FITTINGS
111
CIGARETTE LIGHTER/12 V
ACCESSORY SOCKET


)
To use the cigarette lighter, press
it in and wait a few seconds until it
pops out automatically.

)
To connect a 12 V accessory (max
power: 120 W), remove the ciga-
rette lighter and connect a suitable
adaptor.
USB PORT/AUXILIARY SOCKET


The "AUX"
connection box, located in the
centre console, comprises an auxiliary
JACK socket and/or a USB port.
It permits the connection of a portable
device, such as a digital audio player of
the iPod
® or USB memory stick type.
It reads certain audio fi le formats allow-
ing them to be heard via the vehicle's
speakers.
You can manage these fi les using the
steering mounted controls or the audio
system control panel and display them
on the multifunction screen.

For more information on the use of
this equipment, refer to the "Audio and
Telematics" section.
Connected to the USB port, the
portable device charges auto-
matically while in use.
LOWER CENTRE CONSOLE




1.
Storage pocket


2.
Cup holder


3.
Large open storage box

6
FITTINGS
112
SEMI-RAISED CENTRE CONSOLE



1.
Front armrest


(see details on following pages)

2.
Open storage


3.
Cup holder


4.
Storage pocket



RAISED CENTRE CONSOLE




1.
Front armrest


(see details on following pages)

2.
12 V accessory socket


(see details on following pages)

3.
Storage box


4.
Cup holder/Bottle holder


5.
Storage pocket


6.
Large multifunctional storage
unit


(see details on following pages)

6
FITTINGS
11 3
LARGE MULTIFUNCTIONAL STORAGE UNIT


This storage unit is closed by a sliding
shutter.
It contains:


- the USB port and 12 V/auxiliary
sockets 1
,

- a retractable support 2
to receive
your mobile phone or portable de-
vice,

- a space ventilated by a closeable
nozzle 3
, to keep food and drinks
fresh if the air conditioning is oper-
ating.

Comfort and storage system for the
driver and front passenger.
The height and length of the armrest
cover can be adjusted.

Height adjustment



)
Raise the cover to the required po-
sition (low, intermediate or high).

)

If you raise the cover slightly beyond
the high position, guide it when lower-
ing it to the low position.

Longitudinal adjustment



)
Slide the cover fully forwards or
rearwards.

Storage

The storage space in the armrest can
hold up to 6 CDs.
This storage space may be fi tted with a
230 V/50 Hz socket.


)
Raise the lever.

)
Raise the cover fully.
It is illuminated only when the
sliding shutter is fully open.
The sliding shutter can be partly
closed up to the level of the re-
tractable support, so as to keep
the storage unit cool.

6
FITTINGS
114
FRONT ARMREST
Comfort and storage device for the driv-
er and front passenger.
The length of the armrest cover can be
adjusted.

Longitudinal adjustment



)
To move forwards, raise the lever.
The armrest slides forwards to its
stop.

)
To stow it, slide it fully back and
press down to lock it.



Storage

The armrest's compartment can hold
up to 6 CDs.


)
Raise the cover fully.

6
FITTINGS
11 5
230 V/50 HZ POWER SOCKET


A 230 V/50 Hz socket (maximum power:
120 W) is fi tted to the centre console.

To use the socket:


)
lift the front armrest cover for ac-
cess to its compartment,

)
check that the warning lamp is on
green,

)
connect your multimedia or other
electrical device (telephone charger,
laptop computer, CD-DVD player,
baby food warmer...).
This socket works with the engine
running, as well as in STOP mode on
Stop & Start.

)
To connect a 12 V accessory (max
power: 120 W), lift the cover and
connect a suitable adaptor.
12 V ACCESSORY SOCKET

Connect only one device at a
time to the socket (no extension
or multi-way connector).
Connect only devices with class
II insulation (shown on the de-
vice).
As a safety measure, when elec-
trical consumption is high and
when required by the vehicle's
electrical system (particular
weather conditions, electrical
overload...), the current supply
to the socket will be cut off; the
green warning lamp goes off.

In the event of a fault with the socket,
the green warning lamp fl ashes.
Have it checked by a CITROËN dealer
or a qualifi ed workshop.

6
FITTINGS
116
MATS
Removable carpet protection.


Fitting

When fi tting the mat for the fi rst time,
on the driver's side use only the fi xings
provided in the wallet attached.
The other mats are simply placed on
the carpet.


Removal

To remove the mat on the driver's side:


)
move the seat as far back as pos-
sible,

)
unclip the fi xings,

)
remove the mat.



Refitting

To refi t the mat on the driver's side:


)
position the mat correctly,

)
refi t the fi xings by pressing,

)
check that the mat is secured cor-
rectly.

To avoid any risk of jamming of
the pedals:


- only use mats which are
suited to the fi xings already
present in the vehicle; these
fi xings must be used,

- never fi t one mat on top of
another.
The use of mats not approved
by CITROËN may interfere with
access to the pedals and hinder
the operation of the cruise con-
trol/speed limiter.

STORAGE DRAWERS

Located under each front seat, except
for the driver's seat on versions with
electric seat.
Opening


)
Raise the front of the drawer and
pull it open.
Do not place heavy objects in the drawer.
Removal

Avoid removing the drawer completely,
as refi tting it is not easy.


)
Open the drawer fully.

)
Pull the drawer upwards to disen-
gage it.

Refitting

However, if it has been completely re-
moved, to refi t it:


)
use the torch to illuminate the area
under the seat,

)
engage the drawer in its runners,

)
lift the retaining tongues and slide
the drawer under these tongues,

)
at the end of its travel, press down
on the drawer to engage it.

6
FITTINGS
11 7
REAR ARMREST
Comfort system for the rear passengers.


)
Lower the rear armrest for a more
comfortable position.
This also gives access to the ski fl ap.
SKI FLAP

Arrangement for storing and transport-
ing long objects.

Opening



)
Lower the rear armrest.

)
Pull the fl ap handle downwards.

)
Lower the fl ap.

)
Load the objects from inside the
boot.

6
118
BOOT FITTINGS


1.
Rear parcel shelf


(see details on a following page)

2.
Hooks


(see details on a following page)

3.
12 V accessory socket


(see details on a following page)

4.
Torch


(see details on following pages)

5.
Lashing rings


6.
Storage box


(see details on following pages)

7.
Retaining straps


8.
Storage net
