2011 Citroen DS3 Owner's Manual

135Child safety








ISOFIX child seat recommended by CITROËN and approved for
your vehicle
This child seat can also be used on seats which are not fitted with ISOFIX mountings. In this case, it must be attached to the vehicle seat using
the three point seat belt.

Follow the instructions for fitting the child seat given in the seat manufacturer's installation guide.




RÖMER Duo Plus ISOFIX
(size category B1
)


Group 1: from 9 to 18 kg







Installed in the for wards-facing position.
Fitted with an upper strap to be secured on the upper ring B
, referred to as the TOP TETHER.
Three seat body angles: sitting, reclining, lying.

Installing ISOFIX child seats
In accordance with European regulations, this table indicates the options for the installation of ISOFIX child seats on the vehicle seats fitted with
ISOFIX mountings.
In the case of the universal and semi-universal ISOFIX child seats, the child seat's ISOFIX size category, determined by a letter between A
and G
, is
indicated on the child seat next to the ISOFIX logo.

IUF:
seat suitable for the installation of an I
sofix U
niversal seat, " F
or ward facing" and secured using the "Top Tether" upper strap.

IL-SU:
seat suitable for the installation an I
sofix S
emi- U
niversal seat which is:


- "rear facing" fitted with a "Top Tether" upper strap or a stay,

- "for ward facing" fitted with a stay,
For the securing of the "Top Tether" upper strap, refer to the "ISOFIX Mountings" section.

X:
seat which is not suitable for the installation of an ISOFIX seat of the size category indicated.

*
Infant car seats and "car cots" cannot be installed on the front passenger seat.







Weight of the child
/indicative age


Less than 10 kg
(group 0)


Up to 6 months
approx

Less than 10 kg
(group 0)


Less than 13 kg
(group 0+)


Up to 1 year approx

From 9 to 18 kg (group 1)


From 1 to 3 years approx


Type of ISOFIX child seat



Infant car seat

*


"rear facing"



"rear facing"



"forward facing"




ISOFIX size category



F



G



C



D



E



C



D



A



B



B1




Universal and semi-universal ISOFIX child
seats which can be installed on the outer
rear seats



X



X



IL-SU



X



IL-SU



IUF


IL-SU

137Child safety

008
Safety


This section describes the operation of the direction indicators, hazard
warning lamps and the horn to warn other road users, the emergency
or assistance call in the event of an accident or breakdown, the various
braking and trajectory control systems for maintaining control of your
vehicle, the seat belts and airbags to reduce the risk of injury in the event
of a collision.

Direction indicators

Selection of the left or right direction indicators
to signal a change of direction of the vehicle.


)
Left: lower the lighting stalk beyond the
point of resistance.

)
Right: raise the lighting stalk beyond the
point of resistance.







"Motorway" function



)
Press briefly upwards or downwards,
without going beyond the point of
resistance; the direction indicators will flash
3 times.










Hazard warning lamps

A visual warning by means of the direction
indicators to aler t other road users to a vehicle
breakdown, towing or accident.


)
Press this button, the direction indicators
flash.
They can operate with the ignition off.

141Safety












Automatic operation of
hazard warning lamps
When braking in an emergency, depending on
the deceleration, the hazard warning lamps
come on automatically.
They switch off automatically the first time you
accelerate.


)
You can also switch them off by pressing
the button.










Horn


Audible warning to aler t other road users to an
imminent danger.


)
Press one of the spokes of the steering
wheel.
Use the horn moderately and only in
the following cases:


- immediate danger,

- over taking a cyclist or pedestrian

- when approaching an area where
there is no visibility.










Emergency or
assistance call
This system allows you to make an emergency
or assistance call to the emergency ser vices or
to the dedicated CITROËN ser vice.
For more information on the use of this
function, refer to the "Audio and telematics"
section.

Braking assistance systems

Group of supplementary systems which help
you to obtain optimum braking in complete
safety in emergency situations:


- anti-lock braking system (ABS),

- electronic brake force distribution (EBFD),

- emergency braking assistance (EBA).

Anti-lock braking system
and electronic brake force
distribution
Linked systems which improve the stability and
manoeuvrability of your vehicle when braking,
in par ticular on poor or slippery sur faces.

Activation

The anti-lock braking system comes into
operation automatically when there is a risk of
wheel lock.
Normal operation of the ABS may make itself
felt by slight vibration of the brake pedal.

When braking in an emergency, press
very firmly without releasing the
pressure.


Operating fault

If this warning lamp comes on,
together with the STOP
and ABS

warning lamps, accompanied
by an audible signal and a message in the
multifunction screen, it indicates a malfunction
of the electronic brake force distribution which
could result in loss of control of the vehicle
when braking.

You must stop as soon as it is safe to do so.


When replacing wheels (tyres and
rims), ensure that they conform to the
manufacturer's recommendations.
If this warning lamp comes on,
accompanied by an audible signal
and a message in the multifunction
screen, it indicates a malfunction of the anti-
lock braking system which could result in loss
of control of the vehicle when braking.
In either case, contact a CITROËN dealer or a
qualified workshop.
