P0506 ISC SYSTEM
P0506 ISC SYSTEM
DescriptionINFOID:0000000006217861
The ECM controls the engine idle speed to a specified leve
l through the fine adjustment of the air, which is let
into the intake manifold, by operating the electric thrott le control actuator. The operating of the throttle valve is
varied to allow for optimum control of the engine idli ng speed. The crankshaft position sensor detects the
actual engine speed and sends a signal to the ECM.
The ECM controls the electric throttle control actuator so that the engine speed coincides with the target value
memorized in the ECM. The target engine speed is t he lowest speed at which the engine can operate steadily.
The optimum value stored in the ECM is determined by taking into consideration various engine conditions,
such as during warming up, deceleration and engine load (air conditioner, power steering and cooling fan
operation, etc.).
DTC LogicINFOID:0000000006217862
DTC DETECTION LOGIC
NOTE:
If DTC P0506 is displayed with ot her DTC, first perform the trouble diagnosis for the other DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
If the target idle speed is ou t of the specified value, perform EC-148, "
Work Procedure", before con-
ducting DTC Confirmation Procedure.
TESTING CONDITION:
 Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
 Always perform the test at a temperature above −10 °C (14 °F).
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and warm it up to normal operating temperature.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Turn ignition switch OFF and wait at least 10 seconds.
5. Restart engine and run it for at least 1 minute at idle speed.
6. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-358, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217863
1.CHECK INTAKE AIR LEAKAGE
1. Start engine and let it idle.
2. Listen for an intake air leakage after the mass air flow sensor.
Is intake air leakage detected?
YES >> Discover air leakage location and repair.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P0506 ISC SYSTEM
(Idle speed control system
RPM lower than expected) The idle speed is less than the target idle
speed by 100 rpm or more.
 Electric throttle control actuator
 Intake air leakage
Revision: 2010 May2011 QX56

EC-360
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0507 ISC SYSTEM
P0507 ISC SYSTEM
DescriptionINFOID:0000000006217864
The ECM controls the engine idle speed to a specified leve
l through the fine adjustment of the air, which is let
into the intake manifold, by operating the electric thrott le control actuator. The operating of the throttle valve is
varied to allow for optimum control of the engine idli ng speed. The crankshaft position sensor detects the
actual engine speed and sends a signal to the ECM.
The ECM controls the electric throttle control actuator so that the engine speed coincides with the target value
memorized in the ECM. The target engine speed is t he lowest speed at which the engine can operate steadily.
The optimum value stored in the ECM is determined by taking into consideration various engine conditions,
such as during warming up, deceleration and engine load (air conditioner, power steering and cooling fan
operation, etc.).
DTC LogicINFOID:0000000006217865
DTC DETECTION LOGIC
NOTE:
If DTC P0507 is displayed with ot her DTC, first perform the trouble diagnosis for the other DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
If the target idle speed is ou t of the specified value, perform EC-148, "
Work Procedure", before con-
ducting DTC Confirmation Procedure.
TESTING CONDITION:
 Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
 Always perform the test at a temperature above −10 °C (14 °F).
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and warm it up to normal operating temperature.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Turn ignition switch OFF and wait at least 10 seconds.
5. Start engine and run it for at least 1 minute at idle speed.
6. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-360, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217866
1.CHECK PCV HOSE CONNECTION
Confirm that PCV hose is connected correctly.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning part.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P0507 ISC SYSTEM
(Idle speed control system
RPM higher than expected) The idle speed is more than the target idle
speed by 200 rpm or more.  Electric throttle control actuator
 Intake air leakage
 PCV system
Revision: 2010 May2011 QX56

EC-364
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0524 ENGINE OIL PRESSURE
P0524 ENGINE OIL PRESSURE
DTC LogicINFOID:0000000006288342
DTC DETECTION LOGIC
NOTE:
If DTC P0524 is displayed with DTC P0075 or P0081,
perform trouble diagnosis for DTC P0075 or P0081
first. Refer to EC-193, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING-I
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confi rm that battery voltage is between 10 V and 16 V at
idle.
>> GO TO 2.
2.PRECONDITIONING-II
Check oil level and oil pressure. Refer to LU-7, "
Inspection".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Proceed to LU-7, "
Inspection".
3.PERFORM DTC CONFIRMATION PROCEDURE
WITH CONSULT-III
1. Select “DATA MONITOR” mode with CONSULT-III.
2. Maintain the following conditions for at least 20 consecutive seconds.
CAUTION:
Always drive at a safe speed.
3. Check 1st trip DTC.
WITH GST
Follow the procedure “With CONSULT-III” above.
Is 1st trip DTC detected?
YES >> Proceed to EC-365, "Diagnosis Procedure"
DTC No.Trouble diagnosis name
(Trouble diagnosis content) Detecting condition Possible cause
P0524 ENGINE OIL PRESSURE
(Engine oil pressure too low) Engine oil pressure is low because
there is a gap between angle of target
and phase-control angle.  Engine oil pressure or level too low
 Crankshaft position sensor
 Camshaft position sensor
 Intake valve timing control solenoid valve
 Accumulation of debris to the signal pick-up por-
tion of the camshaft
 Timing chain installation
 Foreign matter caught in the oil groove for intake valve timing control
ENG SPEED More than 1,700 rpm
COOLAN TEMP/S More than 70 °C (158 °F)
Selector lever 1st or 2nd position
Driving location uphill Driving vehicle uphill
(Increased engine load will help maintain the driving
conditions required for this test.)
Revision: 2010 May2011 QX56

P0527 COOLING FAN SPEED SENSOREC-367
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0527 COOLING FAN SPEED SENSOR
DTC LogicINFOID:0000000006217867
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and warm it up to the normal operating temperature.
2. Keep the engine speed approximately 1,000 rpm at no load.
3. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-367, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217868
1.CHECK COOLING FAN SPEED SENSOR POWER SUPPLY CIRCUIT-I
1. Turn ignition switch OFF.
2. Disconnect electrically-controlled c ooling fan coupling harness connector.
3. Turn ignition switch ON.
4. Check the voltage between electrically-controlled cooling fan coupling harness connector terminals.
Is inspection result normal?
YES >> GO TO 6.
NO >> GO TO 2.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0527 Cooling fan speed sen-
sor circuit range/perfor-
mance The number of fan speed signals is 16 rpm or
less during engine rev.  Harness or connectors
(The Fuel rail pressure sensor circuit is
open or shorted.)
(The Power steering pressure sensor cir-
cuit is open or shorted)
(The Electrically-controlled cooling fan
coupling circuit is open or shorted)
 Fuel rail pressure sensor
 Power steering pressure sensor
 Cooling fan speed sensor
 Electrically-controlled cooling fan cou- pling
 Cooling fan
 IPDM E/R
Electrically-controlled cooling fan coupling Vo l ta g e
(Approx.)
Connector +
−
terminal
F39 2 4 5 V
Revision: 2010 May2011 QX56

P0527 COOLING FAN SPEED SENSOREC-369
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Is inspection result normal?
YES >> Check intermittent incident. Refer to
GI-40, "Intermittent Incident".
NO >> Repair or replace error-detected parts.
6.CHECK COOLING FAN SPEED SENSOR SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between electrically-contro lled cooling fan coupling harness connector and ECM har-
ness connector.
4. Also check harness for short to ground and to power.
Is inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace error-detected parts.
7.CHECK COOLING FAN SPEED SENSOR
1. Reconnect all harness connectors disconnected.
2. Perform cooling fan speed sensor component inspection. Refer to EC-369, "
Component Inspection (Cool-
ing Fan Speed Sensor)".
Is inspection result normal?
YES >> GO TO 8.
NO >> Replace electrically-controlled cooling fan coupling.
8.CHECK COOLING FAN ROTATIONAL CONDITION
Rotate the cooling fan by hand.
Dose the cooling fan rotates smoothly?
YES >> GO TO 9.
NO >> Check that the cooling fan is not interfered with other parts.
9.CHECK ELECTRICALLY-CONTROLLED COOLING FAN COUPLING SYSTEM
Refer to EC-495, "
Diagnosis Procedure".
Is inspection result normal?
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> Repair or replace error-detected parts.
Component Inspection (C ooling Fan Speed Sensor)INFOID:0000000006217869
1.CHECK COOLING FAN SPEED SENSOR
1. Turn ignition switch OFF.
2. Disconnect electrically-controlled c ooling fan coupling harness connector.
3. Rotate the electrically-controlled cooling fan coupling slowly with hand and check the voltage between
electrically-controlled cooling fan coupling c onnector terminals under the following conditions.
+
−Continuity
ECM
Connector Terminal F 111 1 0 Ground Existed
E80 174
175
+
−
Continuity
Electrically-controlled cooling fan
coupling ECM
Connector Terminal Connector Terminal F39 5 F111 37 Existed
Revision: 2010 May2011 QX56

P0550 PSP SENSOREC-373
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
NO >> Repair or replace error-detected parts.
6.CHECK PSP SENSOR SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between PSP sens or harness connector and ECM harness connector.
4. Also check harness for short to ground and to power.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace error-detected parts.
7.CHECK PSP SENSOR
Refer to EC-373, "
Component Inspection (Power Steering Pressure Sensor)".
Is the inspection result normal?
YES >> GO TO 8.
NO >> Replace PSP sensor.
8.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Component Inspection (Power Steering Pressure Sensor)INFOID:0000000006217872
1.CHECK POWER STEERING PRESSURE SENSOR
1. Turn ignition switch OFF.
2. Reconnect all harness connectors disconnected.
3. Start engine and let it idle.
4. Check the voltage between ECM harness connector terminals under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace power steering pressure sensor.
+ −
Continuity
PSP sensor ECM
Connector Terminal Connector Terminal F35 2 F111 39 Existed
ECM Condition Voltage (V)
Connector +–
Te r m i n a l Te r m i n a l
F111 39 45 Steering wheel Being turned 0.5 - 4.5
Not being turned 0.4 - 0.8
Revision: 2010 May2011 QX56

P0850 PNP SWITCHEC-383
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0850 PNP SWITCH
DescriptionINFOID:0000000006217884
When the selector lever position is P or N, park/neut
ral position (PNP) signal is sent to ECM from TCM.
DTC LogicINFOID:0000000006217885
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.INSPECTION START
Will CONSULT-III be used?
Will CONSULT-III be used?
YES >> GO TO 2.
NO >> GO TO 5.
2.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 3.
3.CHECK PNP SIGNAL
WITH CONSULT-III
1. Turn ignition switch ON.
2. Select “P/N POSI SW” in “DATA MONITOR” mode wit h CONSULT-III. Then check the “P/N POSI SW” sig-
nal under the following conditions.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Go to EC-384, "
Diagnosis Procedure".
4.PERFORM DTC CONFIRMATION PROCEDURE
1. Select “DATA MONITOR” mode with CONSULT-III.
2. Start engine and warm it up to normal operating temperature.
3. Maintain the following conditions for at least 50 consecutive seconds. CAUTION:
Always drive vehicle at a safe speed.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P0850 P-N POS SW/CIRCUIT
(Park/neutral position
switch) The signal of the park/neutral position (PNP)
signal does not change during driving after the
engine is started.  Harness or connectors
[The park/neutral position (PNP) signal
circuit is open or shorted.]
TCM
Position (Selector lever) Known-good signal
N or P position ON
Except above position OFF
ENG SPEED 1,300 - 6,375 rpm
COOLAN TEMP/S More than 70 °C (158 °F)
B/FUEL SCHDL 2.0 - 31.8 msec
Revision: 2010 May2011 QX56

EC-384
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0850 PNP SWITCH
4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to
EC-384, "Diagnosis Procedure".
NO >> INSPECTION END
5.PERFORM COMPONENT FUNCTION CHECK
WITH GST
Perform Component Function Check. Refer to EC-384, "
Component Function Check".
NOTE:
Use Component Function Check to check the overall func tion of the park/neutral position (PNP) signal circuit.
During this check, a 1st trip DTC might not be confirmed.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-384, "
Diagnosis Procedure".
Component Function CheckINFOID:0000000006217886
1.PERFORM COMPONENT FUNCTION CHECK
WITH GST
1. Turn ignition switch ON.
2. Check the voltage between ECM harness connector terminals under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-384, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006217887
1.CHECK DTC WITH TCM
Refer to TM-61, "
CONSULT-III Function (TRANSMISSION)".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning part.
2.CHECK STARTING SYSTEM
Turn ignition switch OFF, then turn it to START.
Does starter motor operate?
YES >> GO TO 3.
NO >> Check DTC with BCM. Refer to BCS-57, "
DTCIndex".
3.CHECK PNP SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect A/T assembly harness connector.
3. Disconnect ECM harness connector.
4. Check the continuity between A/T assembly harness connector and ECM harness connector.
VHCL SPEED SE More than 64 km/h (40 mph)
Selector lever Suitable position
ECM
Condition Voltage (V)
Connector +–
Te r m i n a l Te r m i n a l
F111 11 175 Selector lever P or N position Battery voltage
Except above position Approx. 0
Revision: 2010 May2011 QX56
