BRC-72
< SERVICE INFORMATION >[VDC/TCS/ABS]
TROUBLE DIAGNOSIS FOR
SELF-DIAGNOSTIC ITEMS
2. Select “YAW RATE SEN”, “SIDE G-SENSOR” in “Data Monitor” and check Yaw rate/side/decel G sensor
signal.
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-89, "Removal and Installa-
tion".
NO >> Replace Yaw rate/side/decel G sensor. Refer to BRC-92, "
Removal and Installation".
Solenoid and VDC Change-Over Valve System InspectionINFOID:0000000005928489
INSPECTION PROCEDURE
1.SELF-DIAGNOSIS RESULT CHECK
Check self-diagnosis results.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> Inspection End.
2.CONNECTOR INSPECTION
1. Disconnect ABS actuator and electric unit (control unit) connector.
2. Check the terminals for deformati on, disconnection, looseness or damage.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace as necessary.
3.CHECKING SOLENOID POWER AND GROUND
Vehicle condition Yaw rate sensor (Data monitor) Side G sensor (Data monitor)
Stopped Approx. 0 d/s
Approx. 0 m/s
2
Turning right Negative valueNegative value
Turning left Positive valuePositive value
Self-diagnosis results
FR LH IN ABS SOL
FR LH OUT ABS SOL RR RH IN ABS SOL
RR RH OUT ABS SOL FR RH IN ABS SOL
FR RH OUT ABS SOL RR LH IN ABS SOL
RR LH OUT ABS SOL USV LINE [FL-RR]
USV LINE [FR-RL]
HSV LINE [FL-RR]
HSV LINE [FR-RL] MAIN RELAY
Revision: May 2010 2011 Versa

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
BRC-73
< SERVICE INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
1. Check voltage between ABS actuator and electric unit (control unit) harness connector E33 and body ground.
2. Check resistance between ABS actuator and electric unit (con- trol unit) harness connector E33 and body ground.
OK or NG
OK >> Perform self-diagnosis again. If the same results appear, replace ABS actuator and electric unit (control
unit). Refer to BRC-89, "
Removal and Installation".
NG >> Repair the circuit.
Actuator Motor, Motor Relay, and Circuit InspectionINFOID:0000000005928490
INSPECTION PROCEDURE
1.CHECKING SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> Inspection End.
2.CONNECTOR INSPECTION
Disconnect the ABS actuator and electr ic unit (control unit) connector.
Check the terminals for deformation, disconnection, looseness or damage.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace as necessary.
3.CHECKING ABS MOTOR AND MOTOR RELAY POWER SYSTEM
1. Check voltage between ABS actuator and electric unit (control unit) harness connector E33 and ground. ABS actuator and electric
unit (control unit) harness connector E33 Body
ground Measured
value
(Approx.)
3 — 12V
WFIA0499E
ABS actuator and electric
unit (control unit) harness connector E33 Body
ground Measured
value
(Approx.)
4—0 Ω
WFIA0500E
Self-diagnosis results
PUMP MOTOR
ABS actuator and electric
unit (control unit) harness connector E33 Body
ground Measured
value
(Approx.)
2 — 12V
WFIA0501E
Revision: May 2010 2011 Versa

CVT SYSTEMCVT-21
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
Hydraulic Control SystemINFOID:0000000005928735
TCM FunctionINFOID:0000000005928736
The function of the TCM is to:
• Receive input signals sent from various switches and sensors.
• Determine required line pressure, shifting point, and lock-up operation.
• Send required output signals to the step motor and the respective solenoids.
CONTROL SYSTEM OUTLINE
The CVT senses vehicle operating conditions through various sensors. It always controls the optimum shift
position and reduces shifting and lock-up shocks.
AWDIA0768GB
SENSORS (or SIGNAL)
⇒TCM
⇒ACTUATORS
Transmission range switch
Accelerator pedal position signal
Closed throttle position signal
Engine speed signal
CVT fluid temperature sensor
Vehicle speed signal
Overdrive control signal
Stop lamp switch signal
Primary speed sensor
Secondary speed sensor
Secondary pressure sensor Shift control
Line pressure control
Primary pressure control
Secondary pressure control
Lock-up control
Engine brake control
Vehicle speed control
Fail-safe control
Self-diagnosis
CONSULT-III co
mmunication
line
Duet-EA control
CAN system
On board diagnosis Step motor
Torque converter clutch solenoid
valve
Lock-up select solenoid valve
Line pressure solenoid valve
Secondary pressure solenoid
valve
Shift position indicator
O/D OFF indicator lamp
Starter relay
Revision: May 2010
2011 Versa

CVT-54
< SERVICE INFORMATION >[RE0F08B]
TROUBLE DIAGNOSIS
BRAKE SW (on/off)
XX Stop lamp switch (Signal input with CAN comuni-
cation)
FULL SW (on/off) XX
Signal input with CAN communications
IDLE SW (on/off) XX
SPORT MODE SW (on/off) XX Overdrive control switch (Signal input with CAN
comunication)
STRDWNSW (on/off) X—
Not mounted but displayed.
STRUPSW (on/off)
X—
DOWNLVR (on/off) X—
UPLVR (on/off) X—
NONMMODE (on/off) X—
MMODE (on/off) X—
INDLRNG (on/off) —— “L” position indicator output
INDDRNG (on/off) —— “D” position indicator output
INDNRNG (on/off) —— “N” position indicator output
INDRRNG (on/off) —— “R” position indicator output
INDPRNG (on/off) —— “P” position indicator output
CVT LAMP (on/off) ——
SPORT MODE IND (on/off) ——
MMODE IND (on/off) —— Not mounted but displayed.
SMCOIL D (on/off) —— Step motor coil “D” energizing status
SMCOIL C (on/off) —— Step motor coil “C” energizing status
SMCOIL B (on/off) —— Step motor coil “B” energizing status
SMCOIL A (on/off) —— Step motor coil “A” energizing status
LUSEL SOL OUT (on/off) ——
REV LAMP (on/off) — X
STRTR RLY OUT (on/off) —— Starter relay
LUSEL SOL MON (on/off) ——
STRTR RLY MON (on/off) —— Starter relay
VDC ON (on/off) X—
Not mounted but displayed.
TCS ON (on/off) X—
ABS ON (on/off) X—
ACC ON (on/off) X— Not mounted but displayed.
RANGE —X Indicates position is recognized by TCM. Indi-
cates a specific value required for control when
fail-safe function is activated.
M GEAR POS —X
Monitored item (Unit)
Monitor item selection
Remarks
ECU IN-
PUT SIG- NALS MAIN SIG-
NALS SELEC-
TION
FROM
MENU
Revision: May 2010 2011 Versa

EC-5
C
DE
F
G H
I
J
K L
M
EC A
N
O P
Component Inspection (Fuel filler cap) ...............
..
344
Component Inspection (Drain filter) ......................345
P0460 FUEL LEVEL SENSOR ...................... ..346
Description .......................................................... ..346
DTC Logic .............................................................346
Diagnosis Procedure .............................................346
P0461 FUEL LEVEL SENSOR ........................347
Description .......................................................... ..347
DTC Logic .............................................................347
Component Function Check ..................................347
Diagnosis Procedure .............................................348
P0462, P0463 FUEL LEVEL SENSOR ............349
Description .......................................................... ..349
DTC Logic .............................................................349
Diagnosis Procedure .............................................349
P0500 VSS .......................................................351
Description .......................................................... ..351
DTC Logic .............................................................351
Component Function Check ..................................352
Diagnosis Procedure .............................................352
P0506 ISC SYSTEM .........................................353
Description .......................................................... ..353
DTC Logic .............................................................353
Diagnosis Procedure .............................................353
P0507 ISC SYSTEM .........................................355
Description .......................................................... ..355
DTC Logic .............................................................355
Diagnosis Procedure .............................................355
P0603 ECM POWER SUPPLY .........................357
Description .......................................................... ..357
DTC Logic .............................................................357
Diagnosis Procedure .............................................357
P0605 ECM .......................................................359
Description ............................................................359
DTC Logic .............................................................359
Diagnosis Procedure .............................................360
P0607 ECM .......................................................361
Description ............................................................361
DTC Logic .............................................................361
Diagnosis Procedure .............................................361
P0643 SENSOR POWER SUPPLY .................362
DTC Logic ........................................................... ..362
Wiring Diagram .....................................................363
Diagnosis Procedure .............................................363
P0850 PNP SWITCH ........................................366
Description ............................................................366
DTC Logic .............................................................366
Component Function Check ..................................367
Wiring Diagram .....................................................368
Diagnosis Procedure .............................................368
P1148 CLOSED LOOP CONTROL ................371
DTC Logic ............................................................ ..371
P1217 ENGINE OVER TEMPERATURE ........372
DTC Logic ..............................................................372
Component Function Check ..................................372
Diagnosis Procedure .............................................373
P1225 TP SENSOR .........................................376
Description .............................................................376
DTC Logic ..............................................................376
Diagnosis Procedure .............................................376
Special Repair Requirement ..................................377
P1226 TP SENSOR .........................................378
Description .............................................................378
DTC Logic ..............................................................378
Diagnosis Procedure .............................................378
Special Repair Requirement ..................................379
P1421 COLD START CONTROL ...................380
Description .............................................................380
DTC Logic ..............................................................380
Diagnosis Procedure .............................................380
P1715 INPUT SPEED SENSOR (PRIMARY
SPEED SENSOR) ...........................................
382
Description ........................................................... ..382
DTC Logic ..............................................................382
Diagnosis Procedure .............................................382
P1805 BRAKE SWITCH .................................383
Description .............................................................383
DTC Logic ..............................................................383
Wiring Diagram ......................................................384
Diagnosis Procedure .............................................384
Component Inspection (Stop Lamp Switch) ..........386
P2100, P2103 THROTTLE CONTROL MO-
TOR RELAY ....................................................
387
Description .............................................................387
DTC Logic ..............................................................387
Wiring Diagram ......................................................388
Diagnosis Procedure .............................................388
P2101 ELECTRIC THROTTLE CONTROL
FUNCTION ......................................................
391
Description ........................................................... ..391
DTC Logic ..............................................................391
Wiring Diagram ......................................................392
Diagnosis Procedure .............................................392
Component Inspection ...........................................395
Special Repair Requirement ..................................395
P2118 THROTTLE CONTROL MOTOR .........396
Description .............................................................396
DTC Logic ..............................................................396
Wiring Diagram ......................................................397
Diagnosis Procedure .............................................397
Component Inspection ...........................................398
Special Repair Requirement ..................................399
Revision: May 2010 2011 Versa

EC-13
C
DE
F
G H
I
J
K L
M
EC A
N
O P
CVT ........................................................................
..
942
CVT : Description ..................................................942
CVT : CONSULT-III Reference Value in Data
Monitor Mode ...................................................... ..
942
CVT : On Board Diagnosis Logic ..........................943
CVT : DTC Confirmation Procedure ......................943
CVT : Diagnosis Procedure ...................................943
DTC P1805 BRAKE SWITCH ..........................944
Description .......................................................... ..944
CONSULT-III Reference Value in Data Monitor
Mode ................................................................... ..
944
On Board Diagnosis Logic ....................................944
DTC Confirmation Procedure ................................944
Wiring Diagram .....................................................945
Diagnosis Procedure .............................................946
Component Inspection ..........................................947
DTC P2100, P2103 THROTTLE CONTROL
MOTOR RELAY ...............................................
948
Component Description ....................................... ..948
CONSULT-III Reference Value in Data Monitor
Mode ................................................................... ..
948
On Board Diagnosis Logic ....................................948
DTC Confirmation Procedure ................................948
Wiring Diagram .....................................................949
Diagnosis Procedure .............................................950
DTC P2101 ELECTRIC THROTTLE CON-
TROL FUNCTION ........................................... ..
952
Description .......................................................... ..952
On Board Diagnosis Logic ....................................952
DTC Confirmation Procedure ................................952
Wiring Diagram .....................................................953
Diagnosis Procedure .............................................954
Component Inspection ..........................................957
Removal and Installation .......................................957
DTC P2118 THROTTLE CONTROL MOTOR ..958
Component Description ....................................... ..958
On Board Diagnosis Logic ....................................958
DTC Confirmation Procedure ................................958
Wiring Diagram .....................................................959
Diagnosis Procedure .............................................960
Component Inspection ..........................................961
Removal and Installation .......................................961
DTC P2119 ELECTRIC THROTTLE CON-
TROL ACTUATOR ...........................................
963
Component Description ....................................... ..963
On Board Diagnosis Logic ....................................963
DTC Confirmation Procedure ................................963
Diagnosis Procedure .............................................964
DTC P2122, P2123 APP SENSOR ..................965
Component Description ....................................... ..965
CONSULT-III Reference Value in Data Monitor
Mode ................................................................... ..
965
On Board Diagnosis Logic ....................................965
DTC Confirmation Procedure ................................965
Wiring Diagram .................................................... ..966
Diagnosis Procedure .............................................967
Component Inspection ...........................................969
Removal and Installation .......................................969
DTC P2127, P2128 APP SENSOR .................970
Component Description .........................................970
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ..
970
On Board Diagnosis Logic .....................................970
DTC Confirmation Procedure ................................971
Wiring Diagram ......................................................972
Diagnosis Procedure .............................................973
Component Inspection ...........................................975
Removal and Installation .......................................976
DTC P2135 TP SENSOR ................................977
Component Description .........................................977
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ..
977
On Board Diagnosis Logic .....................................977
DTC Confirmation Procedure ................................977
Wiring Diagram ......................................................978
Diagnosis Procedure .............................................979
Component Inspection ...........................................981
Removal and Installation .......................................981
DTC P2138 APP SENSOR .............................982
Component Description .........................................982
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ..
982
On Board Diagnosis Logic .....................................982
DTC Confirmation Procedure ................................983
Wiring Diagram ......................................................984
Diagnosis Procedure .............................................985
Component Inspection ...........................................988
Removal and Installation .......................................988
DTC P2A00 A/F SENSOR 1 ...........................989
Component Description .........................................989
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ..
989
On Board Diagnosis Logic .....................................989
DTC Confirmation Procedure ................................989
Wiring Diagram ......................................................991
Diagnosis Procedure .............................................992
Removal and Installation .......................................995
ASCD BRAKE SWITCH ..................................996
Component Description .........................................996
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ..
996
Wiring Diagram ......................................................997
Diagnosis Procedure .............................................998
Component Inspection .........................................1002
ASCD INDICATOR .........................................1004
Component Description .......................................1004
CONSULT-III Reference Value in Data Monitor
Mode ....................................................................
1004
Revision: May 2010 2011 Versa

EC-46
< FUNCTION DIAGNOSIS >[HR16DE]
ENGINE CONTROL SYSTEM
Crankshaft position sensor (POS)
EC-267, "Description"
Cooling fan motorEC-71, "System Description"
Electric throttle control actuatorEC-400, "Description"
Engine coolant temperature sensorEC-168, "Description"
EVAP canister purge volume control solenoid valveEC-295, "Description"
EVAP canister vent control valveEC-305, "Description"
EVAP control system pressure sensorEC-316, "Description"
Fuel injectorEC-433, "Description"
Fuel level sensorEC-346, "Description"
Fuel pumpEC-437, "Description"
Fuel tank temperature sensorEC-244, "Description"
Heated oxygen sensor 2EC-207, "Description"
Heated oxygen sensor 2 heaterEC-142, "Description"
Ignition signalEC-442, "Description"
Intake air temperature sensorEC-164, "Description"
Intake valve timing control solenoid valveEC-89, "System Description"
Knock sensorEC-263, "Description"
Mass air flow sensorEC-150, "Description"
PCV valveEC-459, "Description"
Refrigerant pressure sensorEC-460, "Description"
Stop lamp switchEC-383, "Description"
Throttle control motorEC-396, "Description"
Throttle control motor relayEC-387, "Description"
Throttle position sensorEC-174, "Description"
Component Reference
Revision: May 2010 2011 Versa

AIR CONDITIONING CUT CONTROLEC-63
< FUNCTION DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
AIR CONDITIONING
CUT CONTROL
System DiagramINFOID:0000000005929775
System DescriptionINFOID:0000000005929776
INPUT/OUTPUT SIGNAL CHART
*1: This signal is sent to the ECM via the CAN communication line.
*2: ECM determines the start signal status by the signals of engine speed and battery voltage.
SYSTEM DESCRIPTION
This system improves engine operation when the air conditioner is used.
Under the following conditions, the air conditioner is turned off.
• When the accelerator pedal is fully depressed.
• When cranking the engine.
• At high engine speeds.
• When the engine coolant temperature becomes excessively high.
JMBIA2195GB
Sensor Input Signal to ECMECM functionActuator
Air conditioner switch*
1Air conditioner ON signal
Air conditioner
cut controlIPDM E/R
↓
Air conditioner relay
↓
Compressor
Accelerator pedal position sensor
Accelerator pedal position
Crankshaft position sensor (POS)
Camshaft position sensor (PHASE) Engine speed*
2
Engine coolant temperature sensor
Engine coolant temperature
Battery Battery voltage*
2
Refrigerant pressure sensorRefrigerant pressure
EPS control unit Power steering operation
ABS actuator and electric unit (control unit) Vehicle speed*
1
Combination meter
BCMAir conditioner ON signal*
1
Revision: May 2010 2011 Versa
