2011 HONDA PILOT Owners Manual

The instrument panel has many
indicators to give you important
inf ormation about your vehicle. This indicator comes on when youturn the ignition switch to the ON
(II) position. It reminds you and your
passengers to f asten your seat belts.
A beeper also sounds if you have not
f astened your seat belt.
If your f ront passenger does not
f asten their seat belt, the indicator
comes on about 6 seconds af ter the
ignition switch is turned to the ON
(II) position.If either of you do not f asten your
seat belt while driving, the beeper
will sound and the indicator will f lash
again at regular intervals. For more
inf ormation, see page .
You will also see a ‘‘FASTEN SEAT
BELT’’ or ‘‘FASTEN PASSENGER
SEAT BELT’’ message on the multi-
inf ormation display (see page ).
For more inf ormation, see page .
If you turn the ignition switch to the
ON (II) position bef ore f astening
your seat belt, the beeper sounds,
and the indicator f lashes. If you do
notfastenyourseatbeltbeforethe
beeper stops, the indicator stops
f lashing but remains on. 22
9522
On vehicles with navigation system
Seat Belt Reminder
Indicator
Instrument Panel Indicators
Inst rument s and Cont rols
69
10/01/26 18:34:43 31SZA620_074
2011 Pilot

The engine can be severely
damaged if this indicator f lashes
or stays on when the engine is
running. For more inf ormation,
see page .
You will also see a ‘‘CHECK
ENGINE OIL LEVEL’’ message
on the multi-information display
(see page ).If this indicator comes on when the
engine is running, the battery is not
being charged. For more inf ormation,
see page .
You will also see a ‘‘CHECK
CHARGING SYSTEM’’ message on
the multi-information display (see
page ).
For more inf ormation, see page
.
You will also see a ‘‘CHECK
EMISSION SYSTEM’’ message on
the multi-information display (see
page ). For more inf ormation, see
page .
521
95 521
95 522
95522
On vehicles with navigation system On vehicles with navigation systemOn vehicles with navigation system
L ow Oil Pressure
Indicator
Charging System
IndicatorMalf unction Indicator
Lamp
Instrument Panel Indicators
70
10/01/26 18:34:55 31SZA620_075
2011 Pilot

This indicator has two f unctions:Itcomesonwhenyouturnthe
ignition switch to the ON (II)
position. It is a reminder to check
the parking brake. A beeper
sounds if you drive with the
parking brake not f ully released.
Driving with the parking brake not
fully released can damage the
brakes and tires.
You will also see a ‘‘RELEASE
PARKING BRAKE’’ message on
the multi-information display (see
page ). If it remains on af ter you have
fully released the parking brake
while the engine is running, or if it
comes on while driving, there
could be a problem with the brake
system. For more inf ormation, see
page .
You will also see a ‘‘LOW BRAKE
FLUID’’ or ‘‘CHECK BRAKE
SYSTEM’’ message on the multi-
inf ormation display (see page ).
1. 2.
95 523
95
On vehicles with navigation system On vehicles with navigation system
Instrument Panel Indicators
Parking Brake
and Brake
System
Indicator (Red)
Inst rument s and Cont rols
71
U.S. Canada
10/01/26 18:35:05 31SZA620_076
2011 Pilot

This indicator comes on f or several
seconds when you turn the ignition
switch to the ON (II) position. If it
comes on at any other time, it
indicates a potential problem with
your f ront airbags. This indicator will
also alert you to a potential problem
with your side airbags, passenger’s
side airbag automatic cutoff system,
side curtain airbags, automatic seat
belt tensioners, driver’s seat position
sensor, or the f ront passenger’s
weight sensors. For more
inf ormation, see page .
You will also see a ‘‘CHECK
AIRBAG SYSTEM’’ message on the
multi-inf ormation display (see page). This indicator comes on f or several
seconds when you turn the ignition
switch to the ON (II) position. If it
comes on at any other time, it
indicates that the passenger’s side
airbag has automatically shut off.
For more inf ormation, see page .
This indicator normally comes on
f or a f ew seconds when you turn
the ignition switch to the ON (II)
position, and when the ignition
switch is turned to the START
(III) position. If it comes on at any
other time, there is a problem with
theABS.If thishappens,have
your vehicle checked at a dealer.
With this indicator on, your
vehicle still has normal braking
ability but no anti-lock f unction.
For more inf ormation, see page
.
You will also see a ‘‘CHECK ABS
SYSTEM’’ message on the multi-
inf ormation display (see page ).
You will also see a ‘‘PASSENGER
SIDE AIRBAG OFF’’ message on the
multi-inf ormation display (see page
).
35
95 35
95 429
95
On vehicles with navigation system On vehicles with navigation system
On vehicles with navigation system
Supplemental Restraint
System Indicator Anti-lock Brake System
(A BS) Indicator
Side Airbag Of f
Indicator
Instrument Panel Indicators
72
U.S. Canada
10/01/26 18:35:21 31SZA620_077
2011 Pilot

This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position.This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position. For more inf ormation, see
page .
Itcomesonasareminderthatyou
have turned off the vehicle
stability assist (VSA) system.
It flashes when VSA is active (see
page ).
You will also see a ‘‘CHECK VSA
SYSTEM’’ message on the multi-
inf ormation display (see page ). This indicator has three f unctions:
The lef t or right turn signal indicator
blinks when you signal a lane change
or turn. If an indicator does not blink
or blinks rapidly, it usually means
one of the turn signal bulbs is
burned out (see page ). Replace
the bulb as soon as possible, since
other drivers cannot see that you are
signaling.
When you press the hazard warning
button, both turn signal indicators
and all turn signals on the outside of
the vehicle f lash.
If itcomesonandstaysonatany
other time, or if it does not come on
when you turn the ignition switch to
the ON (II) position, there is a
problem with the VSA or Hill Start
Assist systems. Take your vehicle to
a dealer to have it checked. Without
VSA, your vehicle still has normal
driving ability, but will not have VSA
traction and stability enhancement.
See page for more information
on the VSA system.
It comes on along with the VSA
system indicator if there is a
problem with the VSA or Hill Start
Assist systems.
You will also see a ‘‘CHECK VSA
SYSTEM’’ message on the multi-
inf ormation display (see page ). 1.
2.
3.
431
95 431
431
95 484
On vehicles with navigation system
On vehicles with navigation system
Instrument Panel Indicators
Vehicle Stability Assist
(VSA ) System IndicatorVSA Activation Indicator
Turn Signal and
Hazard Warning
Indicators
Inst rument s and Cont rols
73
10/01/26 18:35:38 31SZA620_078
2011 Pilot

This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position.
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position. If it comes on while driving,
it indicates that one or more of your
vehicle’s tires are signif icantly low
on pressure.
If this happens, pull to the side of the
road when it is saf e, check which tire
has lost the pressure, and determine
the cause. If it is because of a flat tire,
replace the flat tire with the compact
spare (see page ), and have the
f lat tire repaired as soon as possible.
If two or more tires are underinf lated,
call a prof essional towing service
(see page ). For more
inf ormation, see page . This indicator has two f unctions:
If it comes on while driving, it
indicates that one or more of your
vehicle’s tires are signif icantly low
on pressure.
You will also see a ‘‘CHECK TIRE
PRESSURE’’ message on the
multi-inf ormation display (see
page ).
Check the tire pressure monitor
on the multi-information display
and determine the cause (see page ). If this happens, pull to the side
of the road when it is saf e,
check which tire has lost
pressure on the multi-
inf ormation display, and
determine the cause. If it is
because of a flat tire, have the
flat tire repaired as soon as
possible. If two or more tires are
underinf lated, call a prof essional
towing service. For more
inf ormation, see page .
1.
508 420 96
424 531
531
On vehicles without navigation system On vehicles with navigation system
Instrument Panel Indicators
Low Tire Pressure/
TPMS Indicator
Low Tire Pressure
Indicator
74
10/01/26 18:35:51 31SZA620_079
2011 Pilot

This indicator comes on when there
is a problem with the starter system.
For more inf ormation, see page .
If you see a ‘‘CHECK STARTER
SYSTEM’’ message on the multi-
inf ormation display, there is a
problem with the starter system (see
page ).
If this indicator begins to f lash,
there is a problem with the tire
pressure monitoring system
(TPMS). You will also see a
‘‘CHECK TPMS SYSTEM’’
message on the multi-inf ormation
display. The indicator continues to
f lash f or a while (approximately 1
minute), then stays on. If this
happens, have your dealer check
the system as soon as possible.
For more inf ormation, see page
. This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position.
If this indicator comes on and stays
on at any other time, or if it does not
come on when you turn the ignition
switch to the ON (II) position, there
is a problem with the TPMS. With
this indicator on, the low tire
pressure indicator and the tire
pressure monitor will not come on
when a tire loses pressure. Take the
vehicle to your dealer to have the
system checked.
2.
426 411
96
On vehicles without navigation system On vehicles without navigation system
On vehicles with navigation system
Instrument Panel Indicators
Starter System
Indicator Tire Pressure Monitoring
System (T PMS) Indicator
Inst rument s and Cont rols
75
U.S. Canada
10/01/26 18:36:04 31SZA620_080
2011 Pilot

This indicator monitors the
temperature of the automatic
transmission f luid. It should come on
f or a f ew seconds when you turn the
ignition switch to the ON (II)
position. If it comes on while driving,
it means the transmission f luid
temperature is too high. Pull to the
side of the road when it is saf e, shif t
to Park, and let the engine idle until
the indicator goes out.You will also see an ‘‘A/T TEMP
HIGH’’ message on the multi-
inf ormation display (see page ).
96
4WD models only On 4WD models with navigation system
Instrument Panel Indicators
A/T Temperature
Indicator
76
Continuing to drive with the A/T
temperature indicator on may cause
serious damage to the transmission.
10/01/26 18:36:11 31SZA620_081
