SYMPTOM DIAGNOSIS
EXCESSIVE OPERATION FREQUENCY
DescriptionINFOID:0000000006222657
VDC function, TCS function, ABS functi on, EBD function, hill start assist function and brake limited slip differ-
ential (BLSD) function operates in excessive operation frequency.
Diagnosis ProcedureINFOID:0000000006222658
1.CHECK BRAKING FORCE
Check brake force using a brake tester.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check brake system.
2.CHECK FRONT AND REAR AXLE
Check that there is no excessive looseness in front and rear axle.
 Front axle: Refer to FA X - 7 , "
Inspection" (2WD), FAX-16, "Inspection" (4WD).
 Rear axle: Refer to RAX-5, "
Inspection"
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace error-detected parts.
3.CHECK WHEEL SENSOR
Check wheel sensor.
 Check installation and damage of wheel sensor.
 Check connection of wheel sensor harness connector.
 Check terminal of wheel sensor harness connector.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace wheel sensor.  Front wheel sensor: Refer to BRC-134, "
FRONT WHEEL SENSOR : Removal and Installation".
 Rear wheel sensor: Refer to BRC-135, "
REAR WHEEL SENSOR : Removal and Installation".
4.CHECK WARNING LAMP TURNS OFF
Check that ABS warning lamp, brake warning lamp and VDC warning lamp turn OFF approx. 1 second after
key switch is turned ON and stay in OFF status during driving.
CAUTION:
Brake warning lamp turns ON when parking brake is operated (parking brake switch is ON) or brake
fluid is less than the specified level (brake fluid level switch is ON).
Is the inspection result normal?
YES >> Normal
NO >> Perform self-diagnosis for “ABS” with CONSULT-III.
