2011 INFINITI QX56 ground

P0615 STARTER RELAYTM-105
< DTC/CIRCUIT DIAGNOSIS > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK HARNESS BETWEEN A/T ASSE MBLY AND IPDM E/R (PART 2)
Check the continuity between A/T assembly vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace damaged parts.
4.CHECK JOINT CONNECTOR
1. Remove joint connector. Refer to TM-182, "
Exploded View".
2. Check the continuity between joint connector terminals.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts.
5.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace the control valve & TCM. Refer to TM-182, "Exploded View".
NO >> Repair or replace damaged parts.
A/T assembly vehicle side harness connector IPDM E/R vehicle side harness connector Continuity
Connector Terminal Connector Terminal
F51 9 E15 48 Existed
A/T assembly vehicle side harness connector GroundContinuity
Connector Terminal
F51 9 Not existed
A/T assembly harness connector side TCM harness connector side Continuity
Te r m i n a l Te r m i n a l
99Existed
Revision: 2010 May2011 QX56

P1815 M-MODE SWITCHTM-145
< DTC/CIRCUIT DIAGNOSIS > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
1. Turn ignition switch OFF.
2. Check manual mode switch. Refer to TM-146, "
Component Inspection (Manual Mode Switch)".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace damaged parts.
3.CHECK GROUND CIRCUIT (MANUA L MODE SWITCH CIRCUIT)
1. Turn ignition switch OFF.
2. Check continuity between A/T shift selector vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace damaged parts.
4.CHECK HARNESS BETWEEN A/T SHIFT SELEC TOR AND COMBINATION METER (PART 1)
1. Disconnect unified meter and A/C amp. connector.
2. Check continuity between A/T shift selector v ehicle side harness connector terminals and combination
meter vehicle side harness connector terminals.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts.
5.CHECK HARNESS BETWEEN A/T SHIFT SELEC TOR AND COMBINATION METER (PART 2)
Check continuity between A/T sh ift selector vehicle side harness connector terminals and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace damaged parts.
6.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace damaged parts.
7.CHECK COMBINATION METER
1. Reconnect all the connectors.
2. Turn ignition switch ON.
A/T shift selector vehicle side harness connector
GroundContinuity
Connector Terminal
M57 4 Existed
A/T shift selector vehicle side harness connector Combination meter vehicle side harness connector Continuity
Connector Terminal Connector Terminal
M57 1
M34 40
Existed
238
339
537
A/T shift selector vehicle side harness connector
GroundContinuity
Connector Terminal
M57 1
Not existed
2
3
5
Revision: 2010 May2011 QX56

MAIN POWER SUPPLY AND GROUND CIRCUITTM-151
< DTC/CIRCUIT DIAGNOSIS > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
MAIN POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000006226875
1.CHECK TCM POWER SOURCE (PART 1)
1. Turn ignition switch OFF.
2. Disconnect A/T assembly connector.
3. Check voltage between A/T assembly vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 6.
2.CHECK TCM POWER SOURCE (PART 2)
Check voltage between A/T assembly vehicl e side harness connector terminals and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 7.
3.CHECK TCM GROUND CIRCUIT
Check continuity between A/T assembly v ehicle side harness connector terminals and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace damaged parts.
4.CHECK JOINT CONNECTOR
1. Remove joint connector. Refer to TM-182, "
Exploded View".
2. Check the continuity between joint connector terminals.
Is the inspection result normal?
A/T assembly vehicle side harness connector
GroundCondition Voltage (Approx.)
Connector Terminal
F51 2 Always Battery voltage
A/T assembly vehicle side harness connector
GroundCondition Voltage (Approx.)
Connector Terminal
F51 1
Turn ignition switch ON Battery voltage
Turn ignition switch OFF 0 V
6 Turn ignition switch ON Battery voltage
Turn ignition switch OFF 0 V
A/T assembly vehicle side harness connector
GroundContinuity
Connector Terminal
F51 5
Existed
10
A/T assembly harness connector side TCM harness connector side Continuity
Te r m i n a l Te r m i n a l
11
Existed
22
5 5
66
10 10
Revision: 2010 May2011 QX56

TM-152
< DTC/CIRCUIT DIAGNOSIS >[7AT: RE7R01B]
MAIN POWER SUPPLY AND GROUND CIRCUIT
YES >> GO TO 5.
NO >> Repair or replace damaged parts.
5.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace the control valve & TCM. Refer to TM-182, "Exploded View".
NO >> Repair or replace damaged parts.
6.DETECT MALFUNCTIONING ITEM (PART 1)
Check the following.
 Harness for short or open between battery positive term inal and A/T assembly vehicle side harness connec-
tor terminal 2. Refer to PG-11, "
Wiring Diagram - BATTERY POWER SUPPLY -".
Battery
 10A fuse (No.38, located in the fuse, fusible link and relay box). Refer to PG-141, "
Fuse and Fusible Link
Arrangement".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> Repair or replace damaged parts.
7.CHECK HARNESS BETWEEN IPDM E/ R AND A/T ASSEMBLY (PART 1)
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check continuity between IPDM E/R vehicle side harness connector terminal and A/T assembly vehicle
side harness connector terminals.
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair or replace damaged parts.
8.CHECK HARNESS BETWEEN IPDM E/ R AND A/T ASSEMBLY (PART 2)
Check continuity between A/T assembly vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 9.
NO >> Repair or replace damaged parts.
9.DETECT MALFUNCTIONING ITEM (PART 2)
Check the following.
 Harness for short or open between ignition switch and IPDM E/R. Refer to PG-89, "
Wiring Diagram - IGNI-
TION POWER SUPPLY -".
 Ignition switch
 10A fuse (No.55, located in the IPDM E/R). Refer to PG-143, "
Fuse, Connector and Terminal Arrangement".
 IPDM E/R
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> Repair or replace damaged parts.
IPDM E/R vehicle side harness connector A/T assembly vehicle side harness connector Continuity
Connector Terminal Connector Terminal
E15 57 F51 1
Existed
6
A/T assembly vehicle side harness connector
GroundContinuity
Connector Terminal
F51 1
Not existed
6
Revision: 2010 May2011 QX56

TM-154
< DTC/CIRCUIT DIAGNOSIS >[7AT: RE7R01B]
TOW MODE SYSTEM
*1: 2WD models
*2: 4WD models
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 9.
6.CHECK TOW MODE SWITCH
Check tow mode switch. Refer to TM-155, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace damaged parts.
7.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair or replace damaged parts.
8.CHECK TOW MODE SYSTEM
1. Replace the control valve & TCM. Refer to TM-182, "
Exploded View".
2. Reinstall any parts removed.
3. Check tow mode system. Refer to TM-153, "
Component Function Check".
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace combination meter. Refer to TM-182, "
Exploded View".
9.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between SNOW MODE/TOW MODE/VDC OFF switch as sembly (2WD models) or 4WD
switch assembly connector (4WD models) vehicle side harness connector terminal and ground.
*1: 2WD models
*2: 4WD models
Is the inspection result normal?
YES >> GO TO 10.
NO >> Repair or replace damaged parts.
10.CHECK HARNESS BETWEEN SNOW MODE/TOW MODE/VDC OFF SWITCH ASSEMBLY (2WD MOD-
ELS) OR 4WD SWITCH ASSEMBLY (4WD MODELS) AND COMBINATION METER (PART 1)
1. Disconnect combination meter connector.
2. Check continuity between SNOW MODE/TOW MODE/VDC OFF switch as sembly (2WD models) or 4WD
switch assembly connector (4WD models) vehicl e side harness connector terminal and combination
meter vehicle side harness connector terminal.
SNOW MODE/TOW MODE/VDC OFF sw itch assembly (2WD models) or 4WD switch assembly
(4WD models) Voltage (Approx.)
Connector Te r m i n a l
+–
M54
*1
M147*223 20 Battery voltage
SNOW MODE/TOW MODE/VDC O FF switch assembly (2WD
models) or 4WD switch assembly (4WD models)
GroundContinuity
Connector Terminal
M54
*1
M147*220 Existed
Revision: 2010 May2011 QX56

TOW MODE SYSTEMTM-155
< DTC/CIRCUIT DIAGNOSIS > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
*1: 2WD models
*2: 4WD models
Is the inspection result normal?
YES >> GO TO 11.
NO >> Repair or replace damaged parts.
11 .CHECK HARNESS BETWEEN SNOW MODE/TOW MODE/VDC OFF SWITCH ASSEMBLY (2WD MOD-
ELS) OR 4WD SWITCH ASSEMBLY (4WD MODELS) AND COMBINATION METER (PART 2)
Check continuity between SNOW MODE/TOW MODE/V DC OFF switch assembly (2WD models) or 4WD
switch assembly connector (4WD models) vehicle side harness connector terminal and ground.
*1: 2WD models
*2: 4WD models
Is the inspection result normal?
YES >> GO TO 12.
NO >> Repair or replace damaged parts.
12.CHECK COMBINATION METER
1. Reconnect all the connectors.
2. Check combination meter input/output signal. Refer to MWI-35, "
Reference Value".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> Replace combination meter. Refer to MWI-85, "
Exploded View".
Component InspectionINFOID:0000000006226878
NOTE:
Tow mode switch is integrated in to SNOW MODE/T OW MODE/VDC OFF switch assembly (2WD models) or
4WD switch assembly (4WD models).
1.CHECK TOW MODE SWITCH
Check continuity between SNOW MODE/TOW MODE/V DC OFF switch assembly (2WD models) or 4WD
switch assembly (4WD models) connector terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace tow mode switch. Refer to TM-181, "
Removal and Installation".
SNOW MODE/TOW MODE/VDC OFF switch as-
sembly (2WD models) or 4WD switch assembly (4WD models) Combination meter
Continuity
Connector Terminal Connector Terminal M54
*1
M147*223 M34 7 Existed
SNOW MODE/TOW MODE/VDC OF F switch assembly (2WD
models) or 4WD switch assembly (4WD models)
GroundContinuity
Connector Terminal
M54
*1
M147*223 Not existed
SNOW MODE/TOW MODE/VDC OF F switch assembly (2WD
models) or 4WD switch assembly (4WD models) Condition Continuity
Te r m i n a l
23 20 Tow mode switch is depressed Existed
Tow mode switch is released Not existed
Revision: 2010 May2011 QX56

SHIFT LOCK SYSTEMTM-157
< DTC/CIRCUIT DIAGNOSIS > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
SHIFT LOCK SYSTEM
Component Function CheckINFOID:0000000006226882
1.CHECK A/T SHIFT LOCK OPERATION (PART 1)
1. Turn ignition switch ON.
2. Shift the selector lever to “P” position.
3. Attempt to shift the selector lever to any other position with the brake pedal released.
Can the selector lever be shifted to any other position?
YES >> Go to TM-157, "Diagnosis Procedure".
NO >> GO TO 2.
2.CHECK A/T SHIFT LOCK OPERATION (PART 2)
Attempt to shift the selector lever to any other position with the brake pedal depressed.
Can the selector lever be shifted to any other position?
YES >> INSPECTION END
NO >> Go to TM-157, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006226883
1. CHECK POWER SOURCE
1. Turn ignition switch OFF.
2. Disconnect fuse block (J/B) connector.
3. Turn ignition switch ON.
4. Check voltage between fuse block (J/B) connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check the following.  10A fuse [No. 3, located in fuse block (J/B)]. Refer to PG-140, "
Fuse, Connector and Terminal
Arrangement".
 Harness for short or open between ignition switch and fuse block (J/B). Refer to PG-89, "
Wiring
Diagram - IGNITION POWER SUPPLY -".
 Ignition switch
2.CHECK HARNESS BETWEEN FUSE BLOCK (J/B ) AND STOP LAMP SWITCH (PART 1)
1. Turn ignition switch OFF.
2. Disconnect stop lamp switch connector.
3. Check continuity between fuse block (J/B) vehicl e side harness connector terminal and stop lamp switch
vehicle side harness connector terminal.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK HARNESS BETWEEN FUSE BLOCK (J/B ) AND STOP LAMP SWITCH (PART 2)
Check continuity between stop lamp switch vehicle side harness connector terminal and ground.
Fuse block (J/B) connector
GroundVoltage (Approx.)
Connector Terminal
E103 4F Battery voltage
Fuse block (J/B) vehicle side harness connector Stop lamp switch vehicle side harness connector Continuity
Connector Terminal Connector Terminal
E103 4F E115 3 Existed
Revision: 2010 May2011 QX56

TM-158
< DTC/CIRCUIT DIAGNOSIS >[7AT: RE7R01B]
SHIFT LOCK SYSTEM
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace damaged parts.
4.CHECK STOP LAMP SWITCH (PART 1)
Check stop lamp switch. Refer to TM-159, "
Component Inspection (Stop Lamp Switch)".
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 10.
5.CHECK HARNESS BETWEEN STOP LAMP SWIT CH AND A/T SHIFT SELECTOR (PART 1)
1. Disconnect A/T shift selector connector.
2. Check continuity between stop lamp switch vehicl e side harness connector terminal and A/T shift selector
vehicle side harness connector terminal.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace damaged parts.
6.CHECK HARNESS BETWEEN STOP LAMP SWIT CH AND A/T SHIFT SELECTOR (PART 2)
Check continuity between control vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace damaged parts.
7.CHECK GROUND CIRCUIT
Check continuity between A/T shift selector vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair or replace damaged parts.
8.CHECK PARK POSITION SWITCH
Check park position switch. Refer to TM-159, "
Component Inspection (Park Position Switch)".
Is the inspection result normal?
YES >> GO TO 9.
NO >> Repair or replace damaged parts.
9.CHECK SHIFT LOCK SOLENOID
Check shift lock solenoid. Refer to TM-159, "
Component Inspection (Shift Lock Solenoid)".
Stop lamp switch vehicle side harness connector
GroundContinuity
Connector Terminal
E115 3 Not existed
Stop lamp switch vehicle side harness connector A/T shift selector vehicle side harness connector Continuity
Connector Terminal Connector Terminal
E115 4 M57 9 Existed
A/T shift selector vehicle side harness connector GroundContinuity
Connector Terminal
M57 9 Not existed
A/T shift selector vehicle side harness connector GroundContinuity
Connector Terminal
M57 10 Existed
Revision: 2010 May2011 QX56
