2011 Lexus IS220d Owner's Manual

5
535
5-2. Steps to take in an emergency
When trouble arises
IS250/220d/200d_EE
CAUTION
If the engine has to be turned off while driving
Power assist for the brakes and steering wheel will be lost, making the brake
pedal harder to depress and the steering wheel heavier to turn. Decelerate as
much as possible before turning off the engine.

536
5-2. Steps to take in an emergency
IS250/220d/200d_EE

6Vehicle specifications
533
6-1. Specifications
Maintenance data
(fuel, oil level, etc.)........ 534
Fuel information .............. 553
6-2. Customization
Customizable features...... 556

534
IS250/220d/200d_EE
6-1. Specifications
Maintenance data (fuel, oil level, etc.)
Dimensions and weight
Overall length4585 mm (180.5 in.)
Overall width1800 mm (70.9 in.)
Overall height*1
IS250
1425 mm (56.1 in.)
*2
1440 mm (56.7 in.)*3
IS220d and IS200d
1425 mm (56.1 in.)
*4
1440 mm (56.7 in.)*5
Wheelbase2730 mm (107.4 in.)
Tread
Front1535 mm (60.4 in.)
Rear1525 mm (60 in.)*4
1535 mm (60.4 in.) *5
Gross vehicle mass
IS250
2045 kg (4508 lb.)
IS220d and IS200d
2075 kg (4575 lb.)
Maximum permis-
sible axle capacityFront
IS250
1070 kg (2359 lb.)
IS220d and IS200d
1090 kg (2403 lb.)
Rear1150 kg (2535 lb.)
Drawbar load70 kg (154.4 lb.)
Towing capacity
with
brake1500 kg (3307 lb.)
without
brake560 kg (1235 lb.)

535
6-1. Specifications
6
Vehicle specifica-
IS250/220d/200d_EE
*1:Unladen vehicle
*2:Except in Turkey, Ukraine, Kazakhstan and Belarus (except 18-inch
tires)
*3:In Turkey, Ukraine, Kazakhstan and Belarus (18-inch tires)
*4:Models with 18-inch tires
*5:Models with 16-inch or 17-inch tires
Vehicle identification
Vehicle identification number
The vehicle identification number (VIN) is the legal identifier for
your vehicle. This is the primary identification number for your
Lexus. It is used in registering the ownership of your vehicle.
This number is stamped on the top left of the instrument panel or in
the engine compartment.
This number is also on the man-
ufacturer’s label.

536
6-1. Specifications
IS250/220d/200d_EEEngine number
The engine number is stamped on the engine block as shown.
IS250
IS220d and IS200d

537
6-1. Specifications
6
Vehicle specifica-
IS250/220d/200d_EE
Engine
Model4GR-FSE2AD-FHV, 2AD-FTV
Ty p e6-cylinder V type,
4-cycle, gasoline4 cylinder in line, 4
cycle, diesel
(with turbocharger)
Bore and stroke83.0  77.0 mm
(3.27 3.03 in.)86.0  96.0 mm
(3.39 3.78 in.)
Displacement2500 cm3
(152.5 cu.in.)2231 cm3
(136.1 cu.in.)
Drive belt tensionAutomatic adjustment

538
6-1. Specifications
IS250/220d/200d_EE
Fuel
IS250
IS220d and IS200d
Fuel type
EU area:
Unleaded gasoline conforming to European stan-
dard EN228 only
Except EU area:
Unleaded gasoline only
Research octane num-
ber95 or higher
Fuel tank capacity
(Reference)65 L (17.2 gal., 14.3 Imp. gal.)
Fuel type
EU area:
Diesel fuel conforming to European standard
EN590
Except EU area:
Diesel fuel that contains 50 ppm or less of sulfur
Cetane number48 or higher
Fuel tank capacity
(Reference)65 L (17.2 gal., 14.3 Imp. gal.)
