2011 RENAULT SCENIC Engine And Peripherals Workshop Manual

13B-169
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
V4 MR-372-J84-13B000$140.mif
DIESEL INJECTION
Fault finding – Fault finding charts13B
InjectionDDCR
Vdiag No.: 44, 48
ALP2
CONTINUED 2
Check the high pressure system by running TEST 6 High pressure system check.
Check that the computer connectors are properly locked.
Check the condition of the computer connections (bent pin, signs of corrosion, silicone, etc.).
If the connector(s) are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Contact the Techline if the customer complaint is still present.
A

13B-170
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
V4 MR-372-J84-13B000$140.mif
DIESEL INJECTION
Fault finding – Fault finding charts13B
InjectionDDCR
Vdiag No.: 44, 48
ALP3 The engine starts with difficulty, or starts then stalls
NOTESOnly consult this customer complaint after a complete check with the diagnostic tool.
Check that the fuel tank is correctly filled and that the fuel is correct by running TEST 13 Diesel fuel conformity
check.
Check the levels of engine oil and coolant.
Check the air inlet circuit: run test 5 Air inlet circuit check.
Is the catalytic converter clogged or damaged?Replace the catalytic converter (see MR 364
(Mégane II) or MR 370 (Scénic II),
Mechanical, 19B, Exhaust, Catalytic
converter: Removal - Refitting).
Check the electrical conformity of the heater plugs (the resistance value of the heater plug must be less than 2 Ω).
Is the timing set correctly? Carry out the necessary repairs.
Is the compression in order? Carry out the necessary repairs.
YES
NO
NO
YES
NO
YES
A
DDCR_V44_ALP03/DDCR_V48_ALP03

13B-171
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
V4 MR-372-J84-13B000$140.mif
DIESEL INJECTION
Fault finding – Fault finding charts13B
InjectionDDCR
Vdiag No.: 44, 48
ALP3
CONTINUED
Visually check the condition of the engine wiring harness.
Check the air inlet circuit by running TEST 2 Electrical circuit check.
Using the diagnostic tool, check that the injector codes (C2I) are correctly entered on the identification screen. If
not, configure the correct injector codes using command SC002 Enter injector codes.
Check the low pressure circuit by running TEST 1 Low pressure circuit check.
Visually check that there are no leaks on the high pressure circuit by running TEST 7 High pressure circuit
sealing check.
Check the high pressure system by running TEST 6 High pressure system check.
Check that the computer connectors are properly locked.
Check the condition of the computer connections (bent pin, signs of corrosion, silicone, etc.).
If the connector(s) are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Contact the Techline if the customer complaint is still present.
A
YES

13B-172
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
V4 MR-372-J84-13B000$140.mif
DIESEL INJECTION
Fault finding – Fault finding charts13B
InjectionDDCR
Vdiag No.: 44, 48
ALP4 Starting difficult with warm engine
NOTESOnly consult this customer complaint after a complete check with the diagnostic tool.
Check that the fuel tank is correctly filled and that the fuel is correct by running TEST 13 Diesel fuel conformity
check.
Check the air inlet circuit by running TEST 5 Inlet circuit check.
Is the compression in order? Carry out the necessary repairs.
Is the timing set correctly? Carry out the necessary repairs.
Using the diagnostic tool, check that the injector codes (C2I) are correctly entered on the identification screen. If
not, configure the correct injector codes using command SC002 Enter injector codes.
Visually check the condition of the engine wiring harness.
Check the low pressure circuit by running TEST 1 Low pressure circuit check.
NO
YES
NO
YES
A
DDCR_V44_ALP04/DDCR_V48_ALP04

13B-173
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
V4 MR-372-J84-13B000$140.mif
DIESEL INJECTION
Fault finding – Fault finding charts13B
InjectionDDCR
Vdiag No.: 44, 48
ALP4
CONTINUED
Control the injectors using the commands:
– AC005 Cylinder 1 injector,
– AC006 Cylinder 2 injector,
– AC007 Cylinder 3 injector,
– AC008 Cylinder 4 injector.
Can you hear the valve moving when you are
1 metre from the vehicle?Run Test 9 Diesel filter check.
If test 9 is correct, replace only the faulty
injectors (see MR 364 (Mégane II) or MR 370
(Scénic II), Mechanical, 13B, Diesel
injection, Diesel injector: Removal -
Refitting).
Check the high pressure system by running TEST 6 High pressure system check.
Check that the computer connectors are properly locked.
Check the condition of the computer connections (bent pin, signs of corrosion, silicone, etc.).
If the connector(s) are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Contact the Techline if the customer complaint is still present.
A
NO
YES

13B-174
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
V4 MR-372-J84-13B000$140.mif
DIESEL INJECTION
Fault finding – Fault finding charts13B
InjectionDDCR
Vdiag No.: 44, 48
ALP5 Rough idle (pumping)
NOTESOnly consult this customer complaint after a complete check with the diagnostic tool.
Check that the fuel tank is correctly filled and that the fuel is correct by running TEST 13 Diesel fuel conformity
check.
Check the low pressure circuit by running TEST 1 Low pressure circuit check.
Using the diagnostic tool, check that the injector codes (C2I) are correctly entered on the identification screen. If
not, configure the correct injector codes using command SC002 Enter injector codes.
Visually check the condition of the engine wiring harness.
Visually check that there are no leaks on the high pressure circuit by running TEST 7 High pressure circuit
sealing check.
Is the compression in order? Carry out the necessary repairs.
Check the electrical conformity of the heater plugs (the resistance value of the heater plug must be less than 2 Ω).
Check the high pressure system by running TEST 6 High pressure system check.
Contact the Techline if the customer complaint is still present.
NO
YES
DDCR_V44_ALP05/DDCR_V48_ALP05

13B-175
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
V4 MR-372-J84-13B000$140.mif
DIESEL INJECTION
Fault finding – Fault finding charts13B
InjectionDDCR
Vdiag No.: 44, 48
ALP6 Idling speed too high or too low
NOTESOnly consult this customer complaint after a complete check with the diagnostic tool.
Using the diagnostic tool, check that the injector codes (C2I) are correctly entered on the identification screen. If
not, configure the correct injector codes using command SC002 Enter injector codes.
Check the air inlet circuit by running TEST 2 Electrical circuit check.
Is the clutch clearance set correctly? Carry out the necessary repairs
Check that the computer connectors are properly locked.
Check the condition of the computer connections (bent pin, signs of corrosion, silicone, etc.).
If the connector(s) are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Contact the Techline if the customer complaint is still present.
NO
YES
DDCR_V44_ALP06/DDCR_V48_ALP06

13B-176
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
V4 MR-372-J84-13B000$140.mif
DIESEL INJECTION
Fault finding – Fault finding charts13B
InjectionDDCR
Vdiag No.: 44, 48
ALP7 Unexpected acceleration/deceleration and engine racing
NOTESOnly consult this customer complaint after a complete check with the diagnostic tool.
Check that the engine has not sucked up its oil (engine racing).
Check the air inlet circuit by running TEST 5 Inlet circuit check.
Using the diagnostic tool, check that the injector codes (C2I) are correctly entered on the identification screen. If
not, configure the correct injector codes using command SC002 Enter injector codes.
Visually check the condition of the engine wiring harness.
Check the injectors by running TEST 3 Injector check.
Check that the computer connectors are properly locked.
Check the condition of the computer connections (bent pin, signs of corrosion, silicone, etc.).
If the connector(s) are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Contact the Techline if the customer complaint is still present.
DDCR_V44_ALP07/DDCR_V48_ALP07
