B2555 STOP LAMPSEC-75
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace stop lamp switch. Refer to BR-20, "
Removal and Installation".
Stop lamp switch
Condition Continuity
Terminal
1 2 Brake pedal Not depressed Not existed
Depressed Existed
Revision: 2010 May2011 QX56

SEC-76
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2556 PUSH-BUTTON IGNITION SWITCH
B2556 PUSH-BUTTON IGNITION SWITCH
DTC LogicINFOID:0000000006226225
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Press push-button ignition switch under the following condition.
- Brake pedal: Not depressed
2. Release push-button ignition switch and wait 100 seconds or more.
3. Check DTC in “Self Diagnostic Result” mode of “BCM” using CONSULT-III.
Is DTC detected?
YES >> Go to SEC-76, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226226
1.CHECK PUSH-BUTTON IGNITION SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect push-button ignition switch connector.
3. Check voltage between push-button ignition switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK PUSH-BUTTON IGNITION SWITCH CIRCUIT
1. Disconnect BCM connector and IPDM E/R connector.
2. Check continuity between push-button ignition switch harness connector and BCM harness connector.
3. Check continuity between push-button ignition switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause B2556 PUSH-BTN IGN SW BCM detects the push-button ignition switch
stuck at ON for 100 seconds or more.  Harness or connectors
(Push-button ignition switch circuit is
shorted.)
 Push-button ignition switch
BCM
(+)
(–)Voltage (V)
(Approx.)
Push-button ignition switch
Connector Terminal M101 4 Ground 12
Push-button ignition switch BCM Continuity
Connector Terminal Connector Terminal
M101 4 M71 100 Existed
Push-button ignition switch GroundContinuity
Connector Terminal
M101 4 Not existed
Revision: 2010 May2011 QX56

B2556 PUSH-BUTTON IGNITION SWITCHSEC-77
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
3.REPLACE BCM
1. Replace BCM. Refer to BCS-81, "
Removal and Installation".
2. Perform initialization of BCM and registration of all Intelligent Keys using CONSULT-III.
For initialization and registration procedures, refer to CONSULT-III Operation Manual NATS-IVIS/NVIS.
>> INSPECTION END
4.CHECK PUSH-BUTTON IGNITION SWITCH GROUND CIRCUIT
Check continuity between push-button i gnition switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace harness.
5.CHECK PUSH-BUTTON IGNITION SWITCH
Refer to SEC-77, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace push-button ignition switch. Refer to SEC-156, "
Removal and Installation".
6.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000006226227
1.CHECK PUSH-BUTTON IGNITION SWITCH
1. Turn ignition switch OFF.
2. Disconnect push-button ignition switch connector.
3. Check continuity between push-button ignition switch terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace push-button ignition switch. Refer to SEC-156, "
Removal and Installation".
Push-button ignition switch
GroundContinuity
Connector Terminal
M101 1 Existed
Push-button ignition switch Condition Continuity
Terminal
14 Push-button ignition
switchPressed Existed
Not pressed Not existed
Revision: 2010 May2011 QX56

SEC-78
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2557 VEHICLE SPEED
B2557 VEHICLE SPEED
DTC LogicINFOID:0000000006226228
DTC DETECTION LOGIC
NOTE:
 If DTC B2557 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-70, "
DTC Logic".
 If DTC B2557 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to BCS-71, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and wait 10 seconds or more.
2. Drive the vehicle at a vehicle speed of 10 km/h (6.2 MPH) or more for 10 seconds or more.
3. Check DTC in “Self Diagnostic Result” mode of “BCM” using CONSULT-III.
Is DTC detected?
YES >> Go to SEC-78, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226229
1.CHECK DTC OF “ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)”
Check DTC in “Self Diagnostic Result ” mode of “ABS” using CONSULT-III.
Is DTC detected?
YES >> Perform the trouble diagnosis relat ed to the detected DTC. Refer to BRC-51, "DTC Index".
NO >> GO TO 2.
2.CHECK DTC OF “COMBINATION METER”
Check DTC in “Self Diagnostic Result” m ode of “METER/M&A” using CONSULT-III.
Is DTC detected?
YES >> Perform the trouble diagnosis relat ed to the detected DTC. Refer to MWI-43, "DTC Index".
NO >> GO TO 3.
3.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
DTC No. Trouble diagnosis name DTC detecting condition Possible causes
B2557 VEHICLE SPEED BCM detects one of the following conditions for 10
seconds continuously.
 Vehicle speed signal from combination meter is 10
km/h (6.2 MPH) or more, and vehicle speed signal
from ABS actuator and electric unit (control unit) is
4 km/h (2.5 MPH) or less.
 Vehicle speed signal from combination meter is 4 km/h (2.5 MPH) or less, and vehicle speed signal
from ABS actuator and electric unit (control unit) is
10 km/h (6.2 MPH) or more.  Harness or connectors
(The CAN communication line is
open or shorted.)
 Combination meter
 ABS actuator and electric unit
(control unit)
Revision: 2010 May2011 QX56

B2601 SHIFT POSITIONSEC-79
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B2601 SHIFT POSITION
DTC LogicINFOID:0000000006226230
DTC DETECTION LOGIC
NOTE:
 If DTC B2601 is displayed with DTC U1000, first per form the trouble diagnosis for DTC U1000. Refer to
BCS-70, "
DTC Logic".
 If DTC B2601 is displayed with DTC U1010, first per form the trouble diagnosis for DTC U1010. Refer to
BCS-71, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Shift the selector lever to the P position.
2. Turn ignition switch ON and wait 2 seconds or more.
3. Shift the selector lever to any position other than P, and wait 2 seconds or more.
4. Check DTC in “Self Diagnostic Result” mode of “BCM” using CONSULT-III.
Is DTC detected?
YES >> Go to SEC-79, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226231
1.CHECK A/T SHIFT SELECTOR POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect A/T shift selector (detention switch) connector.
3. Check voltage between A/T shift selector (detention switch) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK A/T SHIFT SELECTOR POWER SUPPLY CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between A/T shift selector ( detention switch) harness connector and BCM harness con-
nector.
3. Check continuity between A/T shift select or (detention switch) harness connector and ground.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B2601 SHIFT POSITION When there is a difference between P range
signal from A/T shift selector (detention switch)
and P position signal from IPDM E/R (CAN).  Harness or connectors
(CAN communication line is open or
shorted.)
 Harness or connectors [A/T shift selector (detention switch)
circuit is open or shorted.]
 A/T shift selector (detention switch)
BCM
(+)
(–)Voltage (V)
(Approx.)
A/T shift selector (detention switch)
Connector Terminal M57 13 Ground 12
A/T shift selector (detention switch) BCM Continuity
Connector Terminal Connector Terminal
M57 13 M71 104 Existed
Revision: 2010 May2011 QX56

SEC-80
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2601 SHIFT POSITION
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.REPLACE BCM
1. Replace BCM. Refer to BCS-81, "
Removal and Installation".
2. Perform initialization of BCM and registration of all Intelligent Keys using CONSULT-III.
For initialization and registration procedures, refer to CONSULT-III Operation Manual NATS-IVIS/NVIS.
>> INSPECTION END
4.CHECK A/T SHIFT SELECTOR CIRCUIT (BCM)
1. Disconnect BCM connector and IPDM E/R connector.
2. Check continuity between A/T shift selector ( detention switch) harness connector and BCM harness con-
nector.
3. Check continuity between A/T shift select or (detention switch) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace harness.
5.CHECK A/T SHIFT SELECT OR CIRCUIT (IPDM E/R)
Check continuity between A/T shift selector (detent ion switch) harness connector and IPDM E/R harness con-
nector.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace harness.
6.CHECK A/T SHIFT SELECTOR (DETENTION SWITCH)
Refer to SEC-81, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 7.
NO >> Replace A/T shift selector. Refer to TM-176, "
Removal and Installation".
7.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
A/T shift selector (detention switch) GroundContinuity
Connector Terminal
M57 13 Not existed
A/T shift selector (detention switch) BCM Continuity
Connector Terminal Connector Terminal
M5714M6837Existed
A/T shift selector (detention switch) GroundContinuity
Connector Terminal
M57 14 Not existed
A/T shift selector (detention switch) IPDM E/R Continuity
Connector Terminal Connector Terminal
M57 14 E17 64 Existed
Revision: 2010 May2011 QX56

B2601 SHIFT POSITIONSEC-81
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
Component InspectionINFOID:0000000006226232
1.CHECK A/T SHIFT SELECTOR (DETENTION SWITCH)
1. Turn ignition switch OFF.
2. Disconnect A/T shift selector connector.
3. Check continuity between A/T shift selector (detention switch) terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace A/T shift selector. Refer to TM-176, "
Removal and Installation".
A/T shift selector (detention switch)
Condition Continuity
Te r m i n a l
13 14 Selector lever P position Not existed
Other than above Existed
Revision: 2010 May2011 QX56

SEC-82
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2602 SHIFT POSITION
B2602 SHIFT POSITION
DTC LogicINFOID:0000000006226233
DTC DETECTION LOGIC
NOTE:
 If DTC B2602 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-70, "
DTC Logic".
 If DTC B2602 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to BCS-71, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine.
2. Drive vehicle at a speed of 4 km/h (2.5 MPH) or more for 10 seconds or more.
3. Check DTC in “Self Diagnostic Result” mode of “BCM” using CONSULT-III.
Is DTC detected?
YES >> Go to SEC-82, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226234
1.CHECK DTC OF COMBINATION METER
Check DTC in “Self Diagnostic Result” m ode of “METER/M&A” using CONSULT-III.
Is DTC detected?
YES >> Perform the trouble diagnosis relat ed to the detected DTC. Refer to MWI-43, "DTC Index".
NO >> GO TO 2.
2.CHECK A/T SHIFT SELECTOR POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect A/T shift selector (detention switch) connector.
3. Check voltage between A/T shift selector (detention switch) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 3.
3.CHECK A/T SHIFT SELECTOR POWER SUPPLY CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between A/T shift selector ( detention switch) harness connector and BCM harness con-
nector.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B2602 SHIFT POSITION BCM detects the following status for 10 seconds.
 Selector lever is in the P position
 Vehicle speed is 4 km/h (2.5 MPH) or more
 Ignition switch is in the ON position  Harness or connectors
(CAN communication line is open or
shorted.)
 Harness or connectors [A/T shift selector (detention switch)
circuit is open or shorted.]
 A/T shift selector (detention switch)
 Combination meter
BCM
(+)
(–)Voltage (V)
(Approx.)
A/T shift selector (detention switch)
Connector Terminal M57 13Ground12
Revision: 2010 May2011 QX56
