2010 INFINITI QX56 Ignition switch

DOOR LOCK FUNCTION SYMPTOMSDLK-211
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR LOCK FUNCTION SYMPTOMS
DOOR LOCK AND UNLOCK SWITCH
DOOR LOCK AND UNLOCK SWITCH : Symptom TableINFOID:0000000005147033
DOOR LOCK/UNLOCK FUNCTION MALFUNCTION
NOTE:
• Before performing the diagnosis in the follo wing table, check “WORK FLOW”. Refer to DLK-6, "
Work Flow".
• Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and
check each symptom.
• If the following symptoms are detec ted, check systems shown in the “Diagnosis/service procedure” column
in this order.
Conditions of Vehicle (Operating Conditions)
• “LOCK/UNLOCK BY I-KEY” is ON when setting on CONSULT-III.
• Ignition switch is not depressed.
• All doors are closed.
Symptom Diagnosis/service procedureReference page
Power door lock does not operate with door lock
and unlock switch. 1. Check BCM Power supply and ground circuit.
BCS-33
2. Check door lock and unlock switch. DLK-74
3. Check door lock actuator (driver side)DLK-86
4. Check Intermittent Incident. GI-38
Power door lock does not operate with door key
cylinder operation.
(Power door lock operate properly with door lock
and unlock switch.)1. Check key cylinder switch.
DLK-79
2. Replace power window main switch.PWC-117
Specific door lock actuator does not operate.1a. Check driver side door lock actuator.
DLK-86
1b. Check passenger side door lock actuator.DLK-87
1c. Check rear LH side door lock actuator.DLK-88
1d. Check rear RH side door lock actuator.DLK-90
1e. Check back door lock operation (refer to back door).DLK-214
1f. Check glass hatch lock actuator. DLK-92
2. Check Intermittent Incident. GI-38
Door lock/unlock do not operate by request switch.1. Door switch check.
DLK-712. Ignition knob switch check.DLK-116
3. Replace Intelligent Key unit.SEC-120
Door lock/unlock does not operate by request
switch (LH side).1. Front door request switch LH check.
DLK-832. Front outside antenna LH check.DLK-97
3. Replace Intelligent Key unit.SEC-120
Door lock/unlock does not operate by request
switch (RH side).1. Front door request switch RH check.
DLK-832. Front outside antenna RH check.DLK-97
3. Replace Intelligent Key unit.SEC-120
Selective unlock function does not operate by front
door request switch LH (other door lock functions
operate properly).1.
Check “SELECT UNLOCK FUNCTION” setting in “WORK
SUPPORT”.
DLK-55
2. Replace Intelligent Key unit.
SEC-120
Revision: April 20092010 QX56

DLK-212
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR LOCK FUNCTION SYMPTOMS
INTELLIGENT KEY
INTELLIGENT KEY : Symptom TableINFOID:0000000005147034
REMOTE KEYLESS ENTRY FUNCTION MALFUNCTION
NOTE:
• Before performing the diagnosis in the following table, check “Trouble Diagnosis Procedure”. Refer to
DLK-
6, "Work Flow".
• Make sure that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and
check each symptom.
• If the following “symptoms” are detected, check syst ems shown in the “Diagnosis/service procedure” column
in this order.
Conditions of Vehicle (Operating Conditions)
• Ignition switch is not depressed.
• All doors are closed.
Auto lock function does not operate properly. 1.
Check “AUTO RELOCK TIMER” setting in “WORK SUP-
PORT”. DLK-53
2. Key switch check (BCM).
DLK-115
3. Ignition knob switch check.DLK-116
4. Door switch check. DLK-71
5. Replace Intelligent Key unit.SEC-120
Key reminder function does not operate properly.1.
Check “ANTI KEY LOCK IN FUNCTION” setting in
“WORK SUPPORT”.
DLK-53
2. Door switch check.
DLK-71
3a. Center console area antenna (rear) check. DLK-60
3b. Luggage area antenna check.DLK-62
3c. Center console area antenna (front) check.DLK-64
3d. Overhead console area antenna check. DLK-66
4. Front door lock actuator LH (door unlock sensor) check.DLK-81
5. Intelligent Key battery and function inspection.DLK-106
6. Replace Intelligent Key unit.SEC-120
Vehicle speed sensing auto LOCK operation does
not operate.1.
Ensure automatic door lock/unlock function (lock opera-
tion) is enabled. DLK-55
2. Check combination meter vehicle speed signal.
MWI-27
3. Check intermittent incident. GI-38
Ignition OFF interlock door UNLOCK function does
not operate.1.
Ensure automatic door lock/unlock function (unlock oper-
ation) is enabled. DLK-55
2. Check BCM for DTC.
BCS-54
3. Check intermittent incident. GI-38
SymptomDiagnosis/service procedureReference page
Symptom Diagnosis/service procedureReference
page
All of the remote keyless entry functions do not
operate. 1. Intelligent Key battery and function inspection.
DLK-106
2. Remote Keyless Entry function check.DLK-103
3. Replace Intelligent Key unit.SEC-120
Selective unlock function does not operate by In-
telligent Key remote control button.1.
Check “SELECT UNLOCK FUNCTION” setting in “WORK SUP-
PORT”.
DLK-53
2. Intelligent Key battery inspection.
DLK-106
3. Replace Intelligent Key unit.SEC-120
Revision: April 20092010 QX56

DOOR LOCK FUNCTION SYMPTOMSDLK-213
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Auto lock function does not operate properly. 1. Check “AUTO RELOCK TIMER” setting in “WORK SUPPORT”.
DLK-53
2. Key switch check (BCM).DLK-115
3. Ignition knob switch check.DLK-116
4. Door switch check. DLK-71
5. Replace Intelligent Key unit.SEC-120
Key reminder function does not operate properly.1.
Check “ANTI KEY LOCK IN FUNCTION” setting in “WORK
SUPPORT”.
DLK-53
2. Door switch check.
DLK-71
3a. Center console area antenna (rear) check.DLK-60
3b. Luggage area antenna check.DLK-62
3c. Center console area antenna (front) check.DLK-64
3d. Overhead console area antenna check.DLK-66
4. Front door lock actuator LH (door unlock sensor) check.DLK-81
5. Intelligent Key battery inspection.DLK-106
6. Replace Intelligent Key unit.SEC-120
Panic alarm function does not operate properly.1. Check “PANIC ALARM DELAY” setting in “WORK SUPPORT”.
DLK-55
2. Theft warning operation check.DLK-216
3. Intelligent Key battery inspection.DLK-106
4. Key switch check (BCM). DLK-115
5. Ignition knob switch check.DLK-116
6. Replace Intelligent Key unit.SEC-120
Back door open function does not operate prop-
erly.1. Back door diagnosis.
DLK-1232. Intelligent Key battery inspection.DLK-106
3. Replace Intelligent Key unit.SEC-120
Power window down function does not operate.1. Check “PW DOWN SET” setti
ng in “WORK SUPPORT”. DLK-552. Intelligent Key battery inspection. DLK-106
SymptomDiagnosis/service procedureReference
page
Revision: April 20092010 QX56

BACK DOOR OPENER FUNCTIONDLK-215
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
BACK DOOR HANDLE : Symptom TableINFOID:0000000005147036
BACK DOOR OPEN FUNCTION MALFUNCTION
NOTE:
• Before performing the diagnosis in the follo wing table, check “WORK FLOW”. Refer to DLK-6, "
Work Flow".
• Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and check each symptom.
• If the following “symptoms” are detected, check syst ems shown in the “Diagnosis/service procedure” column
in this order.
Conditions of Vehicle (Operating Conditions)
• Vehicle is in park.
INTELLIGENT KEY
INTELLIGENT KEY : Symptom TableINFOID:0000000005147037
BACK DOOR OPEN FUNCTION MALFUNCTION
NOTE:
• Before performing the diagnosis in the follo wing table, check “WORK FLOW”. Refer to DLK-6, "
Work Flow".
• Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and check each symptom.
• If the following symptoms” are detected, check systems shown in the “Diagnosis/service procedure” column
in this order.
Conditions of Vehicle (Operating Conditions)
• Ignition switch is not depressed.
Symptom Diagnosis/service procedureReference page
Back door open function does not operate by
back door switch (doors unlocked). 1. Refer to diagnosis chart.
DLK-214
2. Check Intermittent Incident. GI-38
Back door open function does not operate by
back door switch only.
(doors locked but Intelligent Key present).1. Outside key antenna check.
DLK-972. Intelligent Key unit power back door input signal.DLK-142
3. Intelligent Key unit power back door output signal.DLK-143
4. Intelligent Key battery and function check.DLK-106
SymptomDiagnosis/service procedureReference page
Back door open function does not operate
by Intelligent Key. 1. Check Intelligent Key battery inspection.
DLK-106
2. Intelligent Key unit power and ground check. DLK-68
3. Check intermittent incident. GI-38
Revision: April 20092010 QX56

DLK-216
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
WARNING FUNCTION SYMPTOMS
WARNING FUNCTION SYMPTOMS
Symptom TableINFOID:0000000005147038
WARNING FUNCTION MALFUNCTION
NOTE:
• Before performing the diagnosis in the following table, check “WORK FLOW”. Refer to
DLK-6, "
Work Flow".
• Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and check each symptom.
• If the following “symptoms are detected, check systems shown in the “Diagnosis/service procedure” column
in this order.
Conditions of Vehicle (Operating Conditions)
Warning chime functions operating condition is extremely complicated, during operating confirmations, recon-
firm the list above twice in order to ensure proper operation.
Symptom Diagnosis/service procedure Reference
page
OFF position warn-
ing does not oper-
ate. For internal
1. Check ignition knob switch.
DLK-116
2. Check door switch. DLK-71
3. Check warning chime function.D L K - 111
4. Check Intermittent Incident. GI-38
For external1. Check ignition knob switch.
DLK-1162. Check door switch. DLK-71
3. Check Intelligent Key warning buzzer.DLK-95
4. Check Intermittent Incident. GI-38
P position warning does not operate.1. Check Park position switch.
TM-45
2. Check door switch.DLK-71
3. Check Intelligent Key warning buzzer.DLK-95
4. Check warning chime function.D L K - 111
5. Check combination meter display function.DLK-110
6. Check Intermittent Incident. GI-38
ACC warning does not operate1. Check ignition knob switch.
DLK-1162. Check warning chime function. D L K - 111
3. Check combination meter display function.DLK-110
4. Check Intermittent Incident. GI-38
Revision: April 20092010 QX56

WARNING FUNCTION SYMPTOMSDLK-217
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Take away warning
does not operate. Door open to close
1. Check door switch.
DLK-71
2. Check inside key antennasCenter console area (rear)
DLK-60Luggage areaDLK-62
Center console area (front)DLK-64
Overhead console areaDLK-66
3. Check Intelligent Key warning buzzer. DLK-95
4. Check warning chime function.D L K - 111
5. Check ignition knob switch.DLK-116
6. Check combination meter display function.DLK-110
7. Check Intermittent Incident. GI-38
Push-button igni-
tion switch opera-
tion1. Check ignition knob switch.
DLK-1162. Check inside key antennasCenter console area (rear)
DLK-60Luggage areaDLK-62
Center console area (front)DLK-64
Overhead console areaDLK-66
3. Check warning chime function. D L K - 111
4. Check combination meter display function.DLK-110
5. Check Intermittent Incident. GI-38
Door is open1. Check ignition knob switch.
DLK-1162. Check inside key antennasCenter console area (rear)
DLK-60Luggage areaDLK-62
Center console area (front)DLK-64
Overhead console areaDLK-66
3. Check combination meter display function. DLK-110
4. Check Intermittent Incident. GI-38
Take away through
window1.
Check “TAKE OUT FROM WIN WARN” setting in “WORK SUP-
PORT”.
DLK-55
2. Check inside key antennasCenter console area (rear)
DLK-60Luggage areaDLK-62
Center console area (front)DLK-64
Overhead console areaDLK-66
3. Check warning chime function. D L K - 111
4. Check ignition knob switch.DLK-116
5. Check combination meter display function.DLK-110
6. Check Intermittent Incident. GI-38
Key warning chime does not operate.1. Check door switch.
DLK-71
2. Check warning chime function.D L K - 111
3. Check ignition knob switch.DLK-116
4. Check combination meter display function.DLK-110
5. Check Intermittent Incident. GI-38
SymptomDiagnosis/service procedure Reference
page
Revision: April 20092010 QX56

DLK-218
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
WARNING FUNCTION SYMPTOMS
Door lock operation warning chime does
not operate.1. Check door switch.
DLK-71
2. Check ignition knob switch.DLK-116
3. Check Intelligent Key warning buzzer. DLK-95
4. Check inside key antennasCenter console area (rear)
DLK-60Luggage areaDLK-62
Center console area (front)DLK-64
Overhead console areaDLK-66
5. Check Intermittent Incident. GI-38
SymptomDiagnosis/service procedure Reference
page
Revision: April 20092010 QX56

KEY REMINDER FUNCTION SYMPTOMSDLK-219
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
KEY REMINDER FUNCTION SYMPTOMS
Symptom TableINFOID:0000000005147039
KEY REMINDER FUNCTION MALFUNCTION
NOTE:
• Before performing the diagnosis in the following table, check “Work flow”. Refer to DLK-6, "
Work Flow".
• If the following symptoms” are detected, check systems shown in the “Diagnosis/service procedure” column in this order.
Conditions of Vehicle (Operating Conditions)
• “LOCK/UNLOCK BY I-KEY” is ON when setting on CONSULT-III.
• “ANSWER BACK FUNCTION” is ON when setting on CONSULT-III.
• Ignition switch is in OFF position.
• All doors are closed.
• Ignition switch is not depressed.
Symptom Diagnosis/service procedureReference page
Key reminder function does not operate. 1.
Check “ANTI KEY LOCK IN FUNCTI”setting in “WORK SUP-
PORT”. DLK-55
2. Check door switch.
DLK-71
3. Check inside key antennasCenter console area (rear)
DLK-60Luggage areaDLK-62
Center console area (front)DLK-64
Overhead console areaDLK-66
4. Check unlock sensor. DLK-81
5. Check Intelligent Key battery inspection.DLK-106
6. Check Intermittent Incident. GI-38
Revision: April 20092010 QX56
