2010 JAGUAR XFR Engine

Some variation in the illustrations may occur, but the essential information is always correct.

1. Disconnect the battery ground cable.

Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).


2. WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.

3. Refer to: Timing Cover (303-01C Engine - V8 5.0L Petrol, Removal and Installation).

4.
5. CAUTION: Only rotate the crankshaft clockwise.
Install the special tool.

Special Tool(s): 303-1447

10.




































11. Make sure the tensioner piston is fully extended. Then fully
depress and lock the tensioner piston with the grenade pin
before installation, failure to do this may result in damage
to the engine.

































CAUTION: Do not release the timing chain tensioner
locking pin at this stage.
Torque: 10 Nm

15.




































16. Make sure the tensioner piston is fully extended. Then fully
depress and lock the tensioner piston with the grenade pin
before installation, failure to do this may result in damage
to the engine.

































CAUTION: Do not release the timing chain tensioner
locking pin at this stage.
Torque: 10 Nm

32.
Remove the special tool.
Special Tool(s): 303-1448











33. Rotate the engine two complete turns clockwise.


34.
















35. CAUTION: Only rotate the crankshaft clockwise.
Install the special tool.
Special Tool(s): 303-1447













Install the special tool.
Special Tool(s): 303-1448

42.
43.
Remove the special tool.
Special Tool(s): 303-1447














Torque: 10 Nm













44.
Refer to: Timing Cover (303-01C Engine - V8 5.0L Petrol, Removal and Installation).

45. Connect the battery ground cable.

Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

Engine - V8 S/C 5.0L Petrol - Valve Cover LH
Removal and Installation Published: 11-May-2011


Removal


NOTE: Removal steps in this procedure may contain installation details.

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

2. Refer to: Supercharger (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).

3. Refer to: Secondary Bulkhead Panel LH - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol (501-02 Front End Body Panels, Removal and Installation).

4. Refer to: Air Cleaner Outlet Pipe LH (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).

5. Refer to: Fuel Rail LH (303-04E Fuel Charging and Controls - V8 S/C 5.0L Petrol, Removal and Installation).

6. Torque: 10 Nm 303-1446
Valve Cover Alignment Tool Special Tool(s)

Engine - V8 S/C 5.0L Petrol - Valve Cover RH
Removal and Installation Published: 11-May-2011


Removal


NOTE: Removal steps in this procedure may contain installation details.

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

2. Refer to: Supercharger (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).

3. Refer to: Secondary Bulkhead Panel RH - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol (501-02 Front End Body Panels, Removal and Installation).

4. Refer to: Air Cleaner Outlet Pipe RH (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).

5. Refer to: Fuel Rail RH (303-04E Fuel Charging and Controls - V8 S/C 5.0L Petrol, Removal and Installation).


6. NOTE: Some variation in the illustrations may occur, but
the essential information is always correct. 303-1446
Valve Cover Alignment Tool Special Tool(s) www.JagDocs.com

Engine - V8 S/C 5.0L Petrol - Cylinder Block Oil Gallery Plug
Removal and Installation

Removal

NOTES:


Removal steps in this procedure may contain installation details.


Some variation in the illustrations may occur, but the essential information is always correct. Published: 23-Jul-2011

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).


2. WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.

3. Refer to: Exhaust Manifold RH (303-01C Engine - V8 5.0L Petrol, Removal and Installation).

4.
