2011 HONDA CIVIC COUPE Owners Manual

CONT INUED
These labels are in the locations
shown. They warn you of potential
hazards that could cause serious
injury or death. Read these labels
caref ully.
If a label comes of f or becomes hard
to read (except for the U.S.
dashboard label which may be
removed by the owner), contact your
dealer f or a replacement.U.S. models
U.S. models only
Canadian models
Saf ety L abels
Driver and Passenger Saf ety
53
SUN VISOR
DASHBOARD
RADIATOR CAP
Main Menu

Canadian models
U.S. models
Saf ety L abels
54
DOORJAMBS
Main Menu

This section gives inf ormation about
the controls and displays that
contribute to the daily operation of
your vehicle. All the essential
controls are within easy reach............................
Control Locations . 56
............................
Instrument Panel . 57
..........
Instrument Panel Indicators . 59
.............................................
Gauges . 67
..............
Display Change Button . 68
.....................................
Odometer . 68
...................................
Trip Meter . 68
Outside Temperature
...................................
Indicator . 69
..................................
Fuel Gauge . 70
...................
Temperature Gauge . 70
..........
Check Fuel Cap Message . 70
...............
Maintenance Minder . 71
Controls Near the Steering
...........................................
Wheel . 72
.
Windshield Wipers and Washers . 73
.........
Turn Signals and Headlights . 74
........................................
Fog Lights . 75
........
Instrument Panel Brightness . 76
.................
Hazard Warning Button . 77
.................
Rear Window Def ogger . 77
........
Steering Wheel Adjustments . 78
...............................
Keys and Locks . 79
........................
Immobilizer System . 80
................................
Ignition Switch . 81 ......................................
Door Locks . 82
......................
Power Door Locks . 83
.
Auto Door Locking/Unlocking . 84
.......................
Remote Transmitter . 89
................................................
Trunk . 93
........
Emergency Trunk Opener . 94
.................................................
Seats . 95
..................................
Seat Heaters . 103
............................
Power Windows . 104
.......................................
Moonroof . 106
...........................................
Mirrors . 108
...............................
Parking Brake . 109
.........
Interior Convenience Items . 110
.....................
Beverage Holders . 111
.............
Console Compartment . 111
..................................
Glove Box . 111
..................................
Coat Hook . 112
........
Accessory Power Sockets . 112
............................
Vanity Mirror . 113
...................................
Sun Visor . 114
...............................
Interior Lights . 114
..............................
Ceiling Light . 114
...................................
Spotlights . 115
..........................
Courtesy Light . 116
Instruments and Controls
Inst rument s and Cont rols
55
TM
Main Menu

Î
Î
Î
Î
ÎÎ ÎÎ
Î
Î
If equipped
:
Control L ocations
56
HEATING/COOLING
CONTROLS
(P.118)
A/T model without navigation system is shown. INSTRUMENT PANEL INDICATORS
MOONROOF SWITCH
HAZARD WARNING BUTTON (P.77) (P.106)
(P.57, 58)
GAUGES
(P.67)
MIRROR CONTROLS
(P.108)
POWER DOOR LOCK
MASTER SWITCH
(P.83)
POWER WINDOW
SWITCHES
(P.104)
(P.144, 153, 196, 207)
SEAT HEATER SWITCHES
(P.103) USB ADAPTER CABLE ACCESSORY POWER
SOCKETS
AUDIO SYSTEM
CLOCK
(P.222)
(P.123)
(P.112)
FUEL FILL DOOR/
TRUNK RELEASE HANDLE
(P.253, 93)
HOOD RELEASE
HANDLE
(P.254)
Main Menu

ÎÎ
Î
Î
Î Î Î
Î
CONT INUED
Canadian DX-G model with M/T has the electric power steering (EPS) indicator (see page 62 ) next to the immobilizer system indicator.
The U.S. instrument panel is shown. Dif f erences f or Canadian models are noted in the text.
Instrument Panel
Inst rument s and Cont rols
DX,LX,EX,EX-L intheU.S.,andDX-G,SE,EX,EX-L inCanada
57
(P.64)
: If equipped
SECURITY SYSTEM INDICATOR
(P.66)
LOW FUEL INDICATOR(P.66)
(P.64)
(P.59, 350)
(P.59, 349)
LOW OIL PRESSURE
INDICATOR (P.61)(P.64)
MAINTENANCE MINDER
INDICATORSUPPLEMENTAL RESTRAINT
SYSTEM INDICATOR
CRUISE MAIN INDICATOR
(P.65)
(P.65)
HIGH BEAM INDICATOR
LIGHTS ON INDICATOR
SIDE AIRBAG OFF
INDICATOR
DAYTIME RUNNING LIGHTS
INDICATOR
VSA ACTIVATION INDICATOR
VEHICLE STABILITY ASSIST (VSA)
SYSTEM INDICATOR
IMMOBILIZER SYSTEM
INDICATOR
CHARGING SYSTEM INDICATOR
(P.59, 349)
MALFUNCTION INDICATOR LAMP ANTI-LOCK BRAKE SYSTEM
INDICATOR
SEAT BELT REMINDER
INDICATOR
TRUNK-OPEN INDICATOR
(P.65)
DOOR-OPEN INDICATOR
(P.65)
(P.60)
(P.64) (P.65) (P.60)
PARKING BRAKE AND BRAKE
SYSTEM INDICATOR
(P.61)
(P.59)
(P.62, 291)
CRUISE CONTROL INDICATOR
(P.60, 351)
(P.63)
TIRE PRESSURE MONITORING
SYSTEM (TPMS) INDICATOR
LOW TIRE PRESSURE
INDICATOR (P.63)
Main Menu

ÎÎ
Î
Î
The U.S. instrument panel is shown. Dif f erences f or Canadian models are noted in the text.
Instrument Panel
Si
58
DOOR-OPEN INDICATOR
SEAT BELT REMINDER
INDICATOR
(P.59, 350) LOW FUEL INDICATOR (P.66)
SECURITY SYSTEM
INDICATOR (P.66)
CRUISE MAIN INDICATOR (P.64)
PARKING BRAKE AND BRAKE
SYSTEM INDICATOR
(P.65)
SUPPLEMENTAL
RESTRAINT SYSTEM
INDICATOR (P.60)
(P.60)
(P.64)
HIGH BEAM INDICATOR
LIGHTS ON INDICATOR
SIDE AIRBAG OFF
INDICATOR
VSA ACTIVATION INDICATOR
FOG LIGHT INDICATOR
DAYTIME RUNNING LIGHTS
INDICATOR
ELECTRIC POWER STEERING
(EPS) INDICATOR
LOW OIL PRESSURE
INDICATOR
CHARGING SYSTEM INDICATOR
(P.59, 349)
MALFUNCTION INDICATOR LAMP (P.65)
(P.65)
(P.65)
(P.64)
(P.62)
(P.59, 349) CRUISE CONTROL
INDICATOR
(P.61)
MAINTENANCE MINDER INDICATOR
IMMOBILIZER SYSTEM
INDICATOR
(P.62, 291)(P.64) (P.65)
TRUNK-OPEN INDICATOR
(P.65)
(P.59)
VEHICLE STABILITY ASSIST
(VSA) SYSTEM INDICATOR (P.60, 351)
REV LIMIT INDICATOR (P.63)
ANTI-LOCK BRAKE
SYSTEM INDICATOR (P.61)
LOW TIRE PRESSURE INDICATOR (P.63)
TIRE PRESSURE
MONITORING SYSTEM
(TPMS) INDICATOR (P.63)If equipped
:
Main Menu

The instrument panel has many
indicators to give you important
inf ormation about your vehicle.If this indicator comes on when the
engine is running, the battery is not
being charged. For more inf ormation,
see page .
The engine can be severely damaged
if this indicator f lashes or stays on
when the engine is running. For
more inf ormation, see page .
See page .
If your f ront passenger does not
f asten their seat belt, the indicator
comes on about 6 seconds af ter the
ignition switch is turned to the ON
(II) position.
If either of you do not f asten your
seat belt while driving, the beeper
will sound and the indicator will f lash
again at regular intervals. For more
inf ormation, see page .
This indicator comes on when you
turn the ignition switch to the ON
(II) position. It reminds you and your
passengers to f asten your seat belts.
A beeper also sounds if you have not
f astened your seat belt.
If you turn the ignition switch to the
ON (II) position bef ore f astening
your seat belt, the beeper sounds
and the indicator f lashes. If you do
notfastenyourseatbeltbeforethe
beeper stops, the indicator stops
f lashing but remains on. 18
349
349
350
Charging System
Indicator
L ow Oil Pressure
Indicator
Seat Belt Reminder
Indicator
Malf unction Indicator
Lamp
Instrument Panel Indicators
Inst rument s and Cont rols
59
Main Menu

This indicator comes on brief ly when
you turn the ignition switch to the
ON (II) position. If it comes on at
any other time, it indicates a
potential problem with your f ront
airbags. This indicator will also alert
you to a potential problem with your
airbag system components. For
more inf ormation, see page .
This indicator has two f unctions:
This indicator comes on brief ly when
you turn the ignition switch to the
ON (II) position. If it comes on at
any other time, it indicates that the
passenger’s side airbag has
automatically shut off. For more
inf ormation, see page .
Itcomesonwhenyouturnthe
ignition switch to the ON (II)
position. It is a reminder to check
the parking brake. A beeper
sounds if you drive with the
parking brake not f ully released.
Driving with the parking brake not
fully released can damage the
brakes and tires.
If it stays on after you have fully
released the parking brake while
the engine is running, or if it
comes on while driving, there
could be a problem with the brake
system. For more inf ormation, see
page .
1. 2.
29
30
351 Supplemental Restraint
System Indicator
Parking Brake
and Brake
System
Indicator Side A irbag Of f
Indicator
Instrument Panel Indicators
60
U.S. Canada
U.S. Canada
