P1089, P1092 VVEL CONTROL SHAFT POSITION SENSOR
EC-387
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P1089, P1092 VVEL CONTROL
SHAFT POSITION SENSOR
DTC LogicINFOID:0000000006217894
DTC DETECTION LOGIC
NOTE:
If DTC P1089 or P1092 is displayed with DTC P1608, first perform the trouble diagnosis for DTC P1608.
Refer to EC-453, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confi rm that battery voltage is 10 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for 1 second.
2. Check DTC.
Is DTC detected?
YES >> Go to EC-387, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217895
1.VVEL CONTROL SHAFT POSITION SENSOR POWER SUPPLY CIRCUIT
1. Disconnect VVEL control shaft pos ition sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between VVEL control shaf t position sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.DETECT MALFUNCTIONING PART
Check the following.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P1089 VVEL POS SEN/CIRC-B1
[VVEL control shaf
t position sen-
sor (bank 1) circuit]  An excessively low voltage from the sensor
is sent to VVEL control module.
 An excessively high voltage from the sensor is sent to VVEL control module.
 Rationally incorrect voltage is sent to VVEL control module compared with the signals
from VVEL control shaft position sensor 1
and VVEL control shaft position sensor 2.  Harness or connectors
(VVEL control shaft position sen-
sor circuit is open or shorted.)
 VVEL control shaft position sen- sor
 VVEL control module
P1092 VVEL POS SEN/CIRC-B2
[VVEL control shaf
t position sen-
sor (bank 2) circuit]
DTC No. VVEL control shaft position sensor
Ground Voltage (V)
Bank Connector Terminal
P1089 1 F72 3
Ground Approx. 5
6
P1092 2 F70 3
6
Revision: 2010 May2011 QX56

EC-388
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P1089, P1092 VVEL CONTRO
L SHAFT POSITION SENSOR
 Harness for open or short between VVEL control shaft position sensor and VVEL control module
 Loose or poor connection for each connector and harness
>> Repair open circuit, short to ground or short to power in harness or connectors.
3.CHECK VVEL CONTROL SHAFT POSITION SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect VVEL control module harness connector.
3. Check the continuity between VVEL control shaf t position sensor harness connector and VVEL control
module harness connector.
4. Also check harness for short to ground and power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 4.
4.DETECT MALFUNCTIONING PART
Check the following.
 Harness for open or short between VVEL control shaft position sensor and VVEL control module
 Loose or poor connection for each connector and harness
>> Repair open circuit, short to ground or short to power in harness or connectors.
5.VVEL CONTROL SHAFT POSITI ON SENSOR INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between VVEL control shaf t position sensor harness connector and VVEL control
module harness connector.
2. Also check harness for short to ground and power.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 6.
6.DETECT MALFUNCTIONING PART
Check the following.
 Harness for open or short between VVEL control shaft position sensor and VVEL control module
 Loose or poor connection for each connector and harness
>> Repair open circuit, short to ground or short to power in harness or connectors.
7.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
DTC No. VVEL control shaft position
sensor VVEL control module
Continuity
Bank Connector Terminal Connector Terminal
P1089 1 F72 2
F56 6
Existed
519
P1092 2 F70 24
517
DTC No.VVEL control shaft position
sensor VVEL control module
Continuity
Bank Connector Terminal Connector Terminal
P1089 1 F72 1
F56 3
Existed
416
P1092 2 F70 15
418
Revision: 2010 May2011 QX56

EC-390
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P1090, P1093 VVEL ACTUATOR MOTOR
P1090, P1093 VVEL ACTUATOR MOTOR
DTC LogicINFOID:0000000006217896
DTC DETECTION LOGIC
NOTE:
If DTC P1090 or P1093 is displayed with DTC P1091,
first perform the trouble diagnosis for DTC P1091.
Refer to EC-393, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confi rm that battery voltage is 10 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for 10 second.
2. Keep the engine speed at approximately 3,500 rpm for at least 10 seconds under no load.
3. Check DTC.
Is DTC detected?
YES >> Go to EC-390, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217897
1.VVEL ACTUATOR MOTOR ASSEMBLY OUTPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Disconnect VVEL control module harness connector.
2. Disconnect VVEL actuator motor assembly harness connector.
3. Check the continuity between VVEL control modul e harness connector and VVEL actuator motor assem-
bly harness connector.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P1090 VVEL ACTR MOT-B1
[VVEL system performance
(bank 1)]
 Event angle difference between the
actual and the target is detected.
 Abnormal current is sent to VVEL actuator motor assembly.  Harness or connectors
(VVEL actuator motor assembly circuit is open
or shorted.)
 VVEL actuator motor assembly
 VVEL actuator housing assembly
 VVEL ladder assembly
 VVEL control module
P1093
VVEL ACTR MOT-B2
[VVEL system performance
(bank 2)]
DTC No.
VVEL control module VVEL ac
tuator motor assembly
Continuity
Bank Connector Terminal Connector Terminal
P1090 1 F5612
F73 1Existed
2 Not existed
25 1 Not existed
2Existed
P1093 2 2
F71 1Existed
2 Not existed
15 1 Not existed
2Existed
Revision: 2010 May2011 QX56

P1212 TCS COMMUNICATION LINEEC-399
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P1212 TCS COMMUNICATION LINE
DescriptionINFOID:0000000006217906
This CAN communication line is used to control the
smooth engine operation during the TCS operation. Pulse
signals are exchanged between ECM and “ABS actuator and electric unit (control unit)”.
Be sure to erase the malfunction information such as DTC not only fo r “ABS actuator and electric unit
(control unit)” but also for ECM after TCS related repair.
DTC LogicINFOID:0000000006217907
DTC DETECTION LOGIC
NOTE:
 If DTC P1212 is displayed with DTC UXXXX, perform the trouble diagnosis for DTC UXXXX.
 If DTC P1212 is displayed with DTC P0607, perform the trouble diagnosis for DTC P0607.
Freeze frame data is not stored in the ECM for this self-diagnosis.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 10.5 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for at least 10 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-399, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217908
Perform the trouble diagnosis for TCS. Refer to BRC-60, "Work Flow".
NOTE:
If DTC P1212 is displayed with DTC UXXXX and/or P0607, perform the following trouble diagnosis.
 Trouble diagnosis for DTC UXXXX Refer to EC-98, "
DTC Index".
 Trouble diagnosis for DTC P0607 Refer to EC-378, "
DTC Logic".
DTC No.Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P1212 TCS/CIRC
(TCS communication line) ECM cannot receive the information from
“ABS actuator and electric unit (control
unit)” continuously.  Harness or connectors
(The CAN communication line is open or short-
ed.)
 ABS actuator and electric unit (control unit)
 Dead (Weak) battery
Revision: 2010 May2011 QX56

P1220 FUEL PUMP CONTROL MODULE (FPCM)
EC-403
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P1220 FUEL PUMP CONTROL MODULE (FPCM)
DTC LogicINFOID:0000000006217912
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
 Before performing the following procedure, confirm that battery voltage is between 12 - 15 V at idle.
 Before performing the following procedure, check that the engine coolant temperature is −10 °C
(14 °F) or more.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for at least 5 seconds. If engine does not start, crank engine for at least 5 seconds.
2. Check DTC.
Is DTC detected?
YES >> Go to EC-403, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217913
1.CHECK FPCM POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect FPCM harness connector.
3. Turn ignition switch ON.
4. Check the voltage between FPCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2.DETECT MALFUNCTIONING PART
Check the following.
 15 A fuse (No.73)
 Harness for open or short between FPCM and IPDM E/R
 Loose or poor connection for each connector and harness
>> Repair open circuit, short to ground or short to power in harness or connectors.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P1220 FPCM
(Fuel pump control module) During engine cranking, the signal voltage
of the FPCM to the ECM is too low.  Harness or connectors
(FPCM circuit is open or shorted)
(Fuel pump circuit is open or shorted)
FPCM
FPCM Ground Voltage
Connector Terminal
B41 10 Ground Battery voltage
Revision: 2010 May2011 QX56

EC-414
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P1550 BATTERY CURRENT SENSOR
8.CHECK BATTERY CURRENT SENSOR GRO
UND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between battery current sensor harness connector and ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 10.
NO >> GO TO 9.
9.DETECT MALFUNCTIONING PART
Check the following.
 Harness for open or short between battery current sensor and ECM
 Loose or poor connection for each connector and harness
>> Repair open circuit, short to ground or short to power in harness or connectors.
10.CHECK BATTERY CURRENT SENSOR INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between battery current sensor harness connector and ECM harness connector.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 12.
NO >> GO TO 11.
11 .DETECT MALFUNCTIONING PART
Check the following.
 Harness for open or short between battery current sensor and ECM
 Loose or poor connection for each connector and harness
>> Repair open circuit, short to ground or short to power in harness or connectors.
12.CHECK BATTERY CURRENT SENSOR
Refer to EC-414, "
Component Inspection (Battery Current Sensor)".
Is the inspection result normal?
YES >> GO TO 13.
NO >> Replace battery negative cable assembly.
13.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Component Inspection (B attery Current Sensor)INFOID:0000000006217921
1.CHECK BATTERY CURRENT SENSOR
1. Turn ignition switch OFF.
2. Reconnect harness connectors disconnected.
Battery current sensor ECM Continuity
Connector Terminal Connector Terminal
E63 4 E80 150 Existed
Battery current sensor ECM Continuity
Connector Terminal Connector Terminal
E63 3 E80 138 Existed
Revision: 2010 May2011 QX56

P1550 BATTERY CURRENT SENSOREC-415
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
3. Disconnect battery negative cable.
4. Install jumper cable between battery negative terminal and body
ground.
5. Turn ignition switch ON.
6. Check the voltage between ECM harness connector terminals under the following conditions.
Before measuring the terminal voltage, confirm that the battery is fully charged. Refer to PG-159, "How to Handle Battery".
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace battery negative cable assembly.
: To body ground
ECM Voltage (V)
Connector +–
Te r m i n a l Te r m i n a l
E80 138
(Battery current sensor signal) 150 Approx. 2.5
JPBIA3287ZZ
Revision: 2010 May2011 QX56

EC-418
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P1551, P1552 BATTERY CURRENT SENSOR
>> INSPECTION END
8.CHECK BATTERY CURRENT SENSOR GRO
UND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between battery current sensor harness connector and ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 10.
NO >> GO TO 9.
9.DETECT MALFUNCTIONING PART
Check the following.
 Harness for open or short between battery current sensor and ECM
 Loose or poor connection for each connector and harness
>> Repair open circuit, short to ground or short to power in harness or connectors.
10.CHECK BATTERY CURRENT SENSOR INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between battery current sensor harness connector and ECM harness connector.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 12.
NO >> GO TO 11.
11 .DETECT MALFUNCTIONING PART
Check the following.
 Harness for open or short between battery current sensor and ECM
 Loose or poor connection for each connector and harness
>> Repair open circuit, short to ground or short to power in harness or connectors.
12.CHECK BATTERY CURRENT SENSOR
Refer to EC-427, "
Component Inspection (Battery Current Sensor)".
Is the inspection result normal?
YES >> GO TO 13.
NO >> Replace battery negative cable assembly.
13.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Battery current sensor ECM Continuity
Connector Terminal Connector Terminal
E63 4 E80 150 Existed
Battery current sensor ECM Continuity
Connector Terminal Connector Terminal
E63 3 E80 138 Existed
Revision: 2010 May2011 QX56
