2011 Lexus IS F Using The Bluetooth Audio System / LEXUS 2011 IS F OWNERS MANUAL QUICK GUIDE (OM53A11U)

9
Seats
■Adjusting seat position
Moves the seat forward
Moves the seat backward
■Adjusting seatback angle
Tilts the seatback forward
Reclines the seatback
■Adjusting seat cushion
Raises and lowers the front of the cushion
Raises and lowers the entire seat
■Adjusting lumbar support
Firmer
Softer
1
2
1
2
1
2
1
2

10
Outside Rear View Mirrors
Selects a mirror to adjust (“L”: left or “R”: right)
Adjusts the mirror up, down, in, or out using
the switch
The mirrors will automatically angle downwards
when the vehicle is reversing.
To disable this function, set the mirror select switch
in the neutral position (between “L” and “R”).
Steering Wheel
Up
Down
Aw a y f ro m t h e d r i v e r
Toward the driver1
2
3
4
The steering wheel retracts automatically when the “ENGINE START STOP” switch is
turned OFF to allow for easy exit and entry. The steering wheel returns automatically to its
previously set position when the “ENGINE START STOP” switch is switched to ACCES-
SORY or IGNITION ON mode.

11
Driving and Seat Position Memory System
■Setting memory positions
Press the “SET” button, then within 3 seconds
press one of the memory buttons (“1”, “2”, or “3”)
until you hear a beep.
The current position of the seat, as well as the
position of the steering wheel and the outside
rear view mirrors (for the driver's seat only) is
recorded.
■Recalling memory positions
Press one of the memory buttons (“1”, “2”, or “3”).
■Linking driving position memory with door unlock operation (driver’s seat only)
While holding down the desired memory button,
press and hold on the wireless remote control
or door lock switch until you hear a beep.
To prevent triggering of the alarm, open one of
the doors within 180 seconds after the beep is
heard.
Your preferred driving position (the position of the driver's seat, steering wheel and the
outside rear view mirrors) and front passenger seat position can be memorized and
recalled with the touch of a button.
Linking driving position memory to the door unlock operation allows the memory position
to be recalled automatically when the driver's door is opened. (The linked function does not
operate if the driver's door is unlocked using the mechanical key or manually from inside
the vehicle.)

12
Head Restraints
■Vertical adjustment (front seats)
To r a i s e: push the head restraint upward.
To l o w e r: push the head restraint down while
pressing the lock release button.
■Folding (rear seats only)
Pull the head restraint up while pressing the lock
release button.
Seat Belts
■Adjusting shoulder belt height (front seats only)
To r a i s e: push the anchor upward.
To l o w e r: depress the button and push the anchor
down.
■Seat belt comfort guides (rear seats only)
If the shoulder belt sits close to the neck, slide the
comfort guide forward.
Lock
release
button
Lock release button

13
Anti-glare Inside Rear View Mirror
Without compass
Turns automatic mode on
Turns automatic mode off
The indicator comes on when automatic mode
is turned on.
With compass
Turns automatic mode on/off
The indicator comes on when automatic mode
is turned on.
The anti-glare mirror uses a sensor to detect light from vehicles behind and automatically
reduces glare.
1
2

14
Engine (Ignition) Switch
■Starting the engine
Make sure the parking brake is set and the shift
lever is in P.
Depress the brake pedal.
The “ENGINE START STOP” switch indi-
cator light turns green.
Press the “ENGINE START STOP” switch.
■Stopping the engine
Set the parking brake and shift the shift lever to P.
Press the “ENGINE START STOP” switch.
■Changing “ENGINE START STOP” switch modes
To change the “ENGINE START STOP” switch mode without turning on the engine, press
the “ENGINE START STOP” switch without depressing the brake pedal. The mode can be
changed in the following order:
With the electronic key on your person, the engine can be started by simply pressing the
“ENGINE START STOP” switch while depressing the brake pedal.
(The mechanical key cannot be used to start the engine.)
ACCE SSORY modeIGNITION ON mode
(Indicator light: amber) OFF
(Indicator light: off)

15
Automatic Transmission
■Shift positions
PPa r k
RReverse
NNeutral (drive not engaged)
DDrive
MM mode
The vehicle can only be shifted out of P when
the “ENGINE START STOP” switch is in
IGNITION ON mode and the brake pedal is
depressed.

16
■Changing shift ranges in the D position
Operating the paddle shift switches allows shift ranges to be selected to suit the driving con-
ditions.
Pull the “-” paddle shift switch toward you.
The indicator in the meter cluster will
change to display the selected shift range.
Higher shift range:
Pull the “+” paddle shift switch toward you.
Lower shift range:
Pull the “-” paddle shift switch toward you.
Pulling and holding the “+” paddle shift switch for a certain period of time allows you to
return to normal D position driving. If the accelerator pedal is depressed for more than a
certain period of time in one range, shift range selection in the D position will be automati-
cally deactivated.
