2011 INFINITI QX56 BATTERY CONNECTORS

EC-188
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P006A, P0101 MAF SENSOR
CAUTION:
Always drive at a safe speed.
3. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-188, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006288270
1.CHECK INTAKE SYSTEM
Check the following for connection.
 Air duct
 Vacuum hoses
 Intake air passage between air duct and intake manifold
Is the inspection result normal?
YES >> GO TO 2.
NO >> Reconnect the parts.
2.CHECK MASS AIR FLOW SENS OR POWER SUPPLY CIRCUIT
1. Disconnect mass air flow sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between mass air flow sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.DETECT MALFUNCTIONING PART
Check the following.
 Harness for open or short between mass air flow sensor and ECM
 Harness for open or short between mass air flow sensor and IPDM E/R
 Loose or poor connection for each connector and harness
>> Repair open circuit, short to ground or short to power in harness or connectors.
4.CHECK MASS AIR FLOW SENSOR GR OUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between mass air flow sensor harness connector and ECM harness connector.
4. Also check harness for short to ground and short to power.
Accelerator pedal position sensor 1 Ground Voltage (V)
Connector Terminal
E110 (Whthout ICC) 3 Ground 1.4 – 2.0
E67 (With ICC) 10
Mass air flow sensor Ground Voltage
Connector Terminal
F31 5 Ground Battery volt-
age
Mass air flow sensor ECM Continu-
ity
Connec-
tor Te r m i n a l Connec-
tor Te r m i n a l
F 3 1 4 F 111 2 5 E x i s t e d
Revision: 2010 May2011 QX56

P0075, P0081 IVT CONTROL SOLENOID VALVE
EC-193
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0075, P0081 IVT CONTRO
L SOLENOID VALVE
DTC LogicINFOID:0000000006217781
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for 5 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-193, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217782
1.CHECK INTAKE VALVE TIMING CONTROL SO LENOID VALVE POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect intake valve timing (IVT) control solenoid valve harness connector.
3. Turn ignition switch ON.
4. Check the voltage between IVT control solenoid valve harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.DETECT MALFUNCTIONING PART
Check the following.
 Harness for open or short between IVT control solenoid valve and IPDM E/R
 Loose or poor connection for each connector and harness
>> Repair open circuit, short to ground or short to power in harness or connectors.
3.CHECK IVT CONTROL SOLENOID VALVE OUTP UT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P0075 INT/V TIM V/CIR-B1
[Intake valve timing control sole-
noid valve (bank 1) circuit]
An improper voltage is sent to the ECM
through intake valve timing control solenoid
valve.  Harness or connectors
(Intake valve timing control solenoid
valve circuit is open or shorted.)
 Intake valve timing control solenoid valve
P0081 INT/V TIM V/CIR-B2
[Intake valve timing control sole-
noid valve (bank 2) circuit]
DTC
IVT control solenoid valve
Ground Voltage
Bank Connector Terminal
P0075 1 F47 2 Ground Battery voltage
P0081 2 F61 2
Revision: 2010 May2011 QX56

P0087, P0088, P0090 FRP CONTROL SYSTEM
EC-195
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0087, P0088, P0090 FRP CONTROL SYSTEM
DTC LogicINFOID:0000000006217784
DTC DETECTION LOGIC
NOTE:

If DTC P0087 or P0090 is displayed with DTC P1197, first perform the trouble diagnosis for DTC
P1197.
 DTC P0087 or P0090 may be displayed when running out of gas.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE-I
1. Check that the fuel tank is 1/8 full of fuel.
2. Warm up the engine to the normal operating temperature and keep the engine speed at idle for 60 sec- onds.
NOTE:
Warm up the engine until “COOLAN TEMP/S” on “DATA MONITOR” of CONSULT-III reaches at least
70 °C (158 °F).
3. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-196, "Diagnosis Procedure".
NO >> GO TO 3.
3.PERFORM DTC CONFIRMATION PROCEDURE-II
1. Cool the engine until the engine coolant temperature reaches 60 °C (140 °F) or less.
2. Start the engine and wait at least 60 seconds.
3. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-196, "Diagnosis Procedure".
NO >> INSPECTION END
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0087 High fuel pressure too low The following condition continues for 5
seconds or more after engine start (re-
gardless of water temperature): Target
fuel pressure
− Actual fuel pressure ≥
2.7 MPa (27 bar, 27.5 kg/cm
2, 392 psi)
 Harness or connectors(The fuel pump circuit is open or shorted.)
 Fuel system
P0088 high fuel pressure too high The following condition continues for 5
seconds or more after engine start (re-
gardless of water temperature):Actual
fuel pressure
− Target fuel pressure ≥
2.7 MPa (27 bar, 27.5 kg/cm
2, 392 psi)
P0090 High pressure fuel pump per-
formance Fuel rail pressure remains at 1.5 MPa
(15 bar, 15.3 kg/ cm
2, 217.5 psi) or less
for 3 seconds or more during engine rev.
Revision: 2010 May2011 QX56

EC-198
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P008A LOW FUEL PRESSURE CONTROL SYSTEM
P008A LOW FUEL PRESSURE CONTROL SYSTEM
DTC LogicINFOID:0000000006217787
DTC DETECTION LOGIC
NOTE:
If DTC P008A is displayed with DTC P1197, first pe
rform the trouble diagnosis for DTC P1197. Refer to
EC-397, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Check that the fuel tank is 1/8 full of fuel.
2. Start the engine and warm it up to the normal operating temperature. NOTE:
When replacing ECM, warm up the engine until “C OOLAN TEMP/S” on “DATA MONITOR” of CONSULT-
III reaches at least 70 °C (158 °F).
3. Let the engine at idle for 60 seconds.
4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-398, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217788
1.PERFORM LOW PRESSURE FUEL PUMP COMPONENT FUNCTION CHECK
Refer to EC-512, "
Component Function Check".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform low pressure fuel pump diagnosis. Refer to EC-512, "
Diagnosis Procedure".
2.CHECK FUEL LEAKAGE
1. Start the engine.
2. Visually check that the low fuel pressure system has no fuel leakage.
Is inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace error-detected parts.
3.CHECK LOW PRESSURE FUEL PIPING AND HOSE
1. Turn ignition switch OFF.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P008A Low fuel pressure too low A condition of low fuel pressure 0.23
MPa (2.3 bar, 2.346 kg/cm
2, 33.35 psi)
or less continues for 5 seconds or more
after warming up the engine.  Harness or connectors
(The low pressure fuel pump circuit is
open or shorted.)
 Low pressure fuel pump
 Fuel pressure regulator
 Low pressure fuel system
 Out of gas
Revision: 2010 May2011 QX56

EC-200
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P008B LOW FUEL PRESSURE CONTROL SYSTEM
P008B LOW FUEL PRESSURE CONTROL SYSTEM
DTC LogicINFOID:0000000006288272
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine and keep the engine speed at idle for 60 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-200, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006288273
1.CHECK FUEL PUMP CONTROL MODULE (FPCM) SIGNAL
Refer to EC-405, "
Component Inspection (FPCM)".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace FPCM. Refer to EC-537, "
Removal and Installation".
2.CHECK FUEL PUMP CONTROL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect FPCM harness connector and fuel level sensor unit and fuel pump harness connector.
3. Check the continuity between FPCM harness connecto r and fuel level sensor unit and fuel pump harness
connector.
4. Also check harness for short to ground and short to power.
Is inspection result normal?
YES >> Replace fuel level sensor unit and fuel pump (fuel pressure regulator malfunction). Refer to FL-5,
"Removal and Installation".
NO >> Repair or replace error-detected parts.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P008B Low fuel pressure too high A condition of low fuel pressure 0.67
MPa (6.7 bar, 6.834 kg/cm
2, 97.15 psi)
or more continues for 5 seconds or
more after warming up the engine.  Harness or connectors
(The low pressure fuel pump circuit is
open or shorted.)
 Fuel pressure regulator
FPCM Fuel level sensor unit and fuel pump Continuity
Connector Terminal Connector Terminal
B41 6
C5 3
Existed
71
Revision: 2010 May2011 QX56

EC-202
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0102, P0103 MAF SENSOR
 Air duct
 Vacuum hoses
 Intake air passage between air duct to intake manifold
Is the inspection result normal?
YES >> GO TO 3.
NO >> Reconnect the parts.
3.CHECK MAF SENSOR POWER SUPPLY CIRCUIT
1. Disconnect mass air flow (MAF) sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between MAF sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 4.
4.DETECT MALFUNCTIONING PART
Check the following.
 Harness for open or short between mass air flow sensor and ECM
 Harness for open or short between mass air flow sensor and IPDM E/R
 Loose or poor connection for each connector and harness
>> Repair open circuit, short to ground or short to power in harness or connectors.
5.CHECK MAF SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between MAF sens or harness connector and ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
6.CHECK MAF SENSOR INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between MAF sens or harness connector and ECM harness connector.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
7.CHECK MASS AIR FLOW SENSOR
Refer to EC-203, "
Component Inspection (MAF Sensor)".
Is the inspection result normal?
MAF sensor Ground Voltage
Connector Terminal
F31 5 Ground Battery voltage
MAF sensor ECM Continuity
Connector Terminal Connector Terminal
F 3 1 4 F 111 2 5 E x i s t e d
MAF sensor ECM Continuity
Connector Terminal Connector Terminal
F 3 1 3 F 111 2 2 E x i s t e d
Revision: 2010 May2011 QX56

P0122, P0123 TP SENSOREC-219
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0122, P0123 TP SENSOR
DTC LogicINFOID:0000000006217801
DTC DETECTION LOGIC
NOTE:
If DTC P0122 or P0123 is displayed with DTC P
0643, perform the trouble diagnosis for DTC P0643.
Refer to EC-381, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conduc ted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
TESTING CONDITION:
Before performing the following procedure, confi rm that battery voltage is 8 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for 1 second.
2. Check DTC.
Is DTC detected?
YES >> Go to EC-219, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217802
1.CHECK THROTTLE POSITION SEN SOR 2 POWER SUPPLY CIRCUIT
1. Disconnect electric throttle c ontrol actuator harness connector.
2. Turn ignition switch ON.
3. Check the voltage between electric throttle control actuator harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
2.CHECK THROTTLE POSITI ON SENSOR 2 GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between electric throttle control actuator harness connector and ECM harness con-
nector.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P0122 TP SEN 2/CIRC-B1
(Throttle position sensor 2
circuit low input) An excessively low voltage from the TP
sensor 2 is sent to ECM.
 Harness or connectors
(TP sensor 2 circuit is open or shorted.)
 Electric throttle control actuator (TP sensor 2)
P0123 TP SEN 2/CIRC-B1
(Throttle position sensor 2
circuit high input) An excessively high voltage from the TP
sensor 2 is sent to ECM.
Electric throttle control actuator
Ground Voltage
Connector Terminal
F66 2 Ground Approx. 5 V
Revision: 2010 May2011 QX56

EC-228
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0130, P0150 A/F SENSOR 1
P0130, P0150 A/F SENSOR 1
DTC LogicINFOID:0000000006217804
DTC DETECTION LOGIC
To judge malfunctions, the diagnosis checks that the A/
F signal computed by ECM from the A/F sensor 1 sig-
nal fluctuates according to fuel feedback control.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE FOR MALFUNCTION A
1. Start engine and warm it up to normal operating temperature.
2. Let engine idle for 2 minutes.
3. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-230, "Diagnosis Procedure".
NO-1 >> With CONSULT-III: GO TO 3.
NO-2 >> With GST: GO TO 7.
3.CHECK AIR FUEL RATIO (A/F) SENSOR 1 FUNCTION
WITH CONSULT-III
1. Start engine and warm it up to normal operating temperature.
2. Select “A/F SEN1 (B1)” or “A/F SEN1 (B 2)” in “DATA MONITOR” mode with CONSULT-III.
3. Check “A/F SEN1 (B1)” or “A/F SEN1 (B2)” indication.
Does the indication fluctuate around 1.5 V?
YES >> GO TO 4.
NO >> Go to EC-230, "
Diagnosis Procedure".
4.PERFORM DTC CONFIRMATION PR OCEDURE FOR MALFUNCTION B-I
1. Select “A/F SEN1 (B1) P1276” (for DTC P0130) or “A/F SEN1 (B2) P1286” (for DTC P0150) of “A/F
SEN1” in “DTC WORK SUPPORT” mode with CONSULT-III.
2. Touch “START”.
3. When the following conditions are met, “T ESTING” will be displayed on the CONSULT-III screen.
DTC No.Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible Cause
P0130 A/F SENSOR1 (B1)
[Air fuel ratio (A/F) sensor 1
(bank 1) circuit] A)
The A/F signal computed by ECM from the A/F
sensor 1 signal is constantly in a range other
than approx. 1.5 V.
 Harness or connectors(The A/F sensor 1 circuit is open
or shorted.)
 A/F sensor 1
B)
The A/F signal computed by ECM from the A/F
sensor 1 signal is constantly approx. 1.5 V.
P0150 A/F SENSOR1 (B2)
[Air fuel ratio (A/F) sensor 1
(bank 2) circuit] A)
The A/F signal computed by ECM from the A/F
sensor 1 signal is constantly in a range other
than approx. 1.5 V.
B) The A/F signal computed by ECM from the A/F
sensor 1 signal is constantly approx. 1.5 V.
Revision: 2010 May2011 QX56
