2011 INFINITI QX56 BATTERY CONNECTORS

DAS-272
< PRECAUTION >[LDW & LDP]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint S
ystem (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000006223697
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and w hether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the “SRS AIR BAG” and “SEAT BELT” of this
Service Manual.
WARNING:
 To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision that would result in air bag inflation, all maintenance must be performed by
an authorized NISS AN/INFINITI dealer.
 Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the “SRS AIR BAG”.
 Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
 When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s)
with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly
causing serious injury.
 When using air or electric power tools or hammers , always switch the ignition OFF, disconnect the
battery, and wait at least 3 minu tes before performing any service.
Precautions For Harness RepairINFOID:0000000006223698
ITS communication uses a twisted pair line. Be careful when repairing it.
 Solder the repaired area and wrap tape around the soldered area.
NOTE:
A fray of twisted lines must be within 110 mm (4.33 in).
SKIB8766E
Revision: 2010 May2011 QX56

DAS-350
< DTC/CIRCUIT DIAGNOSIS >[LDW & LDP]
C1A05 BRAKE SW/STOP LAMP SW
YES >> GO TO 6.
NO >> Replace ICC brake switch.
6.CHECK ICC BRAKE SWITCH POWER SUPPLY CIRCUIT
1. Turn the ignition switch ON.
2. Check voltage between ICC brake switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair the harnesses or connectors.
7.CHECK HARNESS BETWEEN ICC BRAKE SWITCH AND ECM
1. Turn ignition switch OFF
2. Disconnect ECM connector.
3. Check for continuity between ICC brake s witch harness connector and ECM harness connector.
4. Check for continuity between ICC br ake switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair the harnesses or connectors.
8.PERFORM SELF-DIAGNOSIS OF ECM
1. Connect all connectors again if the connectors are disconnected.
2. Turn ignition switch ON.
3. Perform “All DTC Reading”.
4. Check if any DTC is detected in “Self Diagnostic Result” of “ENGINE”. Refer to EC-98, "
DTC Index".
Is any DTC detected?
YES >> Repair or replace the malfunctioning part s identified by the self-diagnosis result.
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
9.CHECK STOP LAMP SWITCH INSTALLATION
1. Turn ignition switch OFF.
2. Check stop lamp switch for correct installation. Refer to BR-7, "
Inspection and Adjustment".
Is the inspection result normal?
YES >> GO TO 10.
NO >> Adjust stop lamp switch installation. Refer to BR-7, "
Inspection and Adjustment".
10.STOP LAMP SWITCH INSPECTION
1. Disconnect stop lamp switch connector.
2. Check stop lamp switch. Refer to DAS-352, "
Component Inspection (Stop Lamp Switch)".
Is the inspection result normal?
YES >> GO TO 11.
Te r m i n a l s
Voltag e
(Approx.)
(+) (-)
ICC brake switch Ground
Connector Terminal
E68 1 Battery voltage
ICC brake switch ECM Continuity
Connector Terminal Connector Terminal
E68 2 E80 147 Existed
ICC brake switch GroundContinuity
Connector Terminal
E68 2 Not existed
Revision: 2010 May2011 QX56

DAS
C1A05 BRAKE SW/STOP LAMP SWDAS-351
< DTC/CIRCUIT DIAGNOSIS > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
NO >> Replace stop lamp switch.
11 .CHECK STOP LAMP SWITCH POWER SUPPLY CIRCUIT
1. Turn the ignition switch ON.
2. Check voltage between stop lamp switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 12.
NO >> Repair the harnesses or connectors.
12.CHECK HARNESS BETWEEN ST OP LAMP SWITCH AND ECM
1. Turn ignition switch OFF
2. Disconnect ECM, rear combination lamp and high-mounted stop lamp connectors.
3. Check for continuity between stop lamp sw itch harness connector and ECM harness connector.
4. Check for continuity between stop lamp switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 13.
NO >> Repair the harnesses or connectors.
13.CHECK HARNESS BETWEEN STOP LAMP SWITCH AND ABS ACTUATOR AND ELECTRIC UNIT
(CONTROL UNIT)
1. Disconnect ABS actuator and electric unit (control unit) connector.
2. Check for continuity between stop lamp switch harness connector and ABS actuator and electric unit
(control unit) harness connector.
3. Check for continuity between stop lamp switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 14.
NO >> Repair the harnesses or connectors.
Te r m i n a l s Vo l ta g e
(Approx.)
(+) (-)
Stop lamp switch
Ground
Connector Terminal
E115 1
Battery voltage
3
Stop lamp switch ECM Continuity
Connector Terminal Connector Terminal
E115 2 E80 158 Existed
Stop lamp switch GroundContinuity
Connector Terminal
E115 2 Not existed
Stop lamp switch ABS actuator and electric
unit (control unit) Continuity
Connector Terminal Connector Terminal
E115 4 E36 17 Existed
Stop lamp switch GroundContinuity
Connector Terminal
E115 4 Not existed
Revision: 2010 May2011 QX56

DAS
WARNING SYSTEMS ON INDICATOR CIRCUITDAS-391
< DTC/CIRCUIT DIAGNOSIS > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
WARNING SYSTEMS ON INDICATOR CIRCUIT
Component Function CheckINFOID:0000000006223828
1.CHECK WARNING SYSTEMS ON INDICATOR
1. Turn the ignition switch ON.
2. Select the active test item “WARNING SY STEM IND” of “ICC/ADAS” with CONSULT-III.
3. With operating the test item, check the operation.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Refer to DAS-391, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006223829
1.CHECK WARNING ON INDICATOR POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect twin switch connector.
3. Turn ignition switch ON.
4. Check voltage between twin switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the warning systems ON indicator power supply circuit.
2.CHECK WARNING SYSTEMS ON INDICATOR SIGNAL FOR OPEN
1. Turn ignition switch OFF.
2. Disconnect the ADAS control unit harness connector.
3. Check continuity between the ADAS control uni t harness connector and twin switch harness connector.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair the harnesses or connectors.
3.CHECK WARNING SYSTEMS ON INDI CATOR SIGNAL CIRCUIT FOR SHORT
Check continuity between the ADAS control unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4. On : Warning systems ON indicator illuminates
Off : Warning systems ON in
dicator is turned OFF
Te r m i n a l s
Vo l ta g e
(Approx.)
(+) (
−)
Twin switch Ground
Connector Terminal
M127 8 Battery voltage
ADAS control unit Twin switch Continuity
Connector Terminal Connector Terminal
B61 4 M127 9 Existed
ADAS control unit
GroundContinuity
Connector Terminal
B61 4 Not existed
Revision: 2010 May2011 QX56

DAS-392
< DTC/CIRCUIT DIAGNOSIS >[LDW & LDP]
WARNING SYSTEMS ON
INDICATOR CIRCUIT
NO >> Repair the harnesses or connectors.
4.CHECK WARNING SYSTEMS ON INDICATOR
Check the warning systems ON indicator. Refer to DAS-392, "
Component Inspection".
Is the inspection result normal?
YES >> Replace the ADAS control unit. Refer to DAS-63, "Removal and Installation".
NO >> Replace warning systems switch. DAS-404, "
Removal and Installation".
Component InspectionINFOID:0000000006223830
1.CHECK WARNING SYSTEMS ON INDICATOR
Apply battery voltage to warning systems switch termi nals 8 and 9, and then check if the warning systems ON
indicator illuminates.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace the warning systems switch. Refer to DAS-404, "
Removal and Installation".
Te r m i n a l s
ConditionDriver warning
systems ON in-
dicator
(+) (-)
89 When the battery voltage is applied On
When the battery voltage is not applied Off
Revision: 2010 May2011 QX56

DAS
WARNING BUZZER CIRCUITDAS-393
< DTC/CIRCUIT DIAGNOSIS > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
WARNING BUZZER CIRCUIT
Component Function CheckINFOID:0000000006223831
1.CHECK WARNING BUZZER
1. Turn the ignition switch ON.
2. Select the active test item “LDP BU ZZER” of “ICC/ADAS” with CONSULT-III.
3. With operating the test item, check the operation.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Refer to DAS-393, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006223832
1.CHECK WARNING BUZZER POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect the warning buzzer connector.
3. Turn ignition switch ON.
4. Check voltage between the warning buzzer harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the warning buzzer power supply circuit.
2.CHECK WARNING BUZZER GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between the warning buzzer harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair the harnesses or connectors.
3.CHECK WARNING BUZZER SIGNAL CIRCUIT FOR OPEN
1. Disconnect the ADAS control unit connector.
2. Check continuity between the ADAS control uni t harness connector and warning buzzer harness connec-
tor.
Is the inspection result normal?
On : Warning buzzer is activated.
Off : Warning buzzer is not activated.
Te r m i n a l s Vo l ta g e
(Approx.)
(+) (
−)
Warning buzzer Ground
Connector Terminal
M94 1 Battery voltage
Warning buzzer GroundContinuity
Connector Terminal
M94 3 Existed
ADAS control unit Warning buzzer Continuity
Connector Terminal Connector Terminal
B61 12 M94 2 Existed
Revision: 2010 May2011 QX56

DAS
PRECAUTIONSDAS-407
< PRECAUTION > [BSW]
C
D
E
F
G H
I
J
K L
M B
N P A
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000006223847
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the “SRS AIR BAG” and “SEAT BELT” of this
Service Manual.
WARNING:
 To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision that would result in air ba g inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
 Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the “SRS AIR BAG”.
 Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
 When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the
ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s)
with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly
causing serious injury.
 When using air or electric power tools or hammers , always switch the ignition OFF, disconnect the
battery, and wait at least 3 minutes before performing any service.
Precaution for BSW System ServiceINFOID:0000000006223848
WARNING:
Be careful of traffic conditions and safety aro und the vehicle when performing road test.
CAUTION:
 Never perform the active test while driving.
 Never change BSW initial state ON ⇒ OFF without the consent of the customer.
TO KEEP THE BSW SYSTEM OPERATING PROPERLY, BE SURE TO OBSERVE THE FOLLOW-
ING ITEMS:
System Maintenance
The two side radar for the BSW system are located near the rear bumper.
 Always keep the area near the side radar clean.
 Do not attach stickers (including transparent material ), install accessories or apply additional paint near the
side radar.
 Do not strike or damage the area around the side radar.
Revision: 2010 May2011 QX56

DAS-512
< DTC/CIRCUIT DIAGNOSIS >[BSW]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
ADAS CONTROL UNIT
ADAS CONTROL UNIT : Diagnosis ProcedureINFOID:0000000006223967
1.CHECK ADAS CONTROL UNIT POWER SUPPLY CIRCUIT
Check voltage between ADAS control unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the ADAS control unit power supply circuit.
2.CHECK ADAS CONTROL UNIT GROUND CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect the ADAS control unit connector.
3. Check for continuity between ADAS control unit harness connector and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Repair the ADAS control unit ground circuit.
SIDE RADAR LH
SIDE RADAR LH : Diagnosis ProcedureINFOID:0000000006223968
1.CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect the side radar LH connector.
3. Check voltage between side radar LH harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the side radar LH power supply circuit.
2.CHECK GROUND CIRCUIT
Check continuity between side radar LH harness connectors and ground.
Te r m i n a l Condition
Voltag e
(Approx.)
(+) (–)
ADAS control unit
GroundIgnition
switch
Connector Terminal
B61 16 OFF 0 V
ON Battery volt-
age
ADAS control unit
GroundContinuity
Connector Terminal
B61 6 Existed
Te r m i n a l s Condition
Vo l ta g e
(Approx.)
(+) (
−)
Side radar LH
GroundIgnition switch
Connector Terminal
B74 5 OFF 0 V
ON Battery voltage
Revision: 2010 May2011 QX56
