DLK-236
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
HOOD
4. Install the primary and secondary cables securely to the hood
lock assembly.
5. Install the hood lock and the secondary hood lock release assemblies.
6. Check the hood lock adjustment and hood opener operation. Refer to DLK-233, "
Fitting Adjustment".
7. Install the remaining components in the reverse order of removal.
Hood Lock Control InspectionINFOID:0000000005147053
CAUTION:
If the hood lock cable is bent or deformed, replace it.
1. Remove the front grille. Refer to EXT-17, "
Removal and Installation".
2. Make sure the secondary latch is properly engaged with the sec- ondary striker with hood's own weight by dropping it from
approx. 200 mm (7.87 in) height.
3. While operating the hood opener, carefully make sure the front end of the hood is raised by approx. 20 mm (0.79 in). Also make
sure the hood opener returns to the original position.
4. Check the hood lock lubrication condition. If necessary, apply “body grease” to the points shown in the figure.
5. Install the front grille. Refer to EXT-17, "
Removal and Installa-
tion".
Hood Stay DisposalINFOID:0000000005356855
1. Fix hood stay (1) using a vise (C).
2. Using hacksaw (A) slowly make 2 holes in the hood stay, in numerical order as shown in the figure.
CAUTION:
• When cutting a hole on hood stay, always cover a hack-saw using a shop cloth (B) to avoid scattering metal frag-
ments or oil.
• Wear eye protection (safety glasses).
• Wear gloves.
PIIA0174E
PIIA1086E
PIIA0176E
JMKIA3336ZZ
Revision: April 20092010 QX56

DLN-4
Commercial Service Tool ......................................193
SYMPTOM DIAGNOSIS ............................194
NOISE, VIBRATION, AND HARSHNESS
(NVH) TROUBLESHOOTING ......................... .
194
NVH Troubleshooting Chart ................................ ..194
ON-VEHICLE REPAIR ...............................195
PROPELLER SHAFT ..................................... .195
On-Vehicle Service .............................................. ..195
REMOVAL AND INSTALLATION ..............196
PROPELLER SHAFT ..................................... .196
Removal and Installation ..................................... ..196
DISASSEMBLY AND ASSEMBLY ............199
PROPELLER SHAFT ..................................... .199
Disassembly and Assembly ................................. ..199
SERVICE DATA AND SPECIFICATIONS
(SDS) ........................................................ ..
201
SERVICE DATA AND SPECIFICATIONS
(SDS) ............................................................... .
201
General Specification .......................................... ..201
Snap Ring ..............................................................201
FRONT FINAL DRIVE: M205
PRECAUTION .............. ..............................
203
PRECAUTIONS .............................................. .203
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" .............................................................. ..
203
Precaution Necessary for Steering Wheel Rota-
tion After Battery Disconnect .................................
203
Precaution for Servicing Front Final Drive .............204
PREPARATION ..........................................205
PREPARATION .............................................. .205
Special Service Tool ............................................ ..205
Commercial Service Tool ......................................207
SYMPTOM DIAGNOSIS ............................208
NOISE, VIBRATION AND HARSHNESS
(NVH) TROUBLESHOOTING ......................... .
208
NVH Troubleshooting Chart ................................ ..208
ON-VEHICLE MAINTENANCE ..................209
DIFFERENTIAL GEAR OIL ............................ .209
Changing Front Differential Gear Oil .....................209
Checking Front Differential Gear Oil .................... ..209
ON-VEHICLE REPAIR ...............................210
SIDE OIL SEAL .............................................. ..210
Removal and Installation .......................................210
FRONT OIL SEAL ............................................211
Removal and Installation .......................................211
CARRIER COVER .......................................... ..214
Removal and Installation .......................................214
REMOVAL AND INSTALLA TION .............215
FRONT FINAL DRIVE .................................... ..215
Removal and Installation .......................................215
DISASSEMBLY AND ASSEMBLY ...........217
FRONT FINAL DRIVE .................................... ..217
Disassembly and Assembly ................................. .217
SERVICE DATA AND SPECIFICATIONS
(SDS) ........ .................................................
234
SERVICE DATA AND SPECIFICATIONS
(SDS) .............................................................. ..
234
General Specification ........................................... .234
Inspection and Adjustment ....................................234
REAR FINAL DRIVE: R230
PRECAUTION ............... ............................
236
PRECAUTIONS .............................................. ..236
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" .............................................................. .
236
Precaution Necessary for Steering Wheel Rota-
tion After Battery Disconnect ................................
236
Precaution for Servicing Rear Final Drive .............237
PREPARATION .........................................238
PREPARATION .............................................. ..238
Special Service Tool ............................................ .238
Commercial Service Tool ......................................240
SYMPTOM DIAGNOSIS ...........................242
NOISE, VIBRATION AND HARSHNESS
(NVH) TROUBLESHOOTING ......................... ..
242
NVH Troubleshooting Chart ..................................242
DESCRIPTION ................................................ ..243
Cross-Sectional View ........................................... .243
ON-VEHICLE MAINTENANCE .................244
DIFFERENTIAL GEAR OIL ..............................244
Changing Rear Differential Gear Oil .................... .244
Checking Rear Differential Gear Oil ......................244
ON-VEHICLE REPAIR ..............................245
FRONT OIL SEAL ............................................245
Revision: April 20092010 QX56

DLN-14
< FUNCTION DIAGNOSIS >[ATX14B]
4WD SYSTEM
• Displays 4LO condition while engine is running. 4LO indicator lamp flashes if transfer gear does not shift
completely under 2WD, AUTO, 4H ⇔4LO. (When 4WD warning lamp is turned on, 4LO indicator lamp is
turned off.)
• Turns ON for approximately 1 second when ignition switch is turned ON, for purpose of lamp check.
4WD WARNING LAMP
Turns on or flashes when there is a malfunction in 4WD system.
Also turns on when ignition switch is turned ON, for purpose of lamp che\
ck. Turns OFF approximately 1 sec-
ond after the engine starts if system is normal.
4WD Warning Lamp Indication
ATP WARNING LAMP
When the A/T selector lever is in P position, the vehicle may move if the transfer case is in neutral. ATP warn-
ing lamp is turned on to indicate this condition to the driver.
LINE PRESSURE SWITCH
• With the transfer system design, control of the oil pressure provides the transmission of drive torque to the
front wheels. The main pressure to control the oil pressure is referred to as the line pressure.
• The line pressure switch determines whether or not adequate line pressure has built up under different oper- ating conditions.
• The line pressure switch closes when line pressure is produced.
• The line pressure switch senses line pressure abnormalities and turns the 4WD warning lamp ON.
CLUTCH PRESSURE SWITCH
• The clutch pressure switch determines whether or not adequate clutch pressure has built up under different
operating conditions.
• The clutch pressure switch closes when clutch pressure is produced.
• The clutch pressure switch senses clutch pressure abnormalities and turns the 4WD warning lamp ON.
WAIT DETECTION SWITCH
• The wait detection switch operates when there is circulating torque produced in the propeller shaft (L→H) or
when there is a phase difference between 2-4 sleeve and clutch drum (H →L). After the release of the circu-
lating torque, the wait detection switch helps provi de the 4WD lock gear (clutch drum) shifts. A difference
may occur between the operation of the 4WD shift swit ch and actual drive mode. At this point, the wait
detection switch senses an actual drive mode.
• The wait detection switch operates as follows.
- 4WD lock gear (clutch drum) locked: ON
- 4WD lock gear (clutch drum) released: OFF
• The wait detection switch senses an actual drive mode and the 4WD shift indicator lamp indicates the vehi-
cle drive mode.
ATP SWITCH
ATP switch detects if transfer case is in neutral by the position of the L-H shift fork.
NOTE:
Transfer case may be in neutral when shifting between 4H-4LO.
NEUTRAL-4LO SWITCH
The neutral-4LO switch detects that transfer gear is in neutral or 4LO (or shifting from neutral to 4LO) condi-
tion by L-H shift fork position.
Condition 4WD warning lamp
System normal OFF
Lamp check Turns ON when ignition switch is turned ON.
Turns OFF after engine start.
4WD system malfunction ON
During self-diagnosis Flashes malfunction mode.
Large difference in diameter of front/
rear tires Flashes slow (1 flash / 2 seconds)
(Continues to flash until the ignition switch is turned OFF)
High fluid temperature in transfer case Flashes rapidly (2 flashes / 1 second)
(Continues to flash until fluid temperature returns to normal)
Revision: April 20092010 QX56

DLN-68
< COMPONENT DIAGNOSIS >[ATX14B]
P1826 TRANSFER FLUID TEMPERATURE
P1826 TRANSFER FLUID TEMPERATURE
DescriptionINFOID:0000000005148829
Signal voltage from the transfer fluid temperature sensor is abnormally high (Transfer fluid temperature is
abnormally low) while driving.
DTC LogicINFOID:0000000005148830
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Perform self-diagnosis.
Is DTC P1826 displayed?
YES >> Perform diagnosis procedure. Refer to DLN-68, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000005148831
Regarding Wiring Diagram information, refer to DLN-89, "Wiring Diagram - ALL-MODE 4WD SYSTEM -".
1.CHECK TRANSFER FLUID TEMPERATURE SENSOR SIGNAL
With CONSULT-III
1. Start engine.
2. Select DATA MONITOR mode for ALL MODE AWD/4WD with CONSULT-III.
3. Read out the value of FLUID TEMP SE.
Without CONSULT-III
1. Start engine.
2. Check voltage between transfer control unit harness connector
terminals and ground.
Are inspection results normal?
DTC CONSULT-III Diagnostic item is detected when... Reference
[P1826] OIL TEMP SEN Signal voltage from transfer fluid temper-
ature sensor is abnormally high (Trans-
fer fluid temperature is abnormally low)
while driving.Refer to
DLN-68
.
Condition Display value
(Approx.)
Transfer fluid temperature approx. 20 - 80 °C (68 - 176 °F) 1.1 - 0.3V
Connector Terminal ConditionData
(Approx.)
E143 28 -
Ground Always
0V
31 -
Ground Ignition switch:
ON Transfer fluid temperature
approx. 20
°C (68 °F) 1.1V
Transfer fluid temperature
approx. 80 °C (176 °F) 0.3V
SDIA2742E
Revision: April 20092010 QX56

TRANSFER CONTROL UNITDLN-99
< ECU DIAGNOSIS > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
CAUTION:
• If CAN COMM CIRCUIT [U1000] or CONTROL UNIT (CAN) [U1010] is displayed with other DTCs, first perform the trouble
diagnosis for CAN communication line.
• If ABS OP SIG [P1830], VDC OP SIG [P1831] or TCS OP SIG [P 1832] is displayed, first perform the trouble diagnosis for ABS
system.
• If VHCL SPEED SEN·AT [P1807] is displayed, firs t perform the trouble diagnosis for A/T system.
NOTE:
• If SHIFT ACT POSI SW [P1818] or SHIFT ACT CIR [P1819] is disp layed, first erase self-diagnostic results. (SHIFT ACT POSI SW
[P1818] or SHIFT ACT CIR [P1819] may be displayed after installing transfer control unit or transfer assembly.)
• If CL PRES SW [P1827] or LINE PRES SW [P1828] is displayed only while driving in reverse, check the continuity of R position o n
transmission range switch. When there is no malfunction found in the electrical system, check the hydraulic system.
FLASH CODE CHART
[P1826] OIL TEMP SEN Signal voltage from transfer fluid temperature sen-
sor is abnormally high (Transfer fluid temperature is
abnormally low) while driving. Refer to
DLN-68.
[P1827] CLUTCH PRES SW • Improper signal from clutch pressure switch is in-
put due to open or short circuit.
• Malfunction occurs in clutch pressure switch or
hydraulic circuit. Refer to
DLN-71
.
[P1828] LINE PRES SW • Improper signal from line pressure switch is input
due to open or short circuit.
• Malfunction occurs in line pressure switch or hy-
draulic circuit. Refer to
DLN-74
.
[P1829] THROTTLE POSI SEN • Malfunction is detected in accelerator pedal posi-
tion signal that is output from ECM through CAN
communication.
• Signal voltage from accelerator pedal position sensor is abnormally high or low. Refer to
DLN-77
.
[P1830] ABS OP SIG Malfunction is detected in ABS operation signal that
is output from ABS actuator and electric unit (control
unit) through CAN communication. Refer to
DLN-78
.
[P1831] VDC OP SIG Malfunction is detected in VDC operation signal that
is output from ABS actuator and electric unit (control
unit) through CAN communication.
Refer to
DLN-79
.
[P1832] TCS OP SIG Malfunction is detected in TCS operation signal that
is output from ABS actuator and electric unit (control
unit) through CAN communication. Refer to
DLN-80
.
DTC CONSULT-III Diagnostic item is detected when... Reference
Flashing pattern
ItemDiagnostic item is detected when... Reference
2 Vehicle speed signal
(from A/T) • Malfunction is detected in output shaft revolution signal
that is output from TCM through CAN communication.
• Improper signal is input while driving. Refer to DLN-27
.
3 Clutch pressure sole-
noid signal Proper voltage is not applied to clutch pressure solenoid
valve due to open or short circuit.
Refer to DLN-54
.
4 2-4WD solenoid signal Proper voltage is not applied to 2-4WD solenoid valve due
to open or short circuit. Refer to DLN-58
.
5 Transfer motor Transfer motor does not operate properly due to open or
short circuit in transfer motor or transfer motor relay.
Refer to DLN-62
.
6 Vehicle speed signal
(from ABS) • Malfunction is detected in vehicle speed signal that is out-
put from ABS actuator and electric unit (control unit)
through CAN communication.
• Improper signal is input while driving. Refer to DLN-28
.
7 CAN communication Malfunction has been detected from CAN communication
line. Refer to LAN-14
.
8 AD converter AD converter system of transfer control unit is malfunction-
ing. Refer to DLN-25
.
Revision: April 20092010 QX56

DLN-128
< ON-VEHICLE MAINTENANCE >[ATX14B]
TRANSFER OIL FILTER
3. Apply ATF to the two new O-rings (1), and install them on the oil
filter (2).
CAUTION:
Do not reuse O-rings.
4. Install the oil filter to the transfer assembly. Tighten the bolts to the specified torque. Refer to DLN-142, "
Disassembly and
Assembly".
CAUTION:
• Do not damage oil filter.
• Attach oil filter an d tighten bolts evenly.
5. Check the transfer fluid. Refer to DLN-129, "
Inspection".
6. Start the engine for one minute. Then stop the engine and recheck the transfer fluid. Refer to DLN-129, "
Inspection".
WDIA0285E
SDIA2136E
Revision: April 20092010 QX56

DLN-132
< ON-VEHICLE REPAIR >[ATX14B]
FRONT OIL SEAL
1. Install the new front oil seal until it is flush with the end face of
the front case using Tool.
CAUTION:
• Do not reuse oil seal.
• Apply petroleum jelly to oil seal.
2. Align the matching mark of the front drive shaft with the match- ing mark of the companion flange, then install the companion
flange.
3. Install the new self-lock nut. Tighten to the specified torque using suitable tool. Refer to DLN-142, "
Disassembly and
Assembly".
CAUTION:
Do not reuse self-lock nut.
4. Install the front propeller shaft. Refer to DLN-186, "
Removal and
Installation".
5. Refill the transfer with fluid and check for fluid leakage and fluid level. Refer to DLN-129, "
Inspection".
Tool number : KV38100500 ( — )
SDIA2662E
SDIA2658E
LDIA0147E
Revision: April 20092010 QX56

DLN-134
< ON-VEHICLE REPAIR >[ATX14B]
REAR OIL SEAL
3. Install the new dust cover to the rear case using Tool.
CAUTION:
• Do not reuse dust cover.
• Apply petroleum jelly to dust cover.
4. Install the rear propeller shaft. Refer to DLN-196, "
Removal and
Installation".
5. Refill the transfer with fluid and check for fluid leakage and fluid level. Refer to DLN-129, "
Replacement".
Tool number : KV40105310 ( — )PDIA0116E
Revision: April 20092010 QX56
