PERIODIC MAINTENANCE AND ADJUSTMENTRecommended final transmission
oil:
See page 8-1.
Oil quantity:
0.11 L (0.12 US qt, 0.10 Imp.qt)8. Install the final transmission oil
fi ller cap and its new O-ring, and
then tighten the oil fi ller cap.
9. Check the fi nal transmission case
for oil leakage. If oil is leaking,
check for the cause.
EAUT3120
Air filter and V-belt case air
lter elementsThe air filter and V-belt case air filter
elements should be cleaned at the in-
tervals specifi ed in the periodic main-
tenance and lubrication chart. Check
both filter elements more frequently
if you are riding in unusually wet or
dusty areas. The air fi lter check hoses
must be frequently checked and
cleaned if necessary.
Replacing the air lter element
1. Place the scooter on the center-
stand.2. Remove the air filter case cover
by removing the screws.
ZAUM00**
1
2(✕6)
1. Air fi lter case cover
2. Screw3. Pull the air fi lter element out.
4. Insert a new air fi lter element into
the air fi lter case.
NOTICE:
Make
sure that the air filter element
is properly seated in the air
filter case. The engine should
never be operated without
the air filter element installed,
otherwise the piston(s) and/or
cylinder(s) may become exces-
sively worn.
[ECA10481]
5. Install the air fi lter case cover by
installing the screws.
4P9-F8199-E5_CS.indd 6-134P9-F8199-E5_CS.indd 6-13
2011/09/06 14:18:402011/09/06 14:18:40
Process BlackProcess Black

1
2
3
4
5
6
7
8
9
6-14
EAU1722A
PERIODIC MAINTENANCE AND ADJUSTMENT
Cleaning the air lter check hoses
1. Check the hoses on the front and
rear side of the air filter case for
accumulated dirt or water.ZAUM00**
1
1
1. Air fi lter check hose2. If dirt or water is visible, remove
the hoses, clean them, and then
install them.Cleaning the V-belt case air filter
element
1. Remove the V-belt air filter case
cover by removing the screws.
ZAUM00**
1
1. V-belt air fi lter case cover2. Remove the fi lter element holder
by removing the screw.ZAUM00**
1
1. Air fi lter element holder
3. Pull the air fi lter element out, and
then clean it with solvent. After
cleaning, remove the remain-
ing solvent by squeezing the
element. WARNING! Use only a
dedicated parts cleaning sol-
vent. To avoid the risk of re or
explosion, do not use gasoline
or solvents with a low flash
point.
[EWA10431]
NOTICE:
To avoid
damaging the air lter element,
handle it gently and carefully,
and do not twist it.
[ECA10521]
ZAUM00**
1
1. V-belt case air fi lter element4. Apply oil of the recommended
type to the entire surface of
the sponge material, and then
squeeze the excess oil out.
4P9-F8199-E5_CS.indd 6-144P9-F8199-E5_CS.indd 6-14
2011/09/06 14:18:412011/09/06 14:18:41
Process BlackProcess Black

1
2
3
4
5
6
7
8
9
6-15
EAU1722A
PERIODIC MAINTENANCE AND ADJUSTMENTTIPThe air filter element should be wet
but not dripping.Recommended oil:
Yamaha foam air filter oil or other
quality foam air fi lter oil5. Insert the element into the air fi l-
ter case.
6. Install the fi lter element holder by
installing the screw.
7. Install the V-belt air filter case
cover by installing the screws.
EAU21401
Valve clearanceThe valve clearance changes with
use, resulting in improper air-fuel mix-
ture and/or engine noise. To prevent
this from occurring, the valve clear-
ance must be adjusted by a Yamaha
dealer at the intervals specifi ed in the
periodic maintenance and lubrication
chart.
EAU21384
Checking the throttle grip
free playThe throttle grip free play should mea-
sure 3 ~ 5 mm (0.12 ~ 0.20 in) at the
inner edge of the throttle grip. Periodi-
cally check the throttle grip free play
and, if necessary, have a Yamaha
dealer adjust it.ZAUM00**
1
1. Throttle cable free play
4P9-F8199-E5_CS.indd 6-154P9-F8199-E5_CS.indd 6-15
2011/09/06 14:18:412011/09/06 14:18:41
