2011 Citroen C4 DAG Owner's Manual

223
EMERGENCY OR ASSISTANCE CALL

224
EMERGENCY OR ASSISTANCE CALL

EMERGENCY CALL
In an emergency, press this button for more than2 seconds. Flashing of the green indicator lamp and a voice message confi rm that the call has been made to the CITROËN Emergency team * .g
Pressing this button again immediately cancels the request. The green
indicator lamp goes off.
A press
(at any time) of more than 8 seconds on this button, cancels
the request.

ASSISTANCE CALL
When the ignition is switched on, the green
indicator lamp comes on for 3 seconds
indicating that the system is operating correctly.


If the orange indicator lamp fl ashes: there
is a system fault.
If the orange indicator lamp is on continuously:
the backup battery must be replaced.
In either case, contact a CITROÀN. Pressin
g this button again immediately cancels the request.
The cancellation is confi rmed b
y a voice message.
Press this button for more than 2 seconds to request
assistance if the vehicle breaks down.
A voice message confi rms that the call has been made *
.


OPERATION OF THE SYSTEM The green indicator lamp remains on (without fl ashing) whencommunication is established. It goes off at the end of communication.
This call is dealt with b
y the CITROÀN Emergency team which receiveslocating information from the vehicle and can send a detailed alert to theappropriate emergency services. In countries in which the team is not
operational, or when the locating service has been expressly declined,
the call is dealt with directly by the emergency services (11 2) without the
vehicle location.

If an impact is detected b
y the airbag ECU, and independentlyof the deployment of any airbags, an emergency call is made
automatically.

* These services are sub
ject to conditions and availability.
Consult a CITROÀN dealer.
If
you purchased your vehicle outside the CITROÀN dealer network,
we invite you to have a dealer check the confi guration of these services
and, if desired, modifi ed to suit your wishes. In a multi-lingual country,confi guration is possible in the offi cial national language of your choice. If you benefi t from the CITROËN eTouch offer, you also have availableadditional services in your MyCITROËN personal space, via the CITROËN y,y
Internet website www.citroen.co.uk.

For technical reasons, particularl
y to improve the quality of telematic services for customers, the manufacturer reserves the right to carry out
updates to the vehicle's on-board telematic system.

225

The system is protected in such a way that it will onlyoperate in your vehicle. If it is to be installed in another vehicle, contact a CITROËN dealer for confi guration of py
the system.
eMyWay


01 First steps - Control panel


For safety reasons, the driver must carry out operations
which require prolonged attention while the vehicle is stationary.
When the en
gine is switched off and to prevent
discharging of the battery, the system switches off following the activation of the energy economy mode.



CONTENTS

02 Steering mounted controls

03 General operation

04 Navigation - Guidance

05 Traffic information

06 Using the telephone

07 Radio

08 Music media players

09 Audio settings

10 Configuration

11 Screen menu map

Frequently asked questions p.
p.
p.
p.
p.
p.
p.
p.
p.
p.
p.
p. 2
26
228
229
231
244
247
257
2
60
266
267
268
271

SATELLITE NAVIGATION SYSTEM
MULTIMEDIA BLUETOOTH TELEPHONE AUDIO
SYSTEM

226
1142
9
3
4
5
67
8
10
111213
01 FIRST STEPS


CONTROL PANEL

Buttons 2, 3, 4, 5, 6 and 12: selection of left or right of the screen, when a Menu is displayed in the screen.

227
01



1. Rotary control:
-
Short press engine not running: on/off.
-
Short press engine running: mute on/off.
- Rotation: volume ad
justment (each source
is independant, including TA messages and navigation information).

2. Radio source, access to the FM/AM band
menu and displa
y the list of stations.

3. Access to the MEDIAmenu and display the list of tracks.

4. A
ccess to the Navigation - guidance
menu and display the last destinations.

5. Access to the Traffi c informationmenu anddisplay the current traffi c alerts.

6. Access to the "Telephone
" menu and displaythe recent calls list.
2 - 3. Lon
g press: access to the Audio settings:music ambiance, bass, treble, loudness,left/right balance, front/rear fader, automatic volume adjustment. 7.
Access to the " Confi guration" menu.
Lon
g press: access to the GPS coverage and
the navigation demonstration mode.
8. MODE button:
Selection of the t
ype of permanent display.
Lon
g press: black screen (DARK).
9. ESC: abandon the operation in pro
gress, upone level in the menu.
Long press: return to permanent display.
10.
CD eject.
Continuous press: reinitialisation of thesystem.
11. Accordin
g to context:
Selection of the previous/next line in a list or
menu
Selection of the previous/next media folder.
Step by step selection of the previous/next
radio frequency.
Move up
/down in Move the map
mode.
12. Accordin
g to context:
Automatic selection o
f the next lower/higher radio frequency

Selection of the previous/next CD or media
track
Selection of left/ri
ght on the screen when a
menu is displayed.
Move left/ri
ght in Move the map mode.

1
3. Buttons 1 to 6:

Short press: selection of the stored radio station.
Lon
g press: store the current radio station.

14. Dial for selection and
OK confi rmation:

Selection of an item on the screen or in alist in a menu, then confi rmation with a shortpress.

Other than for menus and lists, a short press
displays a contextual menu depending on the
current screen.
Rotation with map displa
yed: zoom the mapscale in and out.
FIRST STEPS

228
02 STEERING MOUNTED CONTROLS




- Change the audio source.
Long press: mute.


-
Volume increase.


- V
olume decrease.


- Radio: displa
y the list of stations.
Media: display the list o
f tracks.


-
Rotation

Radio -automatic selection of next/previous frequency.

Media: previous/next track.

- Pr
ess then rotation: access to6 preset stations.





- TEL button:

Access to the telephone menu:

Call list/Contacts/Hands-freemode/Answer/Hang up.

Accept an incoming call/

Long press: reject an incoming callor end the current call.


-
Move in the menus.

Zoom the map in and out
Pr
ess: confi rmation


-
Abandon the current operation.

229
03

For a detailed global view of the menus available, refer to the"Screen menu map" section.


For cleaning the screen, the use of a soft, non-abrasive cloth (spectacles cloth) is recommended, with no additional product. "RADIO
/MEDIA"
"
TELEPHONE"
(If conversation in progress)
SETUP
: PARAMETERS
date and time, display parameters, sound.
Changing the audio source:
RADIO:RADIObroadcasts.
MUSIC :playing MEDIA.
Press the MODE
button several times in succession for access to the following displays:

GENERAL OPERATION
"FULL SCREEN MAP"
"MAP IN WINDOW"

230
03
A press on the OK dial gives access to
short-cut menus according to the display
in the screen.

RADIO:
Activate/Deactivate TA

Activate/Deactivate RDS



GENERAL OPERATION







DISPLAY ACCORDING TO CONTEXT

MUSIC MEDIA PLAYERS,
CD or USB (according to
media):
Play modes:
Normal
Random
Random on all media
Repetition


TELEPHONE (call in
progress):
Private mode


FULL SCREEN MAP OR
IN A NEW WINDOW:
Stop/Restore guidance
Select destination
Enter an address
Directory
GPS coordinates
Divert route
Move the map
Info. on location
Select as destination
Select as sta
ge
Save this place (contacts)
Quit map mode
Guidance criteria


Put call on hold

DTMF rin
g tones

Han
g up1
1
1
1
1
1
1
1
2
2
2
2
2
1
2
2
2
1
1
1
1
1
1
