Page 1009 of 3039
23.
24.
25. Loosen the Torx screws half a turn each.
CAUTIONS:
Install new high-pressure fuel supply lines.
Lubricate only the union threads with clean engine oil.
NOTES:
Remove and discard the blanking caps.
Install the bolt and unions fully finger tight before final tightening.
Page 1017 of 3039
49. CAUTIONS:
Install all the bolts finger tight before final tightening.
The bolts can only be used 3 times, mark the bolts with a center punch.
If 2 punch marks are visible, discard the bolts.
Install the bolts in the noted position.
NOTES:
Make sure that the crankshaft is not rotated.
Make sure the crankshaft and flexplate mating faces are clean before
installation.
Tighten the retaining bolts working diagonally.
Torque:
Stage 1:45 Nm Stage 2:90°
50. Refer to: Engine (303-01D Engine - V8 S/C 5.0L Petrol, Installation).
51. Refer to: Crankshaft Pulley (303-01D Engine - V8 S/C 5.0L Petrol, Removal and Installation).
52. Lower the vehicle.
53. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
Page 1018 of 3039
Engine - V8 S/C 5.0L Petrol - Oil Pump
Removal and Installation
Removal Published: 07-Oct-2011
1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
2. WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.
3. Refer to: Oil Pan Extension (303-01C Engine - V8 5.0L Petrol, Removal and Installation).
4. NOTE: Tsubaki timing drive only.
5. NOTE: INA timing drive only.
Page 1024 of 3039
9. CAUTION: Make sure that the tensioner spring is
correctly located.
NOTE: INA timing drive only.
Torque: 21 Nm
10. Refer to: Oil Pan Extension (303-01C Engine - V8 5.0L Petrol, Removal and Installation).
11. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
Page 1025 of 3039
Engine - V8 S/C 5.0L Petrol - Timing Cover
Removal and Installation
Removal
NOTE: Removal steps in this procedure may contain installation details. Published: 12-Sep-2011
1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
2. WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.
3. Refer to: Accessory Drive Belt (303-05D Accessory Drive - V8 S/C 5.0L Petrol, Removal and Installation).
4. Refer to: Accessory Drive Belt Tensioner (303-05D Accessory Drive - V8 S/C 5.0L Petrol, Removal and Installation).
5. Refer to: Thermostat Housing - Vehicles With: Supercharger (303-03C Engine Cooling - V8 5.0L Petrol/V8 S/C 5.0L Petrol, Removal and
Installation).
6. Refer to: Valve Cover LH (303-01D Engine - V8 S/C 5.0L Petrol, Removal and Installation).
7. Refer to: Valve Cover RH (303-01D Engine - V8 S/C 5.0L Petrol, Removal and Installation).
8. Refer to: Crankshaft Pulley (303-01D Engine - V8 S/C 5.0L Petrol, Removal and Installation).
9. NOTE: Engine shown removed for clarity.
Page 1026 of 3039
10.
11.
12. NOTE: Engine shown removed for clarity.
NOTE: Engine shown removed for clarity.
NOTE: Engine shown removed for clarity. www.JagDocs.com
Page 1031 of 3039
12.
Refer to: Crankshaft Pulley (303-01D Engine - V8 S/C 5.0L Petrol, Removal and Installation).
13. Refer to: Valve Cover RH (303-01D Engine - V8 S/C 5.0L Petrol, Removal and Installation).
14. Refer to: Valve Cover LH (303-01D Engine - V8 S/C 5.0L Petrol, Removal and Installation).
15. Refer to: Thermostat Housing - Vehicles With: Supercharger (303-03C Engine Cooling - V8 5.0L Petrol/V8 S/C 5.0L Petrol, Removal and
Installation).
16. Refer to: Accessory Drive Belt Tensioner (303-05D Accessory Drive - V8 S/C 5.0L Petrol, Removal and Installation).
17. Refer to: Accessory Drive Belt (303-05D Accessory Drive - V8 S/C 5.0L Petrol, Removal and Installation).
18. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures). www.JagDocs.com
Page 1032 of 3039
Engine - V8 S/C 5.0L Petrol - Timing Drive Components
Removal and Installation
Special Tool(s)
303-1445
Timing Tool – Camshaft Alignment
303-1447
Timing Tool
303-1448
Locking Tool
303-1452
Camshaft Rotating Tool
303-1482
Tensioner Tool Removal
CAUTION: Check all timing components for wear and install new components if required.
NOTES:
Removal steps in this procedure may contain installation details. Published: 12-Jun-2014
