2011 Lexus IS F Using The Bluetooth Audio System / LEXUS 2011 IS F OWNERS MANUAL QUICK GUIDE (OM53A11U)

Contents
The Quick Guide is not intended as a substitute for your Owner’s
Manual. We strongly encourage you to review the Owner’s
Manual and supplementary manuals so you will have a better
understanding of your vehicle’s capabilities and limitations.
1
Air Conditioning System
Using the automatic mode ........................................................................................................34
Adjusting the temperature in dual mode ............................................................................ 34
Anti-glare Inside Rear View Mirror...............................................................................................13
Ashtrays ..................................................................................................................................................... 41
Audio System
Basic operation .............................................................................................................................. 28
Radio................................................................................................................................................... 29
CD player ......................................................................................................................................... 30
Operating an iPod ........................................................................................................................ 33
Remote control (steering wheel switches) ......................................................................... 33
Automatic Transmission .....................................................................................................................15
Compass ................................................................................................................................................. 44
Console Boxes ..................................................................................................................................... 42
Cruise Control...................................................................................................................................... 23
Cup Holders .......................................................................................................................................... 43
Door Locks..............................................................................................................................................47
Driving and Seat Position Memory System................................................................................. 11
Dynamic Radar Cruise Control ....................................................................................................24
Emergency Flasher Switch ...............................................................................................................22
Engine (Ignition) Switch ...................................................................................................................... 14
Fog Lights................................................................................................................................................ 26
F-Sport Mode Total Control Switch/SNOW Mode Switch ..............................................18
Fuel Tank Cap ....................................................................................................................................... 49
Garage Door Opener ...................................................................................................................... 35
Glove Box............................................................................................................................................... 43
Head Restraints ...................................................................................................................................... 12
Headlight Cleaner .............................................................................................................................. 25
Headlights............................................................................................................................................... 25
Hood ......................................................................................................................................................... 49
Instrument Panel Light Control ......................................................................................................27
Interior Lights ........................................................................................................................................ 44
Intuitive Parking Assist .......................................................................................................................22
Keys .............................................................................................................................................................. 6
Lexus Enform with Safety Connect............................................................................................. 39
Luggage Mat ......................................................................................................................................... 46
Moon Roof ............................................................................................................................................. 48

2
Multi-information Display .................................................................................................................20
Outside Rear View Mirrors.............................................................................................................. 10
Parking Brake ......................................................................................................................................... 19
Power Windows ...................................................................................................................................48
Rear Window and Outside Rear View Mirror Defoggers ................................................ 27
Safety Connect ..................................................................................................................................... 37
Satellite Switches................................................................................................................................... 21
Seat Belts .................................................................................................................................................. 12
Seat Heaters............................................................................................................................................ 41
Seats ............................................................................................................................................................. 9
Smart Access System with Push-button Start ............................................................................ 7
Steering Wheel ...................................................................................................................................... 10
Theft Deterrent System ........................................................................................................................8
Trunk......................................................................................................................................................... 50
Trunk Storage Extension ..................................................................................................................45
Turn Signal Lever .................................................................................................................................. 19
Windshield Wipers and Washer ...................................................................................................26

3
OverviewInstrument Panel
Paddle shift switch P.15
Headlight switch
Turn signal lever
Fog light switch P.25
P.19
P.26
Headlight cleaner switch  P.25
Distance switch  P.24
Inside door lock buttons P.47
Fuel filler door opener P.49
Driving and seat position
memory switches
P.11
Power window switches P.48
Window lock switch P.48
Outside rear view
mirror switches
P.10
Trunk opener P.50
Hood release lever P.49
Parking brake pedal P.19
Satellite switches P.21
Tilt and telescopic steering
control switch
P.10
Multi-information
display
P.20
Door lock switches P.47

4
Paddle shift switch P.15
Windshield wiper and
washer switch
P.26
Engine (ignition) switch P.14
Air conditioning system P.34
Emergency flasher switch P.22
Rear window and outside rear
view mirror defoggers switch
P.27
Security indicator P.8
Audio system P.28
Glove box P.43
Trunk opener main switch P.50
See P.5.
Cruise control switch

Dynamic radar cruise control switch 
P.23
P.24
SNOW mode switch P.18
F-sport mode total control switch P.18
 : If equipped

5
OverviewInstrument Panel
Seat heater switchesP.41
Automatic transmission shift lever P.15
Ashtray P.41
Cup holders P.43
 : If equipped

6
Keys
■Electronic key
Smart access system with push-button start
(P. 7 , 1 4 )
*: Canada only
■Mechanical key
●Locks and unlocks the doors
●Opens the trunk
●Locks and unlocks the glove box
The mechanical key is stored inside the electronic
key. To extract the key, release the latch and pull,
or if equipped with a card key, press the button
and pull.
■Wireless remote control
Press: locks all doors
Press once: unlocks the driver's door
Press twice: unlocks all doors
Press and hold: opens the trunk
Press and hold: sounds the alarm
(Use the alarm to attract attention to the vehi-
cle in order to help deter break-ins. To stop the
alarm, press any button on the wireless remote
control.)
Card key*
1
2
3
4

7
Smart Access System with Push-button Start
■Entering the vehicle
To unlock the vehicle, simply grasp either of the
front door handles.
■Exiting the vehicle
To lock the vehicle, press the lock button on either
of the front door handles.
■Opening the trunk
To open the trunk, press the trunk release button.
The smart access system with push-button start allows you to enter and exit the vehicle
or start the engine by simply carrying the electronic key in your pocket or bag.
For details on starting the engine, see page 14.
For details on what to do when the electronic key does not operate properly, see page 53.

8
Theft Deterrent System
■Engine immobilizer system
The engine immobilizer system prevents the
engine from being started in the event that an
attempt is made to start the vehicle using an
unregistered key.
The security indicator light flashes to indicate that
the system is set.
■Alarm
The system sounds the alarm and flashes the lights when forcible entry is detected.
To set the alarm: close the doors, trunk and hood, and lock all doors. The security indicator
light comes on to indicate that the alarm is in its preparation state. When the indicator light
begins to flash, the system is armed.
To deactivate or stop the alarm: turn the “ENGINE START STOP” switch to ACCESSORY
or IGNITION ON mode or start the engine, or unlock the doors or trunk.
■Steering lock
The steering wheel locks when the “ENGINE
START STOP” switch is turned OFF and the
driver’s door is opened.
When the steering lock cannot be released, the
green indicator light on the “ENGINE START
STOP” switch will flash and a message will be
shown on the multi-information display. To release
it, gently turn the wheel left or right while pressing
the “ENGINE START STOP” switch.
The theft deterrent system includes the following features to help protect your vehicle from
theft.
