< SERVICE INFORMATION >[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Monitor item
Display content Data monitor
Note: Error inspection
checklist
Condition Reference value in
normal operation
FR LH SENSOR
FR RH SENSOR
RR LH SENSOR
RR RH SENSOR Wheel speedVehicle stopped
0 [km/h (mph)]
BRC-67, "
Wheel Sensor
System Inspection"Vehicle running (Note 1) Almost in accor-
dance with speed-
ometer display
(within
±10%)
FR RH IN SOL
FR RH OUT SOL
FR LH IN SOL
FR LH OUT SOL
RR RH IN SOL
RR RH OUT SOL
RR LH IN SOL
RR LH OUT SOL Solenoid valve opera-
tionActuator (solenoid) is active
(“ACTIVE TEST” with CON-
SULT-III) or actuator relay is in-
active (in fail-safe mode).
On
BRC-72, "
Solenoid and
VDC Change-Over Valve
System Inspection"When actuator (solenoid) is not
active and actuator relay is ac-
tive (ignition switch ON). Off
STOP LAMP SW Brake pedal operation Brake pedal depressed On
BRC-74, "
Stop Lamp
Switch System Inspec-
tion"Brake pedal releasedOff
MOTOR RELAY Operation status of mo-
tor and motor relayIgnition switch ON or engine
running (ABS not operated)
Off
BRC-73, "
Actuator Motor,
Motor Relay, and Circuit
Inspection"
Ignition switch ON or engine
running (ABS operated) On
ACTUATOR RLY Actuator relay opera-
tion statusVehicle stopped (Ignition
switch ON)
Off
Vehicle stopped (Engine run-
ning) On
ABS WARN LAMP ABS warning lamp ON
condition (Note 2)ABS warning lamp ON On
BRC-83, "
ABS Warning
Lamp Does Not Come On
When Ignition Switch Is
Turned On"ABS warning lamp OFF Off
OFF LAMP VDC OFF indicator
lamp status (Note 2) When VDC OFF indicator
lamp is ON
On
BRC-79, "
CAN Commu-
nication System Inspec-
tion"When VDC OFF indicator
lamp is OFF Off
OFF SW VDC OFF switch
ON/OFF status VDC OFF switch ON
(When VDC OFF indicator
lamp is ON)
On
BRC-79, "
Component In-
spection"VDC OFF switch OFF
(When VDC OFF indicator
lamp is OFF) Off
SLIP LAMP SLIP indicator lamp
status (Note 2)When SLIP indicator lamp is
ON
On
BRC-79, "
CAN Commu-
nication System Inspec-
tion"When SLIP indicator lamp is
OFF Off
BATTERY VOLT Battery voltage sup-
plied to ABS actuator
and electric unit (con-
trol unit)Ignition switch ON
10 to 16VBRC-75, "
ABS/TCS/VDC
Control Unit Power and
Ground Systems Inspec-
tion"
GEAR
Manual mode gear po-
sition determined by
TCMIgnition switch ON 1
2
3
4
5—
YAW RATE SEN Yaw rate detected by
yaw rate/side G sensorVehicle stopped
Approx. 0 d/sBRC-70, "
Yaw Rate/Side/
Decel G Sensor System
Inspection"Vehicle turning –75 to 75 d/s
Revision: January 20102010 Versa

BRC-60
< SERVICE INFORMATION >[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Note 1: Confirm tire pressure is normal.
Note 2: On and Off timing for warning lamp and indicator lamp.
CONSULT-III Function (ABS)INFOID:0000000005612158
CONSULT-III can display each diagnostic item us
ing the diagnostic test modes shown following.
SELF-DIAGNOSIS
Description
If an error is detected in the system, the ABS warning lamp will turn on. In this case, perform self-diagnosis as
follows:
Operation Procedure
1. Turn ignition switch OFF.
2. Connect CONSULT-III To the data link connector.
3. Turn ignition switch ON.
4. Start engine and drive at approximately 30 km/h (19 MPH) for approximately 1 minute.
5. After stopping the vehicle, with the engine running, t ouch “ABS”, “SELF-DIAG RESULTS” in order on the
CONSULT-III screen.
USV[FL-RR]
USV[FR-RL]
HSV[FL-RR]
HSV[FR-RL] VDC switch-over valve
statusWhen actuator (switch-over
valve) is active (“ACTIVE
TEST” with CONSULT-III) or
actuator relay is inactive (when
in fail-safe mode).
On
BRC-72, "
Solenoid and
VDC Change-Over Valve
System Inspection"
When actuator (switch-over
valve) is not active and actua-
tor relay is active (ignition
switch ON). Off
V/R OUPUT Solenoid valve relay
activatedWhen solenoid valve relay is
active (ignition switch OFF)
On
When solenoid valve relay is
not active (in fail-safe mode) Off
M/R OUTPUT Actuator motor and mo-
tor relay activatedWhen actuator motor and mo-
tor relay are active (“ACTIVE
TEST” with CONSULT-III)
On
BRC-73, "
Actuator Motor,
Motor Relay, and Circuit
Inspection"When actuator motor and mo-
tor relay are inactive Off
ENGINE RPM With engine running With engine stopped
0 rpm
BRC-68, "
Engine System
Inspection"Engine running Almost in accor-
dance with ta-
chometer display
Monitor item
Display content Data monitor
Note: Error inspection
checklist
Condition Reference value in
normal operation
ABS diagnostic mo de Description
WORK SUPPORT Supports inspection and adjustment
s. Commands are transmitted to the ABS actuator and electric unit
(control unit) for setting the status suitable for required operation, input/output signals are received from
the ABS actuator and electric unit (control unit) and received data is displayed.
SELF DIAGNOSTIC RESULT Displays ABS ac tuator and electric unit (control unit) self-diagnosis results.
DATA MONITOR Displays ABS actuator and electric unit (control unit) input/output data in real time.
CAN DIAG SUPPORT MNTR The result of transmit/receive diagnosis of CAN communication can be read. ACTIVE TEST Operation of electrical loads can be checked by sending drive signal to them.
FUNCTION TEST Conducted by CONS ULT-III instead of a technician to determine whether each system is "OK" or "NG".
ECU IDENTIFICATION ABS actuator and electric unit (control unit) part number can be read.
Revision: January 20102010 Versa

TROUBLE DIAGNOSISBRC-61
< SERVICE INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
6. The self-diagnostic results are displayed. • When “NO DTC IS DETECTED” is displayed, check the ABS warning lamp, SLIP indicator lamp and
VDC OFF indicator lamp.
7. Conduct the appropriate inspection from the display item list, and repair or replace the malfunctioning
component.
8. Start engine and drive at approximately 30 km /h (19 MPH) for approximately 1 minute.
CAUTION:
• When a wheel sensor “short-circuit” is detected, if the vehicle is not driven at 30 km/h (19 MPH)
for at least 1 minute, the ABS warn ing lamp will not turn off even if the malfunction is repaired.
9. Turn ignition switch OFF to prepare for erasing the memory.
10. Start the engine and touch “ABS”, “SELF-DIAG RESULTS”, “ERASE” in order on the CONSULT-III screen to erase the error memory.
If “ABS” is not indicated, go to GI-36, "
CONSULT-III Data Link Connector (DLC) Circuit".
CAUTION:
If the error memory is not erased, re -conduct the operation from step 5.
11. For the final inspection, drive at approximately 30 km/h (19 MPH) for approximately 1 minute and confirm
that the ABS warning lamp, SLIP indicator lamp, and VDC OFF indicator lamp are off.
Display Item List
Self-diagnostic item Malfunction detecting condition Check system
RR RH SENSOR 1
[C1101] Circuit of rear RH wheel sensor is open.
BRC-67, "
Wheel Sensor
System Inspection"
(Note 1)
RR LH SENSOR 1
[C1102]
Circuit of rear LH wheel sensor is open.
FR RH SENSOR 1
[C1103] Circuit of front RH wheel sensor is open.
FR LH SENSOR 1
[C1104] Circuit of front LH wheel sensor is open.
RR RH SENSOR 2
[C1105] Circuit of rear RH wheel sensor is shorted, or sensor power volt-
age is unusua
l. ABS actuator and electric unit (control unit) cannot
identify sensor pulses, because of large gap between wheel sen-
sor and sensor rotor.
RR LH SENSOR 2
[C1106] Circuit of rear LH wheel sensor is shorted, or sensor power volt-
age is unusua
l. ABS actuator and electric unit (control unit) cannot
identify sensor pulses, because of large gap between wheel sen-
sor and sensor rotor.
FR RH SENSOR 2
[C1107] Circuit of front RH wheel sensor is shorted, or sensor power volt-
age is unusua
l. ABS actuator and electric unit (control unit) cannot
identify sensor pulses, because of large gap between wheel sen-
sor and sensor rotor.
FR LH SENSOR 2
[C1108] Circuit of front LH wheel sensor is shorted, or sensor power volt-
age is unusua
l. ABS actuator and electric unit (control unit) cannot
identify sensor pulses, because of large gap between wheel sen-
sor and sensor rotor.
BATTERY VOLTAGE
[ABNORMAL]
[C1109] ABS actuator and electric unit (con
trol unit) power voltage is too
low. BRC-75, "
ABS/TCS/VDC
Control Unit
Power and
Ground Systems Inspec-
tion"
CONTROLLER FAILURE
[ C 111 0 ] Internal malfunction of ABS actuat
or and electric unit (control
unit). BRC-68, "ABS/TCS/VDC
Control Unit Inspection"
PUMP MOTOR
[ C 1111 ]During actuator motor operation with ON, when actuator motor
turns OFF or when control line fo
r actuator motor relay is open. BRC-73, "Actuator Mo-
tor, Motor Relay, and Cir-
cuit Inspection"During actuator motor operation with OFF, when actuator motor
turns ON or when control line for relay is shorted to ground.
Revision: January 20102010 Versa

BRC-62
< SERVICE INFORMATION >[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
MAIN RELAY
[ C 111 4 ]During actuator relay OFF, when the actuator relay turns ON, or
when the control line for the relay is shorted to ground.
BRC-72, "Solenoid and
VDC Change-Over Valve
System Inspection"During actuator relay ON, when the actuator relay turns ON, or
when the control line for the relay is open.
ABS SENSOR
[ABNORMAL SIGNAL]
[ C 111 5 ] When wheel sensor input signal is malfunctioning. BRC-67, "
Wheel Sensor
System Inspection"
(NOTE 1)
STOP LAMP SW
[ C 111 6 ] Stop lamp switch or circuit malfunction. BRC-74, "
Stop Lamp
Switch System Inspec-
tion"
FR LH IN ABS SOL
[C1120]
Circuit of front LH IN ABS solenoid
is open or shorted, or control
line is open or shorted to power supply or ground.
BRC-72, "
Solenoid and
VDC Change-Over Valve
System Inspection"
FR LH OUT ABS SOL
[C1121]Circuit of front LH OUT ABS solenoid is open or shorted, or control
line is open or shorted to power supply or ground.
FR RH IN ABS SOL
[C1122] Circuit of front RH IN ABS solenoid is open or shorted, or control
line is open or shorted to power supply or ground.
FR RH OUT ABS SOL
[C1123] Circuit of front RH OUT ABS solenoid is open or shorted, or con-
trol line is open or shorted to power supply or ground.
RR LH IN ABS SOL
[C1124] Circuit of rear LH IN ABS solenoid
is open or shorted, or control
line is open or shorted to power supply or ground.
RR LH OUT ABS SOL
[C1125] Circuit of rear LH OUT ABS solenoid is open or shorted, or control
line is open or shorted to power supply or ground.
RR RH IN ABS SOL
[C1126] Circuit of rear RH IN ABS solenoid
is open or shorted, or control
line is open or shorted to power supply or ground.
RR RH OUT ABS SOL
[C1127] Circuit of rear RH OUT ABS solenoid is open or shorted, or control
line is open or shorted to power supply or ground.
ENGINE SIGNAL 1
[C1130] ECM judges th
e communication between ABS/TCS/VDC control
unit and ECM is abnormal.
BRC-68, "
Engine System
Inspection"
ENGINE SIGNAL 2
[C1131]ECM judges th
e communication between ABS/TCS/VDC control
unit and ECM is abnormal.
ENGINE SIGNAL 3
[C1132] ECM judges th
e communication between ABS/TCS/VDC control
unit and ECM is abnormal.
ENGINE SIGNAL 4
[C1133] ECM judges th
e communication between ABS/TCS/VDC control
unit and ECM is abnormal.
ENGINE SIGNAL 6
[C1136] ECM judges th
e communication between ABS/TCS/VDC control
unit and ECM is abnormal.
PRESS SEN CIRCUIT
[C1142] Pressure sensor signal line is open or shorted, or pressure sensor
is malfunctioning. BRC-77, "
Pressure Sen-
sor System Inspection"
ST ANGLE SEN CIRCUIT
[C1143]Neutral position of steering angle sensor is dislocated, or steering
angle sensor is malfunctioning.
BRC-69, "Steering Angle
Sensor System Inspec-
tion"ST ANGLE SEN SIGNAL
[C1144]Neutral position correction of steering angle sensor is not finished.
YAW RATE SENSOR
[C1145] Yaw rate sensor has generated an error, or yaw rate sensor signal
line is open or shorted.
BRC-70, "
Yaw Rate/
Side/Decel G Sensor
System Inspection"SIDE G-SEN CIRCUIT
[C1146]Lateral G-sensor is malfunctioning, or signal line of lateral G-sen-
sor is open or shorted.
Self-diagnostic item Malfunction detecting condition Check system
Revision: January 20102010 Versa

BRC-64
< SERVICE INFORMATION >[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
FR LH OUT SOL
(On/Off)—
×× Front LH OUT ABS solenoid (On/Off) status is dis-
played.
RR RH IN SOL
(On/Off) —
×× Rear RH IN ABS solenoid (On/Off) status is dis-
played.
RR RH OUT SOL
(On/Off) —
×× Rear RH OUT ABS solenoid (On/Off) status is dis-
played.
RR LH IN SOL
(On/Off) —
×× Rear LH IN ABS solenoid (On/Off) status is dis-
played.
RR LH OUT SOL
(On/Off) —
×× Rear LH OUT ABS solenoid (On/Off) status is dis-
played.
STOP LAMP SW
(On/Off) ×××
Stop lamp switch (On/Off) status is displayed.
MOTOR RELAY
(On/Off) —
×× ABS motor relay signal (On/Off) status is dis-
played.
ACTUATOR RLY
(On/Off) —
×× ABS actuator relay signal (On/Off) status is dis-
played.
ABS WARN LAMP
(On/Off) —
×× ABS warning lamp (On/Off) status is displayed.
OFF LAMP
(On/Off) —
×× VDC OFF lamp (On/Off) status is displayed.
OFF SW
(On/Off) ×××
VDC OFF switch (On/Off) status is displayed.
SLIP LAMP
(On/Off) —
×× SLIP indicator lamp (On/Off) status is displayed.
BATTERY VOLT
(V) ××× Voltage (V) supplied to ABS actuator and electric
unit (control unit) is displayed.
GEAR
(1, 2, 3, 4) ××× A/T gear position (1, 2, 3, 4) determined by TCM
is displayed.
YAW RATE SEN
(d/s) ×××
Yaw rate (d/s) detected by yaw rate sensor is dis-
played.
ACCEL POS SIG
(%) ×
— ×Throttle valve open/close (%) status judged by
CAN communication signal is displayed.
SIDE G-SENSOR
(m/s
2) ×
— ×Lateral acceleration (m/s
2) detected by side G
sensor is displayed.
STR ANGLE SIG
(deg) ×
— ×Steering angle (deg) detected by steering angle
sensor is displayed.
PRESS SENSOR
(bar) ×
— ×Brake fluid pressure detected by pressure sensor
is displayed.
EBD SIGNAL
(On/Off) ——
×EBD operation (On/Off) status is displayed.
ABS SIGNAL
(On/Off) ——
×ABS operation (On/Off) status is displayed.
TCS SIGNAL
(On/Off) ——
×TCS operation (On/Off) status is displayed.
VDC SIGNAL
(On/Off) ——
×VDC operation (On/Off) status is displayed.
EBD FAIL SIG
(On/Off) ——
×EBD fail signal (On/Off) status is displayed.
ABS FAIL SIG
(On/Off) ——
×ABS fail signal (On/Off) status is displayed.
TCS FAIL SIG
(On/Off) ——
×TCS fail signal (On/Off) status is displayed.
VDC FAIL SIG
(On/Off) ——
×VDC fail signal (On/Off) status is displayed.
Revision: January 20102010 Versa

TROUBLE DIAGNOSISBRC-65
< SERVICE INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
× : Applicable
–: Not applicable
ACTIVE TEST
CAUTION:
• Do not perform active test while driving vehicle.
• Make sure to completely bleed air from brake system.
• The active test cannot be performed with the AB S warning lamp, VDC indicator lamp, SLIP indicator
lamp or brake warning lamp on.
• ABS warning lamp, VDC OFF indicator lamp, SLIP indicator lamp and brake warning lamp are on
during active test.
NOTE:
• When active test is performed while depressing the pedal, the pedal depression amount will change. This is normal. (Only solenoid valve and ABS motor)
• “TEST IS STOPPED” is displayed 10 seconds after operation start.
• After “TEST IS STOPPED” is displayed, to perform test again, touch BACK.
Test Item
SOLENOID VALVE
• When performing an active test of the ABS function, select “MAIN SIGNALS” for each test item.
• For ABS solenoid valve, touch “Up”, “Keep”, and “Dow n” on the display screen. For ABS solenoid valve
(ACT), touch “Up”, “ACT UP ”, “ACT KEEP” and confirm that solenoid valves operate as shown in the table
below.
CRANKING SIG
(On/Off) ——
×Cranking condition (On/Off) status is displayed.
FLUID LEV SW
(On/Off) ×
— ×Brake fluid level switch (On/Off) status is dis-
played.
PARK BRAKE SW
(On/Off) ×
— ×Parking brake switch (On/Off) status is displayed.
USV[FL-RR]
(On/Off) ——
×Primary side USV solenoid valve (On/Off) status is
displayed.
USV[FR-RL]
(On/Off) ——
×Secondary side USV solenoid valve (On/Off) sta-
tus is displayed.
HSV[FL-RR]
(On/Off) ——
×Primary side HSV solenoid valve (On/Off) status is
displayed.
HSV[FR-RL]
(On/Off) ——
×Secondary side HSV solenoid valve (On/Off) sta-
tus is displayed.
V/R OUTPUT
(On/Off) ——
×Valve relay operation signal (On/Off) status is dis-
played.
M/R OUTPUT
(On/Off) ——
×Motor relay operation signal (On/Off) status is dis-
played.
ENGINE RPM
(rpm) ×
— ×Engine speed judged by CAN communication sig-
nal is displayed.
Operation ABS solenoid va
lve ABS solenoid valve (ACT)
Up Keep Down Up ACT UP ACT KEEP
FR RH SOL FR RH IN SOL Off On On — —
—
FR RH OUT SOL Off Off On* — — —
USV [FR-RL] Off Off On* — — —
HSV [FR-RL] Off Off On* — — —
FR LH SOL FR LH IN SOL Off On On — —
—
FR LH OUT SOL Off Off On* — — —
USV [FL-RR] Off Off On* — — —
HSV [FL-RR] Off Off On* — — —
Revision: January 20102010 Versa

BRC-66
< SERVICE INFORMATION >[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
*: On for 1 to 2 seconds after the touch, and then Off
ABS MOTOR
• Touch “On” and “Off” on screen. Make sure motor rela
y, actuator relay, V/R output and M/R output operate
as shown in table below.
RR RH SOL RR RH IN SOL Off On On — —
—
RR RH OUT SOL Off Off On* — — —
USV [FL-RR] Off Off On* — — —
HSV [FL-RR] Off Off On* — — —
RR LH SOL RR LH IN SOL Off On On — —
—
RR LH OUT SOL Off Off On* — — —
USV [FR-RL] Off Off On* — — —
HSV [FR-RL] Off Off On* — — —
FR RH ABS SOLENOID (ACT) FR RH IN SOL — — — Off Off Off
FR RH OUT SOL — — — Off Off Off
USV [FR-RL]
— — — Off On On
HSV [FR-RL] — — — Off On* Off
FR LH ABS SOLENOID (ACT) FR LH IN SOL — — — Off Off Off
FR LH OUT SOL — — — Off Off Off
USV [FL-RR]
— — — Off Off Off
HSV [FL-RR] — — — Off Off Off
RR RH ABS SOLENOID (ACT) RR RH IN SOL — — — Off Off Off
RR RH OUT SOL — — — Off Off Off
USV [FL-RR]
— — — Off Off Off
HSV [FL-RR] — — — Off Off Off
RR LH ABS SOLENOID (ACT) RR LH IN SOL — — — Off Off Off
RR LH OUT SOL — — — Off Off Off
USV [FR-RL]
— — — Off On On
HSV [FR-RL] — — — Off On* Off
Operation
ABS solenoid valve
ABS solenoid valve (ACT)
Up Keep Down Up ACT UP ACT KEEP
Operation OnOff
MOTOR RELAY OnOff
ACTUATOR RLY OnOn
Revision: January 20102010 Versa

BRC-72
< SERVICE INFORMATION >[VDC/TCS/ABS]
TROUBLE DIAGNOSIS FOR
SELF-DIAGNOSTIC ITEMS
2. Select “YAW RATE SEN”, “SIDE G-SENSOR” in “Data Monitor” and check Yaw rate/side/decel G sensor
signal.
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-89, "Removal and Installa-
tion".
NO >> Replace Yaw rate/side/decel G sensor. Refer to BRC-92, "
Removal and Installation".
Solenoid and VDC Change-Over Valve System InspectionINFOID:0000000005612164
INSPECTION PROCEDURE
1.SELF-DIAGNOSIS RESULT CHECK
Check self-diagnosis results.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> Inspection End.
2.CONNECTOR INSPECTION
1. Disconnect ABS actuator and electric unit (control unit) connector.
2. Check the terminals for deformati on, disconnection, looseness or damage.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace as necessary.
3.CHECKING SOLENOID POWER AND GROUND
Vehicle condition Yaw rate sensor (Data monitor) Side G sensor (Data monitor)
Stopped Approx. 0 d/s
Approx. 0 m/s
2
Turning right Negative valueNegative value
Turning left Positive valuePositive value
Self-diagnosis results
FR LH IN ABS SOL
FR LH OUT ABS SOL RR RH IN ABS SOL
RR RH OUT ABS SOL FR RH IN ABS SOL
FR RH OUT ABS SOL RR LH IN ABS SOL
RR LH OUT ABS SOL USV LINE [FL-RR]
USV LINE [FR-RL]
HSV LINE [FL-RR]
HSV LINE [FR-RL] MAIN RELAY
Revision: January 20102010 Versa
