1. Check voltage between ABS actuator and electric unit (control unit) harness connector E33 and body ground.
2. Check resistance between ABS actuator and electric unit (con- trol unit) harness connector E33 and body ground.
OK or NG
OK >> Perform self-diagnosis again. If the same results appear, replace ABS actuator and electric unit (control
unit). Refer to BRC-89, "
Removal and Installation".
NG >> Repair the circuit.
Actuator Motor, Motor Relay, and Circuit InspectionINFOID:0000000005612165
INSPECTION PROCEDURE
1.CHECKING SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> Inspection End.
2.CONNECTOR INSPECTION
Disconnect the ABS actuator and electr ic unit (control unit) connector.
Check the terminals for deformation, disconnection, looseness or damage.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace as necessary.
3.CHECKING ABS MOTOR AND MOTOR RELAY POWER SYSTEM
1. Check voltage between ABS actuator and electric unit (control unit) harness connector E33 and ground. ABS actuator and electric
unit (control unit) harness connector E33 Body
ground Measured
value
(Approx.)
3 — 12V
WFIA0499E
ABS actuator and electric
unit (control unit) harness connector E33 Body
ground Measured
value
(Approx.)
4—0 Ω
WFIA0500E
Self-diagnosis results
PUMP MOTOR
ABS actuator and electric
unit (control unit) harness connector E33 Body
ground Measured
value
(Approx.)
2 — 12V
WFIA0501E
Revision: January 20102010 Versa

CVT SYSTEMCVT-21
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
Hydraulic Control SystemINFOID:0000000005397772
TCM FunctionINFOID:0000000005397773
The function of the TCM is to:
• Receive input signals sent from various switches and sensors.
• Determine required line pressure, shifting point, and lock-up operation.
• Send required output signals to the step motor and the respective solenoids.
CONTROL SYSTEM OUTLINE
The CVT senses vehicle operating conditions through various sensors. It always controls the optimum shift
position and reduces shifting and lock-up shocks.
AWDIA0768GB
SENSORS (or SIGNAL)
⇒TCM
⇒ACTUATORS
Transmission range switch
Accelerator pedal position signal
Closed throttle position signal
Engine speed signal
CVT fluid temperature sensor
Vehicle speed signal
Overdrive control signal
Stop lamp switch signal
Primary speed sensor
Secondary speed sensor
Secondary pressure sensor Shift control
Line pressure control
Primary pressure control
Secondary pressure control
Lock-up control
Engine brake control
Vehicle speed control
Fail-safe control
Self-diagnosis
CONSULT-III co
mmunication
line
Duet-EA control
CAN system
On board diagnosis Step motor
Torque converter clutch solenoid
valve
Lock-up select solenoid valve
Line pressure solenoid valve
Secondary pressure solenoid
valve
Shift position indicator
O/D OFF indicator lamp
Starter relay
Revision: January 20102010 Versa

CVT-54
< SERVICE INFORMATION >[RE0F08B]
TROUBLE DIAGNOSIS
BRAKE SW (on/off)
XX Stop lamp switch (Signal input with CAN comuni-
cation)
FULL SW (on/off) XX
Signal input with CAN communications
IDLE SW (on/off) XX
SPORT MODE SW (on/off) XX Overdrive control switch (Signal input with CAN
comunication)
STRDWNSW (on/off) X—
Not mounted but displayed.
STRUPSW (on/off)
X—
DOWNLVR (on/off) X—
UPLVR (on/off) X—
NONMMODE (on/off) X—
MMODE (on/off) X—
INDLRNG (on/off) —— “L” position indicator output
INDDRNG (on/off) —— “D” position indicator output
INDNRNG (on/off) —— “N” position indicator output
INDRRNG (on/off) —— “R” position indicator output
INDPRNG (on/off) —— “P” position indicator output
CVT LAMP (on/off) ——
SPORT MODE IND (on/off) ——
MMODE IND (on/off) —— Not mounted but displayed.
SMCOIL D (on/off) —— Step motor coil “D” energizing status
SMCOIL C (on/off) —— Step motor coil “C” energizing status
SMCOIL B (on/off) —— Step motor coil “B” energizing status
SMCOIL A (on/off) —— Step motor coil “A” energizing status
LUSEL SOL OUT (on/off) ——
REV LAMP (on/off) — X
STRTR RLY OUT (on/off) —— Starter relay
LUSEL SOL MON (on/off) ——
STRTR RLY MON (on/off) —— Starter relay
VDC ON (on/off) X—
Not mounted but displayed.
TCS ON (on/off) X—
ABS ON (on/off) X—
ACC ON (on/off) X— Not mounted but displayed.
RANGE —X Indicates position is recognized by TCM. Indi-
cates a specific value required for control when
fail-safe function is activated.
M GEAR POS —X
Monitored item (Unit)
Monitor item selection
Remarks
ECU IN-
PUT SIG- NALS MAIN SIG-
NALS SELEC-
TION
FROM
MENU
Revision: January 20102010 Versa

EC-5
C
DE
F
G H
I
J
K L
M
EC A
N
O P
