2010 JAGUAR XFR Engine

Published: 11-May-2011
Electronic Engine Controls - V8 S/C 5.0L Petrol - Manifold Absolute Pressure
(MAP) Sensor
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details.

1. Refer to: Engine Cover - V8 5.0L Petrol/V8 S/C 5.0L Petrol (501-05 Interior Trim and Ornamentation, Removal and Installation).

2. Refer to: Cowl Vent Screen (501-02 Front End Body Panels, Removal and Installation).


3. NOTE: Some variation in the illustrations may occur, but
the essential information is always correct.
Torque: 10 Nm




















4. NOTE: Some variation in the illustrations may occur,
but the essential information is always correct.

Installation 7. NOTE: Some variation in the illustrations may occur,
but the essential information is always correct.

Torque: 5 Nm
1. To install, reverse the removal procedure.


2. NOTE: For NAS vehicles only.
If required, carry out a short drive cycle.

Refer to: Powertrain Control Module (PCM) Short Drive Cycle Self-Test (303-14D Electronic Engine Controls - V8 S/C 5.0L Petrol, General
Procedures).

Published: 11-May-2011
Electronic Engine Controls - V8 S/C 5.0L Petrol - Mass Air Flow (MAF) Sensor
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details.

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
2.
Installation

1. To install, reverse the removal procedure.


2. NOTE: For NAS vehicles only.

If required, carry out a short drive cycle.

Refer to: Powertrain Control Module (PCM) Short Drive Cycle Self-Test (303-14D Electronic Engine Controls - V8 S/C 5.0L Petrol, General
Procedures). www.JagDocs.com

Published: 11-May-2011
Electronic Engine Controls - V8 S/C 5.0L Petrol - Rear Knock Sensor (KS) LH
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details.

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).


2. WARNING: Do not work on or under a vehicle supported only by a jack.
Always support the vehicle on safety stands.
Raise and support the vehicle.

3. Refer to: Supercharger (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).




Installation

4. Torque: 20 Nm
1. To install, reverse the removal procedure.

Published: 11-May-2011
Electronic Engine Controls - V8 S/C 5.0L Petrol - Rear Knock Sensor (KS) RH
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details.

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).


2. WARNING: Do not work on or under a vehicle supported only by a jack.
Always support the vehicle on safety stands.
Raise and support the vehicle.

3. Refer to: Supercharger (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).




Installation

4. Torque: 20 Nm
1. To install, reverse the removal procedure.

Published: 11-May-2011
Electronic Engine Controls - V8 S/C 5.0L Petrol - Variable Valve Timing (VVT)
Oil Control Solenoid LH
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details.

1. Disconnect the battery ground cable.

Refer to: Specifications (414-00, Specifications).


2. WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.

3. Refer to: Thermostat Housing - Vehicles With: Supercharger (303-03,
Removal and Installation).


4. NOTE: Some variation in the illustrations may occur, but
the essential information is always correct.
Torque: 10 Nm












5. CAUTION: Evenly and progressively, remove the VVT
units from each side.


NOTE: Some variation in the illustrations may occur,
but the essential information is always correct.

Installation

1. CAUTION: Make sure that the mating faces are clean and free of
foreign material.


NOTE: Lubricate the O-ring seal with clean engine oil.
To install, reverse the removal procedure.


2. NOTE: For NAS vehicles only.
If required, carry out a short drive cycle.

Refer to: Powertrain Control Module (PCM) Short Drive Cycle Self-Test (303-14D Electronic Engine Controls - V8 S/C 5.0L Petrol, General
Procedures).

Published: 11-May-2011
Electronic Engine Controls - V8 S/C 5.0L Petrol - Variable Valve Timing (VVT)
Oil Control Solenoid RH
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details.

1. Disconnect the battery ground cable.

Refer to: Specifications (414-00, Specifications).


2. WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.

3. Refer to: Thermostat Housing - Vehicles With: Supercharger (303-03,
Removal and Installation).


4. NOTE: Some variation in the illustrations may occur, but
the essential information is always correct.















5. NOTE: Some variation in the illustrations may occur,
but the essential information is always correct.

Torque: 10 Nm www.JagDocs.com
