2012 Lexus HS250h Navigation Manual

SETUP
376
U10218LC
3. When this screen is displayed, enter
the passcode displayed on the screen
into the portable player.
For the operation of the portable player,
see the manual that comes with it.
If you want to cancel the entry, select “Can-
cel”.
U10219LC
4. When the connection is complete,
this screen is displayed.
You do not need to enter the portable play-
er in case of using the same one.
U10220LC
When this screen is displayed, follow the
guidance on the screen to try connection
again.When another Bluetooth
rdevice is
connected
If you want to disconnect it, select “Yes”.
INFORMATION
If the device corresponds with both
Bluetooth rphone and Bluetooth rau-
dio, register and connect the
Bluetooth rphone first or a connec-
tion failure may occur when register-
ing the Bluetooth raudio.
11 08.03HS250h_NAVI_U
75051U

SETUP
377
(a) Removing a Bluetoothraudio
U10221LC
1. Select “Remove” of “Bluetooth∗
Audio” on “BT Audio Settings” screen.
U10222LC
2. Select the portable player you want
to delete and select “OK”.
U10223LC
3. Select “Yes” to unregister the se-
lected portable player.
∗: Bluetooth is a registered trademark of
Bluetooth SIG.Inc.
U10224LC
If the selected portable player is in use, this
screen will appear. Select “Yes”. The sys-
tem will disconnect the portable player and
remove it.
11 08.03HS250h_NAVI_U
75051U
12

SETUP
378
(b) Connecting Bluetoothraudio
AUTOMATICALLY
U10225LC
Select “On” for “Auto Bluetooth∗connect”
to activate the automatic connection for
the Bluetooth r. Always set it to this mode
and leave the Bluetooth rportable player in
a condition where connection can be
established. The “Auto Bluetooth
∗
Connect” cannot be selected if the
connection method is set to “From
Portable Player”.
∗: Bluetooth is a registered trademark of Bluetooth SIG.Inc.
U10226LC
When the “POWER” switch is in ACCES-
SORY or ON mode, the selected portable
player will be automatically connected and
the connection result is displayed.
MANUALLY
When the auto connection failed or turned
off, you have to connect Bluetooth rmanu-
ally.
For the manual operation, see page 250.
11 08.03HS250h_NAVI_U
75051U

SETUP
379
(c) Changing the passcode
The passcode for registering your por-
table player on the system. You can
change this to 4 to 8 digit number of
your choice. The default is “0000”.
U10227LC
1. Select “Edit” of “Passcode” on “BT
Audio Settings” screen.
U10228LC
2. Enter the new 4−8 digits passcode
and select “OK”.
Each time you select
, an input digit
is deleted. (d) Changing the device name
You can change a device name. Even if
you change a device name, the name
registered your portable player is not
changed.
U10229LC
1. Select “Edit” of “Device Name” on
“BT Audio Settings” screen.
U10230LC
2. Enter the new device name and se-
lect “OK”.
INFORMATION
The device names are common
Bluetooth
raudio and Bluetooth r
phone.
If you change the device name of the
audio, the device name of the phone
will change at same time.
However, passcodes can be set sepa-
rately.
11 08.03HS250h_NAVI_U
75051U
12

SETUP
380
(e) Initializing the Bluetoothraudio
settings
You can initialize the settings.
U10231LC
1. Select “Default” on “BT Audio Set-
tings” screen.
U10232LC
2. Select “Yes”. When the navigation system is turned on,
the “Information” screen displays when it is
time to replace a part or certain compo-
nents. (See page 31.)
U0002AASLY
1. Push the “MENU” button on the Re-
mote Touch.
2. Select “Setup”.
3. Select “Vehicle”.
11 08.03HS250h_NAVI_U
75051U
Vehicle settings —
— Maintenance

SETUP
381
U10289LC
4. Select “Maintenance”.
U10235LC
DSetting maintenance information (See
page 381.)
DSetting dealer (See page 383.)(a) Maintenance information setting
1. Push the “MENU” button on the Re-
mote Touch, then select “Setup”.
2. Select “Vehicle” on the “Setup”
screen.
3. Select “Maintenance” on the “Ve-
hicle Settings” screen.
U10236LC
4. Select the desired button.
For details of each button, see “INFORMA-
TION ITEMS” on page 382.
“Delete All”:
To cancel all conditions
which have been inputted.
“Reset All”: To reset the item which has
satisfied a condition.
“Set Dealer”: To register dealer informa-
tion. (See “ (b) Dealer setting” on page
383.)
“Dealer Info.”: To edit dealer information.
(See “ (b) Dealer setting” on page 383.)
“Reminder”: When this button is se-
lected, the indicator is illuminated. The
system is set to give maintenance informa-
tion with the “Information” screen. (See
page 31.)
When the vehicle needs to be serviced, the
button color will change to orange.
11 08.03HS250h_NAVI_U
75051U
12

SETUP
382
INFORMATION ITEMS
“Engine oil”:Replace engine oil
“Oil filter”: Replace engine oil filter
“Rotation”: Rotate tires
“Tires”: Replace tires
“Battery”: Replace 12 −volt battery
“Brake pad”: Replace brake linings
“Wipers”: Replace wiper blades
“Coolant”: Replace engine coolant
“Brake oil”: Replace brake fluid
“Trans. fluid”: Replace transmission fluid
“Service”: Scheduled maintenance
“Air filter”: Replace air filter
“Personal”: New information items can
be created separately from provided ones.
U10237LC
5. Input the conditions.
“Date”: The next maintenance date can be
input.
“Distance”: The driving distance until the
next maintenance check can be input.
“Delete”: To cancel the date and distance
conditions.
“Reset”: To reset the date and distance
conditions .
6. Select “OK”.
The screen then returns to the “Mainte-
nance” screen.
INFORMATION
D For scheduled maintenance infor-
mation, please refer to the “War-
ranty and Services Guide/Owner’s
Manual Supplement/Scheduled
Maintenance”.
D Depending on driving or road con-
ditions, the actual date and dis-
tance may differ from the stored
date and distance in the system.
11 08.03HS250h_NAVI_U
75051U

SETUP
383
(b) Dealer setting
It is possible to register a dealer in the sys-
tem. With dealer information registered,
route guidance to the dealer is available.
1. Push the “MENU” button on the Re-
mote Touch, then select “Setup”.
2. Select “Vehicle” on the “Setup”
screen.
3. Select “Maintenance” on the “Ve-
hicle Settings” screen.
U10272LC
4. Select “Set Dealer”.
U10238LC
5. If the dealer has not been registered,
enter the location of the dealer in the
same way as for a destination search.
(See “Destination search” on page 68.)
When “Set Dealer” registration is finished,
the “Dealer” screen will be displayed.
U10239LC
6. Select “Edit” for the item you want
to change.
“Dealer”: To enter the name of a dealer.
(See page 384.)
“Contact”: To enter the name of a dealer
member. (See page 384.)
“Location”: To set a location. (See page
384.)
“Phone #”: To set a telephone number.
(See page 385.)
“Delete Dealer”:To delete the dealer in-
formation displayed on the screen.
“Enter
”: To set the displayed dealer as
a destination. (See “Starting route guid-
ance” on page 89.)
11 08.03HS250h_NAVI_U
75051U
12
