B2198 NATS ANTENNA AMP.SEC-67
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
YES >> GO TO 7.
NO >> Replace NATS antenna amp. Refer to SEC-155, "
Removal and Installation".
7.CHECK NATS ANTENNA AMP. OUTPUT SIGNAL 2
1. Disconnect BCM connector.
2. Check voltage between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 9.
NO >> GO TO 8.
8.CHECK NATS ANTENNA AMP. OUTPUT SIGNAL CIRCUIT 2
1. Disconnect NATS antenna amp. connector.
2. Check continuity between BCM harness connector and NATS antenna amp. connector.
3. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> Replace NATS antenna amp. Refer to SEC-155, "Removal and Installation".
NO >> Repair or replace harness.
9.CHECK NATS ANTENNA AMP. COMMUNICATION SIGNAL 2
1. Connect BCM connector.
2. Check voltage between BCM harness connector and ground using analog tester.
Is the inspection result normal?
YES >> GO TO 10.
NO >> Replace NATS antenna amp. Refer to SEC-155, "
Removal and Installation".
10.CHECK NATS ANTENNA AMP. GROUND CIRCUIT
1. Disconnect NATS antenna amp. connector.
2. Check continuity between NATS antenna amp. harness connector and ground.
Is the inspection result normal?
(+)
(–)Voltage (V)
(Approx.)
BCM
Connector Terminal M68 25 Ground 12
BCM NATS antenna amp. Continuity
Connector Terminal Connector Terminal
M68 25 M26 3 Existed
BCM GroundContinuity
Connector Terminal
M68 25 Not existed
(+) (–) Condition Voltage (V)
(Approx.)
BCM
Connector Terminal
M68 25 Ground Contact Intelligent Key backside to
push-button ignition switch, then turn
ignition switch ON.Just after pressing push-button ignition
switch, pointer of analog tester should
move.
NATS antenna amp.
GroundContinuity
Connector Terminal
M26 4 Existed
Revision: 2010 May2011 QX56

SEC-68
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2198 NATS ANTENNA AMP.
YES >> GO TO 11.
NO >> Repair or replace harness.
11 .CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Revision: 2010 May2011 QX56

B2013 STEERING LOCK UNITSEC-69
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B2013 STEERING LOCK UNIT
DTC LogicINFOID:0000000006226218
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Lock the steering. NOTE:
3. Press the push-button ignition switch.
4. Check DTC in “Self Diagnostic Result” mode of “BCM” using CONSULT-III.
Is DTC detected?
YES >> Go to SEC-69, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226219
1.PERFORM INITIALIZATION
Perform initialization of BCM and reregistration of all Intelligent Keys using CONSULT-III.
For initialization and registration procedures, refer to CONSULT-III Operation Manual NATS-IVIS/NVIS.
Does steering lock operate?
YES >> INSPECTION END
NO >> GO TO 2.
2.REPLACE STEERING LOCK UNIT
1. Replace steering lock unit.
2. Perform the service procedure for steering lock unit replacement. Refer to CONSULT-III Operation Man-
ual NATS-IVIS/NVIS.
>> INSPECTION END
DTC No. Trouble diagnosis name DTC detecting condition Possible causeB2013 ID DISCORD BCM-S/L The ID verification results between BCM and
steering lock unit are NG. Steering lock unit
To lock the steering1. Set the selector lever in the P position.
2. Turn the power supply position to the OFF position.
3. Press any door switch.
To unlock the steering 1. Set the selector lever in the P position.
2. Press the push-button ignition switch with brake pedal not depressed.
Revision: 2010 May2011 QX56

SEC-70
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2014 CHAIN OF STRG-IMMU
B2014 CHAIN OF STRG-IMMU
DTC LogicINFOID:0000000006226220
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Lock steering. NOTE:
3. Press the push-button ignition switch.
4. Check DTC in “Self Diagnostic Result” mode of “BCM” using CONSULT-III.
Is DTC detected?
YES >> Go to SEC-70, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226221
1.CHECK STEERING LOCK UNIT POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect steering lock unit connector.
3. Check voltage between steering lock unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK STEERING LOCK UNIT POWER SUPPLY CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between steering lock unit harness connector and BCM harness connector.
3. Check continuity between steering lock unit harness connector and ground.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B2014 CHAIN OF S/L-BCM Inactive communication between steering
lock unit and BCM  Harness or connectors
(Steering lock unit circuit is open or
shorted.)
 Steering lock unit
BCM
To lock the steering 1. Set the selector lever in the P position.
2. Turn the power supply position to the OFF position.
3. Press any door switch.
To unlock the steering 1. Set the selector lever in the P position.
2. Press the push-button ignition switch with brake pedal not depressed.
(+)
(–) Condition Voltage (V)
(Approx.)
Steering lock unit
Connector Terminal
M12 7 Ground Ignition switch OFF or ACC 12
ON 0
Steering lock unit BCM Continuity
Connector Terminal Connector Terminal
M12 7 M71 95 Existed
Revision: 2010 May2011 QX56

B2014 CHAIN OF STRG-IMMUSEC-71
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace harness.
3.CHECK STEERING LOCK UNIT GROUND CIRCUIT
Check continuity between steering lock unit and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
4.CHECK STEERING LOCK UNI T COMMUNICATION SIGNAL
1. Connect steering lock unit connector and BCM connector.
2. Read voltage signal between steering lock unit harness connector and ground.
NOTE:
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 6.
5.REPLACE STEERING LOCK UNIT
1. Replace steering lock unit.
2. Perform the service procedure for steering lock unit replacement. Refer to CONSULT-III Operation Man-
ual NATS-IVIS/NVIS.
Steering lock unit
GroundContinuity
Connector Terminal
M12 7 Not existed
Steering lock unit
GroundContinuity
Connector Terminal
M12 5
Existed
6
(+)
(–) Condition Voltage (V)
(Approx.)
Steering lock unit
Connector Terminal
M12 2 Ground Steering lock unit Lock status 12
Lock or unlock
For 15 seconds after
unlock
12
15 seconds or later
after unlock. 0
To lock the steering 1. Set the selector lever in the P position.
2. Turn the power supply position to the OFF position.
3. Press any door switch.
To unlock the steering 1. Set the selector lever in the P position.
2. Press the push-button ignition switch with brake pedal not depressed.
JMKIA0066GB
Revision: 2010 May2011 QX56

SEC-72
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2014 CHAIN OF STRG-IMMU
>> INSPECTION END
6.CHECK STEERING LOCK UNI
T COMMUNICATION CIRCUIT
1. Disconnect steering lock unit and BCM connector.
2. Check continuity between steering lock unit harness connector and BCM harness connector.
3. Check continuity between steering lock unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace harness.
7.REPLACE BCM
1. Replace BCM. Refer to BCS-81, "
Removal and Installation".
2. Perform initialization of BCM and registration of all Intelligent Keys using CONSULT-III.
For initialization and registration procedures, refer to CONSULT-III Operation Manual NATS-IVIS/NVIS.
>> INSPECTION END
Steering lock unit BCM Continuity
Connector Terminal Connector Terminal
M12 2 M71 94 Existed
Steering lock unit GroundContinuity
Connector Terminal
M12 2 Not existed
Revision: 2010 May2011 QX56

B2555 STOP LAMPSEC-73
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B2555 STOP LAMP
DTC LogicINFOID:0000000006226222
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Depress the brake pedal and wait 1 second or more.
2. Check DTC in “Self Diagnostic Result” mode of “BCM” using CONSULT-III.
Is DTC detected?
YES >> Go to SEC-73, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226223
1.CHECK STOP LAMP SWITCH INPUT SIGNAL 1
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check voltage between BCM harness connector and ground.
Is the inspection normal?
YES >> GO TO 2.
NO-1 >> Check 10 A fuse [No. 7, lo cated in the fuse block (J/B)].
NO-2 >> Check harness for open or short between BCM and fuse.
2.CHECK STOP LAMP SWIT CH POWER SUPPLY CIRCUIT
1. Disconnect stop lamp switch connector.
2. Check voltage between stop lamp switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check harness for open or short between stop lamp switch and fuse.
3.CHECK STOP LAMP SWITCH INPUT SIGNAL 2
1. Connect stop lamp switch connector.
2. Check voltage between BCM harness connector and ground.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B2555 STOP LAMP BCM makes a comparison between the
upper voltage and lower voltage of stop
lamp switch. It judges from their values to
detect the malfunctioning circuit.  Harness or connectors
(Stop lamp switch circuit is open or
shorted.)
 Stop lamp switch
Fuse
BCM
(+)
(–)Voltage (V)
(Approx.)
BCM
Connector Terminal M71 105 Ground Battery voltage
(+) (–)Voltage (V)
(Approx.)
Sto p l am p s w it ch
Connector Terminal E115 1 Ground Battery voltage
Revision: 2010 May2011 QX56

SEC-74
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2555 STOP LAMP
Is the inspecting result normal?
YES >> GO TO 4.
NO >> GO TO 5.
4.REPLACE BCM
1. Replace BCM. Refer to BCS-81, "
Removal and Installation".
2. Perform initialization of BCM and registration of all Intelligent Keys using CONSULT-III.
For initialization and registration procedures, refer to CONSULT-III Operation Manual NATS-IVIS/NVIS.
>> INSPECTION END
5.CHECK STOP LAMP SWITCH CIRCUIT
1. Disconnect stop lamp switch connector.
2. Check continuity between stop lamp swit ch harness connector and BCM harness connector.
3. Check continuity between stop lamp switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace harness.
6.CHECK STOP LAMP SWITCH
Refer to SEC-74, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 7.
NO >> Replace stop lamp switch. Refer to BR-20, "
Removal and Installation".
7.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000006226224
1.CHECK STOP LAMP SWITCH
1. Turn ignition switch OFF.
2. Disconnect stop lamp switch connector.
3. Check continuity between stop lamp switch terminals.
(+)
(–) Condition Voltage (V)
(Approx.)
BCM
Connector Terminal
M68 9 Ground Brake pedal Depressed Battery voltage
Not depressed 0
St op la mp sw i tc h BC M Continuity
Connector Terminal Connector Terminal
E115 2 M68 9 Existed
Stop lamp switch GroundContinuity
Connector Terminal
E115 2 Not existed
Revision: 2010 May2011 QX56
