ 6-20
Checking and lubricating the
cables ......................................... 6-21
Checking and lubricating the throttle grip
and cable .................................... 6-21
Lubricating the front and rear brake
levers .......................................... 6-21
Checking and lubricating the
centerstand and sidestand .......... 6-22
Checking the front fork ................... 6-23
Checking the steering .................... 6-23
Checking the wheel bearings ......... 6-24
Battery ............................................ 6-24
Replacing the fuses ........................ 6-26
Replacing the headlight bulb .......... 6-27
Replacing a front turn signal light
bulb ............................................. 6-28
Replacing the tail/brake light bulb or a
rear turn signal light bulb ............ 6-28
Replacing an auxiliary light bulb ..... 6-29
Troubleshooting ............................. 6-29
Troubleshooting chart .................... 6-31
SCOOTER CARE AND STORAGE .... 7-1
Matte color caution ........................... 7-1
Care ................................................. 7-1
4P9-F8199-E5_CS.indd 64P9-F8199-E5_CS.indd 6
2011/09/06 14:18:392011/09/06 14:18:39
Process BlackProcess Black

TABLE OF CONTENTS
Storage ............................................. 7-4
SPECIFICATIONS .............................. 8-1
CONSUMER INFORMATION ............. 9-1
Identifi cation numbers ...................... 9-1
4P9-F8199-E5_CS.indd 74P9-F8199-E5_CS.indd 7
2011/09/06 14:18:392011/09/06 14:18:39
Process BlackProcess Black

1
2
3
4
5
6
7
8
9
1-1
Q
SAFETY INFORMATION
