2011 INFINITI QX56 maintenance

EXL-124
< PERIODIC MAINTENANCE >[XENON TYPE]
FRONT FOG LAMP AIMING ADJUSTMENT
Front fog lamp light distribution on the screen
JPLIA0008ZZ
A : Cutoff line
B : High illuminance area
H : Horizontal center line of front fog lamp
V : Vertical center line of front fog lamp
X : Cutoff line height
Revision: 2010 May2011 QX56
