2012 TOYOTA TUNDRA Owners Manual

665
6-1. Specifications
6
Vehicle specifications
TWR (Trailer Weight Rating)
Regular Cab models
*1: The model code is indicated on the Certification Label. (P. 668)
*2: Without towing package
*3: With towing package
*4: P275/55R20 tires
Model code*1EngineDriving
systemBed typeTWR
(Trailer weight + cargo)
GSK50L-TRADKA 4.0L V6
(1GR-FE) engine 2WD
Standard 4900 lb. (2220 kg)
GSK51L-THADKA Long 4800 lb. (2175 kg)
UPK50L-TRTDKA 4.6L V8
(1UR-FE) engine 2WD Standard
7100 lb. (3220 kg)
*2
8600 lb. (3900 kg)*3
USK51L-THTDKA
5.7L V8
(3UR-FE) engine 2WD Long
8400 lb. (3810 kg)*2
10400 lb. (4715 kg)*3
USK55L-TRTDKA
4WDStandard
8200 lb. (3715 kg)
*2
9700 lb. (4395 kg)*3
9200 lb. (4170 kg)*3,4
USK56L-THTDKA
Long 8100 lb. (3670 kg)*2
10100 lb. (4580 kg)*3
USK55L-TRTDGA
5.7L V8
(3UR-FBE) engine 4WDStandard 8200 lb. (3715 kg)
*2
9700 lb. (4395 kg)*3
9200 lb. (4170 kg)*3,4
USK56L-THTDGA
Long 8100 lb. (3670 kg)*2
10100 lb. (4580 kg)*3

666 6-1. Specifications
Double Cab models
*1: The model code is indicated on the Certification Label. (P. 668)
*2: Without towing package
*3: With towing package
Model code*1EngineDriving
systemBed typeTWR
(Trailer weight + cargo)
GSK51L-CRASKA 4.0L V6
(1GR-FE) engine 2WD Standard 4500 lb. (2040 kg)
UPK51L-CRTSKA 4.6L V8
(1UR-FE) engine 2WD
Standard 6700 lb. (3035 kg)
*2
8200 lb. (3715 kg)*3
UPK56L-CRTSKA
4WD 6400 lb. (2900 kg)*2
7900 lb. (3580 kg)*3
USK51L-CRTSKA
5.7L V8
(3UR-FE) engine 2WD
Standard 8100 lb. (3670 kg)*2
10100 lb. (4580 kg)*3
USK51L-CRTLKA
8100 lb. (3670 kg)*2
10000 lb. (4535 kg)*3
USK52L-CHTSKA
Long 10000 lb. (4535 kg)
USK56L-CRTSKA 4WDStandard 7800 lb. (3535 kg)
*2
9700 lb. (4395 kg)*3
USK56L-CRTLKA
7800 lb. (3535 kg)*2
9800 lb. (4445 kg)*3
USK57L-CHTSKA
Long 9800 lb. (4445 kg)
USK56L-CRTSGA 5.7L V8
(3UR-FBE) engine 4WD
Standard 7800 lb. (3535 kg)
*2
9700 lb. (4395 kg)*3
USK56L-CRTLGA
7800 lb. (3535 kg)*2
9800 lb. (4445 kg)*3
USK57L-CHTSGA
Long 9800 lb. (4445 kg)

667
6-1. Specifications
6
Vehicle specifications
CrewMax models
*1: The model code is indicated on the Certification Label. (P. 668)
*2: Without towing package
*3: With towing package
Model code*1EngineDriving
systemBed typeTWR
(Trailer weight + cargo)
UPK51L-PSTSKA 4.6L V8
(1UR-FE) engine 2WD
Short 6600 lb. (2990 kg)
*2
8100 lb. (3670 kg)*3
UPK56L-PSTSKA
4WD 6200 lb. (2810 kg)*2
7700 lb. (3490 kg)*3
USK51L-PSTSKA
5.7L V8
(3UR-FE) engine 2WD
8000 lb. (3625 kg)*2
9900 lb. (4490 kg)*3
USK51L-PSTLKA
7900 lb. (3580 kg)*2
9300 lb. (4215 kg)*3
USK56L-PSTSKA
4WD 7700 lb. (3490 kg)*2
9000 lb. (4080 kg)*3
USK56L-PSTLKA
7700 lb. (3490 kg)*2
9000 lb. (4080 kg)*3
USK56L-PSTSGA
5.7L V8
(3UR-FBE) engine 4WD 7700 lb. (3490 kg)*2
9000 lb. (4080 kg)*3
USK56L-PSTLGA
7700 lb. (3490 kg)*2
9000 lb. (4080 kg)*3

668 6-1. Specifications
Vehicle identification■ Vehicle identification number
The vehicle identificati on number (VIN) is the legal identifier for your
vehicle. This is the primary identification number for your Toyota. It is
used in registering the ownership of your vehicle.
This number is stamped on the
top left of the instrument panel.
This number is also on the Certi-
fication Label.

669
6-1. Specifications
6
Vehicle specifications
■
Engine number
The engine number is stamped on the engine bl ock as shown.
4.0L V6 (1GR-FE) engine
4.6L V8 (1UR-FE) engine
5.7L V8 (3UR-FE, 3UR-FBE) engine

670 6-1. Specifications
Engine4.0L V6 (1GR-FE) engine
4.6L V8 (1UR-FE) and 5.7L V8 (3UR-FE, 3UR-FBE) engines
Model 1GR-FE
Type 6-cylinder V-type, 4-cycle, gasoline
Bore and stroke 3.70  3.74 in. (94.0  95.0 mm)
Displacement 241.4 cu.in. (3956 cm3)
Drive belt tension Automatic adjustment
Valve clearance
(engine cold) Automatic adjustment
Model
1UR-FE, 3UR-FE, 3UR- FBE
Type 8-cylinder V-type, 4-cycle, gasoline
Bore and stroke 4.6L V8 (1UR-FE) engine
3.70 
3.27 in. (94.0  83.0 mm)
5.7L V8 (3UR-FE, 3UR-FBE) engine
3.70  4.02 in. (94.0  102.0 mm)
Displacement 4.6L V8 (1UR-FE) engine
281.2 cu.in. (4608 cm3)
5.7L V8 (3UR-FE, 3UR-FBE) engine
345.6 cu.in. (5663 cm
3)
Drive belt tension Automatic adjustment
Valve clearance
(engine cold) Automatic adjustment

671
6-1. Specifications
6
Vehicle specifications
Fuel
Lubrication system
*: The engine oil capacity is a reference quantity to be used when exchanging.
Warm up and turn off the engine, wait more than 5 minutes, and check the oil
level on the dipstick.
Engine Gasoline engine Flex-fuel engine
Fuel typeUnleaded gasoline onlyUnleaded gasoline, E85,
or a blend of the two fuels
Octane rating
(Unleaded gasoline) 87 (Research octane number 91) or higher
Ethanol percentage
(E85) 
85% or less
Fuel tank capacity
(Reference) 26.4 gal. (100.0 L, 22.0 lmp.gal.)
Oil capacity
(Drain and refill - reference
*)
With filter
Without filter 4.0L V6 (1GR-FE) engine
6.4 qt. (6.1 L, 5.4 Imp.qt.)
4.6L V8 (1UR-FE) and 5.7L V8
(3UR-FE, 3UR-FBE) engines
7.9 qt. (7.5 L, 6.6 Imp.qt.)
4.0L V6 (1GR-FE) engine
5.9 qt. (5.6 L, 4.9 Imp.qt.)
4.6L V8 (1UR-FE) and 5.7L V8
(3UR-FE, 3UR-FBE) engines
7.4 qt. (7.1 L, 6.2 Imp.qt.)

672 6-1. Specifications
■Engine oil selection
“Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy
the following grade and viscosity.
Oil grade: ILSAC multigrade engine oil
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice for
good fuel economy and good
starting in cold weather.
If SAE 0W-20 is not available,
SAE 5W-20 oil may be used.
However, it must be replaced
with SAE 0W-20 at the next oil
change.
Oil viscosity (0W-20 is explained here as an example):
●The 0W in 0W-20 indicates the characteristic of the oil which allows cold
startability. Oils with a lower value before the W allow for easier starting of
the engine in cold weather.
● The 20 in 0W-20 indicates the viscosity characteristic of the oil when the
oil is at high temperature. An oil with a higher viscosity (one with a higher
value) may be better suited if the vehicle is operated at high speeds, or
under extreme load conditions.
Outside temperature
