PERIODIC MAINTENANCE AND ADJUSTMENT
tem, reducing braking perfor-
mance.
● Clean the filler cap before re-
moving. Use only DOT 4 brake
uid from a sealed container.● Use only the specified brake
fluid; otherwise, the rubber
seals may deteriorate, causing
leakage.● Refill with the same type of
brake uid. Adding a brake u-
id other than DOT 4 may result
in a harmful chemical reaction.● Be careful that water does not
enter the brake fluid reser-
voir when refilling. Water will
significantly lower the boiling
point of the fluid and may re-
sult in vapor lock.
ECA17640
NOTICEBrake fluid may damage painted
surfaces or plastic parts. Always
clean up spilled uid immediately.
As the brake pads wear, it is normal
for the brake fluid level to gradually go down. A low brake fl uid level may
indicate worn brake pads and/or brake
system leakage; therefore, be sure to
check the brake pads for wear and the
brake system for leakage. If the brake
fl uid level goes down suddenly, have
a Yamaha dealer check the cause be-
fore further riding.
EAU22721
Changing the brake uidHave a Yamaha dealer change the
brake fl uid at the intervals specifi ed in
the TIP after the periodic maintenance
and lubrication chart. In addition, have
the oil seals of the brake master cyl-
inder and caliper as well as the brake
hose replaced at the intervals listed
below or whenever they are damaged
or leaking.● Oil seals: Replace every two
years.● Brake hose: Replace every four
years.
