2012 HONDA CROSSTOUR Owners Manual

CONT INUED
If you have a f lat tire while driving,
stop in a saf e place to change it.
Drive slowly along the shoulder until
you get to an exit or an area to stop
that is far away from the traffic lanes.Take the jack, tools and the bag
out of the tool kit case.
Park the vehicle on firm, level, and
non-slippery ground. Put the
transmission in Park. Apply the
parking brake. If you are towing a
trailer, unhitch it.
Turn on the hazard warning lights,
and turn the ignition switch to the
LOCK (0) position. Have all
passengers get out of the vehicle
while you change the tire. Open the tailgate. Pull up the
handle on the removable tray.
Then remove the hook, and hook
it to the hole on the cargo side
panel (see page ).
Thetoolsandjackareunderthe
cargo area behind the utility box.
Remove the utility box by lif ting it
up with the handle (see page ).
5. 4. 3.
2. 1. 120
121
Changing a Flat Tire
373
HOOK
JACK
SPARE TIRE
TOOLS REMOVABLE TRAY
The vehicle can easily roll off
the jack, seriously injuring
anyone underneath.
Follow the directions for
changing a tire exactly, and
never get under the vehicle
when it is supported only by the
jack.

T aking Care of t he Unexpect ed

2012 Crosstour

µ
Attach the short end of the wheel
nut wrench to the spare tire holder
shaft. Turn the wrench
counterclockwise until the shaf t
loosens. Then attach the longer
section of the wrench to the shaf t,
andturnituntilyoucanseethe
sparetire(about65 70rotations).
Do not turn the wrench any
f urther once you f eel resistance.
The spare tire is stored
underneath the cargo area.
Remove the plastic cover on the
cargo area lining to access the
shaf t f or the spare tire holder.
Lift up the spare tire holder, then
slide the hook and lif t down the
sparetireholder.
Remove the spare tire from the
sparetireholder.
6.
7.8.
9.
Changing a Flat Tire
374
WHEEL NUT WRENCH SPARE TIRE
PLASTIC COVER SPARE TIRE HOLDER HOOK
The wheel nut wrench supplied with
your vehicle is specially adapted to f it
the holder shaf t. Do not use any other
tool.

T aking Care of t he Unexpect ed

2012 Crosstour

CONT INUED
Placethejackunderthejacking
point nearest the tire you need to
change. Turn the end bracket
clockwise until the top of the jack
contacts the jacking point. Make
sure the jacking point tab is
restinginthejacknotch.
Loosen each wheel nut 1/2 turn
with the wheel nut wrench.
To reinstall the spare tire holder,
slide the hook, lift up the spare
tire holder and attach it to the
hook. Attach the longer section of
the wrench to the spare tire
holder shaft. Turn the wrench
clockwise. Then attach the short
end of the wrench to the shaft,
and tighten it securely.
Reinstall the plastic cover.
11. 10.
12.13.
Changing a Flat Tire
375
WHEEL NUT
JACKING POINTS

T aking Care of t he Unexpect ed

2012 Crosstour

Before mounting the spare tire,
wipe any dirt off the mounting
surface of the wheel and hub
with a clean cloth. Wipe the hub
carefully; it may be hot from
driving.
Use the extension and the wheel
nut wrench as shown to raise
the vehicle until the flat tire
is off the ground.
Remove the wheel nuts, then
remove the f lat tire. Handle the
wheel nuts caref ully; they may be
hot from driving. Place the flat tire
on the ground with the outside
surface facing up. Lower the vehicle to the ground,
and remove the jack. Put on the spare tire. Put the
wheel nuts back on f inger-tight,
then tighten them in a crisscross
pattern with the wheel nut wrench
until the wheel is f irmly against
the hub. Do not try to tighten the
wheel nuts f ully.
14.
15. 16.17.
18.
Changing a Flat Tire
376
BRAKE HUB
WHEEL WRENCH EXTENSION

T aking Care of t he Unexpect ed

2012 Crosstour

CONT INUED
Store the jack and tools in the tool
kit case.
Replace the utility box. Remove
the hook and close the removable
tray.
Put the flat tire into the plastic bag,
whichisstoredinthetoolkitcase.
Knot the top of the plastic bag.
Tighten the wheel nuts securely in
the same crisscross pattern. Have
the wheel nut torque checked at
the nearest automotive service
f acility.
Tighten the wheel nuts to:
19.
20.21.
22.
Changing a Flat Tire
377
PLASTIC BAG
TOOL KIT CASE
HOOK
REMOVABLE TRAY
80 lbf·ft (108 N·m , 11 kgf·m)

T aking Care of t he Unexpect ed

2012 Crosstour

Place the flat tire in the cargo area,
and thread the belt through the
cargo hook as shown in the
illustration. Pass the belt through
the ring, and tighten the belt to
secure the f lat tire in place.
Bore through the bag, and pass
the holding belt through the hole
of the bag and the wheel of the flat
tire as shown in the illustration.
This belt is with the bag in the tool
kit case.
23.
24.
Changing a Flat Tire
378
BELTCARGO HOOK
Loose items can fly around the
interior in a crash and could
seriously injure the occupants.
Store the wheel, jack, and tools
securely before driving.

T aking Care of t he Unexpect ed

2012 Crosstour

Your vehicle’s original tire has a
tire pressure monitoring system
sensor. To replace a tire, ref er to(see
page ).
When putting back the spare tire,
placethesparetirefacingupon
the spare tire holder.
25. 26.
315
Changing a Flat Tire
Changing a T ire with T PMS
379
SPARETIREHOLDER
SPARE TIRE
If you store the spare tire f ace down, it
will be damaged and need to be
replaced.
Always ensure that the spare tire holder
is installed onto the hook and the
holder is then completely raised into
place. If the holder is lef t down, it will
be damaged during driving and will
need to be replaced.

T aking Care of t he Unexpect ed

2012 Crosstour

Diagnosing why the engine won’t
start f alls into two areas, depending
on what you hear when you turn the
ignition switch to the START (III)
position:You hear nothing, or almost
nothing. The engine’s starter
motor does not operate at all, or
operates very slowly.
You can hear the starter motor
operating normally, or the starter
motor sounds like it is spinning
f aster than normal, but the engine
does not start up and run. When you turn the ignition switch to
the START (III) position, you do not
hear the normal noise of the engine
trying to start. You may hear a
clicking sound, a series of clicks, or
nothing at all.
Check these things:
Turn the ignition switch to the
START (III) position. If the
headlights do not dim, check the
condition of the f uses. If the f uses
areOK,thereisprobably
something wrong with the
electrical circuit f or the ignition
switch or starter motor. You will
need a qualif ied mechanic to
determine the problem (see
on page ).
If the headlights dim noticeably or
go out when you try to start the
engine, either the battery is dis-
charged or the connections are
corroded. Check the condition of
the battery connections (see page ). You can then try jump
starting the vehicle from a booster
battery (see page ).
Check the transmission
interlock. The transmission must
be in Park or neutral or the
starter will not operate.
Turn the ignition switch to the ON
(II) position. Turn on the
headlights, and check their
brightness. If the headlights are
very dim or do not come on at all,
the battery is discharged. See
on page .382 397
367 382
If theEngineWon’tStart
Nothing Happens or the Starter
Motor Operates Very Slowly
Emergency T owing
Jump Starting
380

T aking Care of t he Unexpect ed

2012 Crosstour
