SE-138
< REMOVAL AND INSTALLATION >
THIRD SEAT
Removal and Installation
INFOID:0000000006217436
REMOVAL
CAUTION:
When removing and installi ng, use shop cloths to protect parts from damage.
1. Remove the headrest.
2. Remove the leg cover. 1. Pull up the front edge of the leg cover to release the pawls.
2. Slide the leg cover forward to release the pawls.
3. Remove the mounting bolts on the front side of the third seat.
4. Operate fold down switch or reclining switch, and fold down seatback LH and RH.
5. Remove the luggage floor bracket. 1. Remove the luggage floor rear board. Refer to INT-34, "
LUGGAGE FLOOR REAR BOARD :
Removal and Installation".
2. Remove the mounting nuts and screws of the luggage floor bracket.
6. Disconnect harness connector (A) and remove har ness clip (B) of seat harness assembly.
7. Remove the seat belt anchor plate.
8. Remove the mounting nuts on the rear side of the third seat.
9. Remove the third seat assembly from vehicle. CAUTION:
When removing and installi ng, use shop cloths to protect parts from damage.
INSTALLATION
10. Seat cushion pad 11. Leg cover RH 12. Seat hinge assembly RH
13. Seat hinge assembly LH 14. Leg cover LH 15. Seat harness LH
16. Seat bracket assembly LH 17. Seatback silencer LH 18. Headrest LH
19. Seatback board LH 20. Seatback board RH 21. Seatback board clip
22. Luggage floor bracket 23. Seat belt anchor nut 24. Seat belt anchor bolt
25. Seat belt buckle RH 26. Seat belt buckle (center) 27. Seat belt anchor plate
28. Seat belt connector buckle 29. Seat belt buckle LH 30. Hinge cover RH
31. Seatback inner arm cover RH 32. Seatback inner arm cover LH 33. Hinge cover LH
34. Seatback support 35. Seatback frame RH 36. Bush
37. Seat cushion frame RH 38. Seat cushion frame LH 39. Seatback frame LH
: Pawl
Refer to GI-4, "
Components" for symbols in the figure.
: Pawl
JMJIA3899ZZ
JMJIA4264ZZ
Revision: 2010 May2011 QX56
SE-140
< REMOVAL AND INSTALLATION >
THIRD SEAT
1. Remove the headrest holder.CAUTION:
Before installing headrest ho lder check its orientation.
(front/rear and right/left)
2. Remove the seatback trim and pad from seatback frame.
3. Remove the hog rings to separate the seatback trim and seatback pad.
7. Remove the seatback silencer.
8. Remove the seatback inner arm cover (RH and LH).
Assembly
Assemble in the reverse order of disassembly.
CAUTION:
Install the hog rings of seatback trim in position, and then securely connect the trim or trim cord with
the seatback frame.
When installing wire, be caref ul that it is not slackened.
SEAT CUSHION
Disassembly
1. Remove the seat cushion trim and seat cushion pad.
1. Remove the seat cushion retainer.
2. Remove the seat cushion trim and seat cushion pat from seat cushion frame.
3. Remove the hog rings to separate the seatback trim and seatback pad.
2. Remove the hinge cover. Remove the fixing screws, and then remove the hinge cover.
3. Remove the mounting bolts, and then remove the seat cushion assembly.
4. Remove the mounting nuts, and then remove the seat hinge assembly.
Assembly
Assemble in the reverse order of disassembly.
CAUTION:
Install the hog rings of seat cushio n trim in position, and then securely connect the trim or trim cord
with the seat cushion pad wire.
PIIB4084J
Revision: 2010 May2011 QX56
