SE-18
< SERVICE INFORMATION >
REAR SEAT
1. Install the rear seatback side bracket, temporarily tighten theseatback assembly and rear seatback side bracket bolt.
2. Lift to fold up seatback assembly. Be sure to lock seatback assembly to rear seat striker.
3. Tighten the rear seatback side bracket bolt. NOTE:
Confirm that side hinge bracket location pin is set to the hole on
the seatback backside.
• Install the left rear seat back brackets and seatback mounting
bolts.
• Install the right rear seat bac k brackets and the rear seat back
bracket bolts.
Disassembly and AssemblyINFOID:0000000006415822
60:40 SPLIT FOLD DOWN SEAT - HATCHBACK
Disassembly of Armrest
1. Fold up the backside of the seatback trim and then remove the armrest nuts.
PIIB2484J
WIIA1288E
WIIA1287E
PIIB2913J
Revision: May 2010 2011 Versa
SRS-40
< ON-VEHICLE REPAIR >
SIDE CURTAIN AIR BAG MODULE
SIDE CURTAIN AIR BAG MODULE
ComponentINFOID:0000000005931214
Hatchback ModelsSedan Models
Removal and InstallationINFOID:0000000005931215
REMOVAL
WARNING:
AWHIA0260GB
1. Side curtain air bag module 2. Inflator 3. Ground bolt
Vehicle front
AWHIA0261GB
1. Side curtain air bag module 2. Inflator 3. Side air bag module connector
Vehicle front
Revision: May 2010 2011 Versa
