SCS-4
< PRECAUTION >[HBMC]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint S
ystem (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000006256134
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and w hether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the “SRS AIR BAG” and “SEAT BELT” of this
Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision that would result in air bag inflation, all maintenance must be performed by
an authorized NISS AN/INFINITI dealer.
 Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the “SRS AIR BAG”.
 Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
 When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s)
with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly
causing serious injury.
 When using air or electric power tools or hammers , always switch the ignition OFF, disconnect the
battery, and wait at least 3 minu tes before performing any service.
Precaution Necessary for Steering W heel Rotation after Battery Disconnect
INFOID:0000000006256136
NOTE:
 Before removing and installing any control units, first tu rn the push-button ignition switch to the LOCK posi-
tion, then disconnect bot h battery cables.
 After finishing work, confirm that all control unit connectors are connected properly, then re-connect both
battery cables.
 Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work.
If a DTC is detected, perform trouble diagnos is according to self-diagnosis results.
For vehicle with steering lock unit, if the battery is disconnected or discharged, the steering wheel will lock and
cannot be turned.
If turning the steering wheel is required with the bat tery disconnected or discharged, follow the operation pro-
cedure below before starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables. NOTE:
Supply power using jumper cables if battery is discharged.
2. Turn the push-button ignition switch to ACC position. (At this time, the steering lock will be released.)
3. Disconnect both battery cables. The steering lock wi ll remain released with both battery cables discon-
nected and the steering wheel can be turned.
4. Perform the necessary repair operation.
Revision: 2010 May2011 QX56

PRECAUTIONSSCS-47
< PRECAUTION > [AIR LEVELIZER CONTROL SYSTEM]
C
D
F
G H
I
J
K L
M A
B
SCS
N
O P
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000006256135
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the “SRS AIR BAG” and “SEAT BELT” of this
Service Manual.
WARNING:
 To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision that would result in air ba g inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
 Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the “SRS AIR BAG”.
 Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
 When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the
ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s)
with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly
causing serious injury.
 When using air or electric power tools or hammers , always switch the ignition OFF, disconnect the
battery, and wait at least 3 minutes before performing any service.
Precaution Necessary for Steering Wh eel Rotation after Battery Disconnect
INFOID:0000000006256137
NOTE:
 Before removing and installing any control units, first tu rn the push-button ignition switch to the LOCK posi-
tion, then disconnect both battery cables.
 After finishing work, confirm that all control unit connectors are connected properly, then re-connect both
battery cables.
 Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work.
If a DTC is detected, perform trouble diagnos is according to self-diagnosis results.
For vehicle with steering lock unit, if the battery is disconnected or discharged, the steering wheel will lock and
cannot be turned.
If turning the steering wheel is required with the batte ry disconnected or discharged, follow the operation pro-
cedure below before starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables. NOTE:
Supply power using jumper cables if battery is discharged.
2. Turn the push-button ignition switch to ACC position. (At this time, the steering lock will be released.)
3. Disconnect both battery cables. The steering lock wil l remain released with both battery cables discon-
nected and the steering wheel can be turned.
4. Perform the necessary repair operation.
Revision: 2010 May2011 QX56

SCS-48
< PRECAUTION >[AIR LEVELIZER CONTROL SYSTEM]
PRECAUTIONS
5. When the repair work is completed, re-connect bot
h battery cables. With the brake pedal released, turn
the push-button ignition switch from ACC position to ON position, then to LOCK position. (The steering
wheel will lock when the push-button igniti on switch is turned to LOCK position.)
6. Perform self-diagnosis check of all control units using CONSULT-III.
Precaution for Procedure without Cowl Top CoverINFOID:0000000006256139
When performing the procedure after removing cowl top cover, cover
the lower end of windshield with urethane, etc.
Precaution for Air Levelizer Control SystemINFOID:0000000006256038
 Never allow water and dust to enter the inside of air compressor.
 Never disassemble the vehicle height sensor.
PIIB3706J
Revision: 2010 May2011 QX56

DESCRIPTIONSCS-49
< SYSTEM DESCRIPTION > [AIR LEVELIZER CONTROL SYSTEM]
C
D
F
G H
I
J
K L
M A
B
SCS
N
O P
SYSTEM DESCRIPTION
DESCRIPTION
DescriptionINFOID:0000000006256039
 Corrects sinkage of vehicle rear that occurs in laden or towing conditions.
 Maintains vehicle height at a constant level and improv es riding comfort by charging or discharging air in air
chamber of rear shock absorber, according to signal from vehicle height sensor installed to rear suspension.
Revision: 2010 May2011 QX56

SCS-50
< SYSTEM DESCRIPTION >[AIR LEVELIZER CONTROL SYSTEM]
COMPONENT PARTS
COMPONENT PARTS
Component Parts LocationINFOID:0000000006256040
Component DescriptionINFOID:0000000006256041
1. Combination meter
Refer to MWI-6, "
METER SYSTEM
: Component Parts Location".2. CK SUSP indicator lamp 3. Air levelizer control module
4. Air compressor relay 5. Air chamber 6. Air compressor
7. Vehicle height sensor
A. Inside of luggage side finisher low- er (LH) B. Engine room (RH) C. Rear shock absorber
D. Vehicle rear (LH)
JSEIA0223GB
Component parts Reference
Air levelizer control module SCS-51, "
Air Levelizer Control Module"
Vehicle height sensorSCS-51, "Vehicle Height Sensor"
Air compressor
SCS-51, "Air Compressor"Exhaust solenoid
Revision: 2010 May2011 QX56

COMPONENT PARTSSCS-51
< SYSTEM DESCRIPTION > [AIR LEVELIZER CONTROL SYSTEM]
C
D
F
G H
I
J
K L
M A
B
SCS
N
O P
Air Levelizer Control ModuleINFOID:0000000006256042
 Operates ON/OFF of air compressor (exhaust solenoid) , according to signal from vehicle height sensor.
 Transmits CK SUSP indicator lamp signal to the combination meter via CAN communication, when setting of standard vehicle height is incomplete.
 If malfunction is detected, the syste m enters fail-safe mode. Refer to SCS-59, "
Fail-safe".
Vehicle Height SensorINFOID:0000000006256043
Measures vehicle height of vehicle rear and transmits th is information to air levelizer control module according
to electric signal.
Air CompressorINFOID:0000000006256044
Operates according to signal from air levelizer control module via air compressor relay, and charges air in air
chamber of rear shock absorber.
EXHAUST SOLENOID
Operates according to signal from air levelizer control module, and discharges air in air chamber of rear shock
absorber.
Air Compressor RelayINFOID:0000000006256045
Turns ON according to signal from air levelizer control module, and operates air compressor.
CK SUSP Indicator LampINFOID:0000000006256046
 Turns ON for 2 seconds when ignition switch is turned ON, for the purpose of bulb check.
 Turns ON when setting of standard vehicle height is incomplete.
NOTE:
Does not turn ON when the system is malfunctioning.
Air compressor relay SCS-51, "Air Compressor Relay"
CK SUSP indicator lampSCS-51, "CK SUSP Indicator Lamp"
Component parts Reference
Revision: 2010 May2011 QX56

STRUCTURE AND OPERATIONSCS-53
< SYSTEM DESCRIPTION > [AIR LEVELIZER CONTROL SYSTEM]
C
D
F
G H
I
J
K L
M A
B
SCS
N
O P
Vehicle Height SensorINFOID:0000000006256048
Vehicle height sensor is installed between rear suspension member
(1) and rear lower link (2).
Since arm (A) portion and rod (B) portion are ball joint type, distance
between rear suspension member and rear lower link shortens when
vehicle height of vehicle rear lowers because of laden or towing con-
ditions, and arm portion changes to the status that is higher in its left
side as shown in the figure.
This angle change in arm portion is transmitted to the air levelizer
control module according to electric signal.
JSEIA0219ZZ
Revision: 2010 May2011 QX56

SCS-54
< SYSTEM DESCRIPTION >[AIR LEVELIZER CONTROL SYSTEM]
SYSTEM
SYSTEM
System DiagramINFOID:0000000006256049
System DescriptionINFOID:0000000006256050
 Based on the signal from the vehicle height sensor, t
he air levelizer control module operates the air com-
pressor (exhaust solenoid) and controls vehicle height so that it remains at a constant height. This operation
occurs if vehicle height of vehicle rear is judged to be 15 mm (0.59 in) or more or 15 mm (0.59 in) or less
than standard vehicle height, continuously for 30 seconds, when engine is started.
 If malfunction is detected, the system enters fail-safe mode. Refer to SCS-59, "
Fail-safe".
INPUT/OUTPUT SIGNAL
Air levelizer control module transmits and receives following signals between each control unit via CAN com-
munication line.
OPERATING PRINCIPLE
System Time Table
JSEIA0220GB
Component parts Control signal
ECM Transmits the following signal via CAN communication line to air levelizer control module.
 Engine speed signal
Combination meter Receives the following signal via CAN communication line from air levelizer control module.
 CK SUSP indicato
r lamp signal
ABS actuator and elec tric unit (con-
trol unit) Transmits the following signal via CAN communication line to air levelizer control module.
 Vehicle speed signal
Revision: 2010 May2011 QX56
