2011 VOLVO S60 Owner´s Manual

05 Infotainment
Bluetooth® hands-free connection
05

225 More information about pairing and
connecting cell phones
A maximum of 10 cell phones can be paired
with the hands-free system. Pairing only needs
to be done once for each phone. After pairing,
the cell phone no longer needs to be in sight or
discoverable. Only one cell phone can be con-
nected to hands-free at a time.
Automatic connectionWhen the hands-free system is active and the
most recently connected cell phone is within
range, it is connected automatically. If this
phone is not within range, the hands-free sys-
tem will attempt to connect one of the other
paired cell phones. When the infotainment sys-
tem searches for the most recently connected
phone, this phone’s name appears in the dis-
play.
Manual connectionTo connect a phone other than the one that
was most recently connected or to switch
between cell phones that are already paired
with the hands-free system, go to Phone main
menu
Change phone.
Removing a paired phone from the listIn phone mode, a paired phone can be
removed from the list of phones in Phone main
menu
Remove Bluetooth device.
BluetoothŸŸ versionFor information about the version of
BluetoothŸ installed in the vehicle, go to Phone
main menu
Phone settingsBluetooth
software version in car.
Phone book
The hands-free system uses two phones
books (one with the cell phone's list of contacts
and one with contacts saved directly in the
infotainment system), which are combined to
form one phone book.
•The infotainment system downloads the
phone book from a connected cell phone.
This phone book will only be displayed
when this cell phone is connected to the
hands-free system.
•The infotainment system also has an inte-
grated phone book made up of contacts
that have been saved in the system,
regardless of which cell phone is currently
connected when the contact is saved.
These contacts will be displayed regard-
less of the cell phone that is connected. If
a contact has been saved in the infotain-
ment system, the
symbol will be dis-
played next to it.
NOTE
Changes made from the infotainment sys-
tem to a contact in the cell phone's phone
book will result in a new contact being
added to the infotainment system's phone
book. However, this contact will not be
saved in the cell phone's phone book. The
infotainment system's display will show
duplicate contacts with different icons.
Please also note that if a speed dial number
is saved or if a contact's information is edi-
ted, this will result in a new contact in the
infotainment system's phone book.
The symbol must be displayed before
the phone book can be used and the hands-
free function must be in phone mode.
The infotainment system saves a copy of each
paired cell phone's phone book. This phone
book can be copied each time the phone is
connected.

Activate/deactivate this function in phone
mode in Phone main menu
Phone
settings
Download phone book.
If the phone book contains information about
someone who is trying to call you, this infor-
mation will be shown in the display.

05 Infotainment
Bluetooth® hands-free connection
05
226
Contact shortcutsA quick way of searching the phone book for
contacts in normal view is to turn TUNE clock-
wise to access the phone book and then coun-
ter-clockwise to select a contact from the list.
Press OK/MENU to call.
Each name in the phone book has a default
phone number. If the
symbol is displayed to
the right of it, this indicates that there are addi-
tional phone numbers for this contact. To use
a phone number other than the default one,
press the
button on the center console
control panel. Turn TUNE to select a different
phone number and press OK/MENU to call.
It is also possible to search for a contact by
using the center console keypad to enter the
first letter(s) of the contact's name (see also the
following table "Buttons in the center console"
for each button's function).
The list of contacts can also be accessed from
normal view by pressing and holding the button
on the center console keypad with the first let-
ter of the contact's name. For example, press-
ing and holding button 6 would provide direct
access to the section of the list with contacts
whose names begin with
M.
Buttons in the center console
ButtonFunction
Space . , - ? @ : ; / ( ) 1
A B C Å Ä Æ À Ç 2
D E F È É 3
G H I Ì 4
J K L 5
M N O Ö Ø Ñ Ò 6
P Q R S ß 7
T U V Ü Ù 8
W X Y Z 9
Shift between upper and lower
case
+ 0 p w
# *
Searching for contacts
Searching for contacts using the text wheel
List of characters
Switch between character entry modes
(see the following table)
Phone book (list of contacts)
To search for or edit a contact in phone mode,
go to Phone main menu
Phone book
Search.
1.
Turn TUNE to the desired letter and press
OK/MENU to confirm. The number/letter
keys on the center console can also be
used.
2. Continue to the next letter, etc. The results
of the search will be displayed in the phone
book (3).

05 Infotainment
Bluetooth® hands-free connection
05

227
3. To switch from letter entry mode to the
entry mode for numbers or special charac-
ters, or to go to the phone book, turn
TUNE to one of the selections (see the
explanation in the following table) in the list
for switching character entry mode (2) and
press OK/MENU.
Character entry modes
123/
ABCToggle between letters and num-
bers by pressing OK/MENU.
MoreSwitch to special characters by
pressing OK/MENU.
This leads to the phone book (3).
Turn TUNE to select a contact
and press OK/MENU to display
the contact's information.
Press EXIT briefly to erase a single character.
Press and hold EXIT to erase all of the char-
acters that have been entered.
If a number button on the center console is
pressed while the text wheel is displayed, a list
of characters (1) will be displayed. Briefly press
the button once to enter its first letter, twice to
enter the second letter, etc. Continue to press
the button to display other characters. Con-
tinue with the next character, etc.
To enter a number, press and hold the button.
Adding a new contact
Enter the name of a new contact
Switch between character entry modes
(see the following table)
Character entry field
New contacts can be added in phone mode in
Phone main menu
Phone bookNew
contact.
1.
When
Name is highlighted, press OK/
MENU to go to the character entry mode
(see the illustration).
2.
Turn TUNE to the desired letter and press
OK/MENU to confirm. The number/letter
keys on the center console can also be
used.3. Continue to the next letter, etc. The name
entered will be displayed in the character
entry field (2).
4. To switch from letter entry mode to the
entry mode for numbers or special charac-
ters, or to toggle between upper and lower
case letters, etc., turn TUNE to one of the
selections (see the explanation in the fol-
lowing table) in the list (1) and press OK/
MENU.
When you have finished entering the name,
select
OK in the list in the display (1) and press
OK/MENU. Continue by entering the phone
number in the same way.
When you have entered the phone number,
press OK/MENU and select a tag for the num-
ber (
Mobile phone, Home, Work orGeneral). Press OK/MENU to confirm.
When all of the contact's information has been
entered, press EXIT to save.
123/
ABCToggle between letters and num-
bers by pressing OK/MENU.
MoreSwitch to special characters by
pressing OK/MENU.
OKSave and return to Add contactby pressing OK/MENU.

05 Infotainment
Bluetooth® hands-free connection
05
228
Toggle between upper and lower
case letters by pressing OK/
MENU.
Press OK/MENU and the cursor
will move to the character entry
field (2) at the top of the display.
The cursor can now be moved by
turning TUNE to a position where
new characters can be entered
or deleted by pressing EXIT. In
order to add characters, return to
text entry mode by pressing OK/
MENU.
Speed dialSpeed dial numbers can be added in phone
mode in Phone main menu
Phone book
Speed dial.
To use speed dial to make a call in phone
mode, press a button on the center console
keypad followed by OK/MENU. If a contact
has not been saved on the speed dial number
used, you will be prompted to save a contact
on the number selected.
Accept vCardsvCards from other cell phones can be added to
the infotainment system's phone book. To ena-
ble this feature, put the infotainment system in
discoverable mode for Bluetooth
Ÿ. The featureis activated in Phone main menu
Phone
book
Receive vCard.
Memory statusIn phone mode, the memory status of the info-
tainment system's phone book and the con-
nected cell phone's phone book can be seen
in Phone main menu
Phone book
Memory status.
Clearing the phone bookIn phone mode, all entries in the infotainment
system's phone book can be cleared in Phone
main menu
Phone bookClear phone
book.
NOTE
Clearing the entries in the infotainment sys-
tem's phone book does not delete entries in
the cell phone's phone book.

05 Infotainment
Cell phone voice control
05

229 Introduction
The infotainment system's voice control fea-
ture1 enables you to voice-activate certain
functions in a BluetoothŸ-connected cell
phone or the navigation system.
NOTE
•The information in this section applies
to using voice commands to operate a
Bluetooth
Ÿ-connected cell phone.
See also the section "BluetoothŸ
hands-free connection" beginning on
page 221 for detailed information about
using a cell phone with the vehicle's
infotainment system.
•The navigation system has a separate
user's guide containing information
about voice commands for operating
that system.
Voice commands offer convenience and help
avoid distractions so that you can concentrate
on driving and focus your attention on road and
traffic conditions.
WARNING
As the driver, you have full responsibility for
operating the vehicle safely and adhering to
all applicable traffic regulations.
The voice control feature provides access to a
number of functions in the BluetoothŸ hands-
free and navigation systems while allowing you
to keep your hands on the steering wheel. Input
is in dialogue form using spoken commands
from the user and verbal prompts from the sys-
tem. Voice control uses the same microphone
as the Bluetooth
Ÿ hands-free system (see the
illustration on page 221) and system prompts
are provided through the infotainment sys-
tem's front speakers.
Since the microphone is positioned directly in
front of the driver, voice commands given by
other occupants of the vehicle may not be
understood.
Getting started
Voice control button on the steering wheel
Activating the systemBefore any phone voice commands can be
used, a BluetoothŸ-enabled cell phone must
be paired with the infotainment system. If a
phone command is given, the system will
inform you If there are no cell phones paired.
See page 222 for information on pairing a cell
phone.
Press the voice control button (1 in the illustra-
tion) to activate the system and initiate a com-
mand dialogue. The system will display com-
monly used commands on the screen when the
button has been pressed.
1Available in vehicles equipped with the optional Volvo Navigation System only

05 Infotainment
Cell phone voice control
05
230
While using the voice control system, keep the
following points in mind:
•When giving commands, speak at your
usual speed and in a normal tone of voice
after the tone
•The vehicle's doors, windows and moon-
roof should be closed when using the voice
control system
•Avoid background noises in the cabin
when using the system
NOTE
If you are uncertain of the commands that
you can use, saying "help" will prompt the
system to provide a number of commands
that can be used in a specific situation.
Voice control commands can be cancelled
by:
•Saying "cancel"
•Not speaking
•Pressing and holding the voice control
button
Voice control support features
•Tutorial: A feature that helps acquaint you
with the system and the procedure for giv-
ing commands.
•Training: A feature that enables the voice
control system to become familiar withyour voice and pronunciation, and allows
you to set up user profiles. Two user pro-
files can be created.
These support features are accessed by press-
ing the MY CAR button in the center console
and turning TUNE to scroll to the desired menu
selection.
TutorialThe tutorial feature can be started in two ways:
NOTE
The tutorial feature can only be started when
the vehicle is parked and the parking brake
is applied.
•By pressing the voice control button and
saying "Voice tutorial."
•By pressing MY CAR and going to
Settings
Voice settingsVoice
tutorial. Press OK/MENU to begin the
tutorial lesson.
The tutorial is divided into three lessons, which
take a total of approximately 5 minutes to com-
plete.
By default, the system will begin with the first
lesson. To skip to the next lesson, press the
voice control button and say "next." Go back
to a previous lesson by saying "previous."Press and hold the voice control button to exit
the tutorial.
TrainingThe system will display up to fifteen phrases for
you to say. To start the voice training proce-
dure, press MY CAR and go to Settings
Voice settingsVoice training. Select User
1
or User 2 and press OK/MENU to begin.
After the training has been completed, remem-
ber to set your user profile in
Voice user
setting.
Other voice control settings found in MY
CAR
•Voice user setting: Two user profiles can
be set by pressing MY CAR and going to
Settings
Voice settingsVoice user
setting. Select
User 1 or User 2.
•Voice output volume: Press MY CAR and
go to Settings
Voice settingsVoice
output volume. Press OK/MENU and turn
TUNE to raise or lower the volume. Press
EXIT to save the change and exit the menu.

05 Infotainment
Cell phone voice control
05

231 Using voice commands
The driver initiates a voice command dialogue
by pressing the voice control button (see the
illustration on page 229).
When a dialogue has been initiated, commonly
used commands will be shown in the display.
Grayed-out texts or texts in parentheses are
not part of the spoken command.
Once you become familiar with the system, you
can speed up the command dialogue by briefly
pressing the voice control button to skip
prompts from the system.
Commands can be given in several ways.
For example, the command "Phone call con-
tact" can be spoken as:
•"Phone > Call contact"—say "Phone," wait
for a system response, and then continue
by saying "Call contact."
•"Phone call contact"—give the entire com-
mand at one time
The following is a list of features that can be
voice-controlled with a Bluetooth
Ÿ-connected
cell phone.
Dialing a numberThe system understands the digits zero to nine.
These numbers can be spoken individually, in
groups of several digits at a time, or the entirenumber can be given at once. Numbers above
nine will not be recognized.
The following is an example of a voice com-
mand dialogue. The system's response may
vary depending on the situation.
The user initiates the dialogue by saying:Phone > dial number
or
Phone dial number
System responseNumber please
User actionBegin saying the digits in the phone number. If
you say several digits and pause, the system
will repeat them and prompt you by saying
"Continue."
Continue saying the digits. When you have fin-
ished, complete the command by saying
"Dial."
•You can also change the number by using
the commands "Correction" (which dele-
tes the last group of digits spoken) or
"Delete" (which will erase the entire phone
number).
Dialing from a call listThis feature lets you make a call from one of
your cell phone's call lists.
The user initiates the dialogue by saying:Phone > dial from call list
or
Phone dial from call list
Continue by responding to the system's
prompts.
Calling a contactThis feature enables you to call pre-defined
contacts. Contacts must be created in your cell
phone. See the phone's user's guide if neces-
sary.
The user initiates the dialogue by saying:Phone > call contact
or
Phone call contact
Continue by responding to the system's
prompts.
When calling contacts, keep the following in
mind:
•If there are several contacts with similar
names, they will be presented in the dis-
play in numbered lines and the system will
prompt you to pick a line number
•If there are more lines in the list than can
be displayed at one time, saying "Down"
will enable you to scroll downward in the

05 Infotainment
Cell phone voice control
05
232
list (and saying "up" will take you back up
through the list).
Dialing voicemailThis feature enables you to call your voicemail
to check any messages that you may have
received. Your voicemail phone number must
be registered in the Bluetooth
Ÿ function, see
page 224.
The user initiates the dialogue by saying:Phone > dial voicemail
or
Phone dial voicemail
Continue by responding to the system's
prompts.
