2010 INFINITI QX56 audio

AV-170
< ON-VEHICLE REPAIR >[AUDIO SYSTEM]
AV CONTROL UNIT
Only remove and replace the A/C or AV switch
assembly knobs if damaged or missing. The knobs
must not be removed from the switches when remo ving and installing the A/C or AV switch assembly
to prevent damage to the switch assembly.
REMOVAL
1. Disconnect the battery negative terminal.
2. Remove the cluster lid C. Refer to IP-15, "
Removal and Installation".
3. Remove the AV control unit screws, using a power tool.
4. Remove the AV control unit.
5. Remove the A/C and AV switch assembly screws, then remove the A/C and AV switch assembles as nec- essary.
INSTALLATION
Installation is in the reverse order of removal.
Revision: April 20092010 QX56

AV
DISPLAY UNITAV-171
< ON-VEHICLE REPAIR > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
DISPLAY UNIT
Removal and InstallationINFOID:0000000005146357
REMOVAL
1. Remove cluster lid C. Refer to IP-15, "Removal and Installation".
2. Remove the display unit screws (A), pull out the display unit (1) from instrument panel, to disconnect the display unit connectors.
3. Remove the A/C auto amp. screws (A) and the A/C auto amp. (1).
• Display unit (2)
4. Remove the display unit bracket screws and the display unit brackets.
INSTALLATION
Installation is in the reverse order of removal.
ALNIA0272ZZ
ALIIA0063ZZ
Revision: April 20092010 QX56

AV-172
< ON-VEHICLE REPAIR >[AUDIO SYSTEM]
FRONT TWEETER
FRONT TWEETER
Removal and InstallationINFOID:0000000005146358
REMOVAL
CAUTION:
Use a suitable tool to prevent da
mage to the tweeter speaker grille trim and the instrument panel.
1. Remove front tweeter speaker grille.
2. Remove the front tweeter clips (C103) (A).
3. Disconnect the front tweeter connector.
4. Remove the front tweeter (1).
INSTALLATION
Installation is in the reverse order of removal.
ALNIA0202ZZ
Revision: April 20092010 QX56

AV
CENTER SPEAKERAV-173
< ON-VEHICLE REPAIR > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
CENTER SPEAKER
Removal and InstallationINFOID:0000000005146359
REMOVAL
CAUTION:
Use a suitable tool to prevent damage to the center speaker grille and the instrument panel.
1. Using a suitable tool, remove the center speaker grille finisher (1).
2. Disconnect the center speaker connector (A).
3. Remove the center speaker screws (B).
4. Remove the center speaker (2).
INSTALLATION
Installation is in the reverse order of removal.
ALNIA0275ZZ
Revision: April 20092010 QX56

AV-174
< ON-VEHICLE REPAIR >[AUDIO SYSTEM]
FRONT DOOR SPEAKER
FRONT DOOR SPEAKER
Removal and InstallationINFOID:0000000005146360
REMOVAL
1. Remove the front door finisher. Refer to
INT-11, "Removal and Installation".
2. Remove the front door speaker screws.
3. Disconnect the front door speaker connector.
4. Remove the front door speaker.
INSTALLATION
Installation is in the reverse order of removal.
WKIA1498E
Revision: April 20092010 QX56

AV
REAR DOOR SPEAKERAV-175
< ON-VEHICLE REPAIR > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
REAR DOOR SPEAKER
Removal and InstallationINFOID:0000000005146361
REAR DOOR SPEAKER
Removal
1. Remove the rear door finisher. Refer to INT-11, "Removal and Installation".
2. Remove the rear door speaker screws.
3. Disconnect the rear door speaker connector.
4. Remove the rear door speaker.
Installation
Installation is in the reverse order of removal.
REAR DOOR TWEETER
Removal
1. Partially remove the rear door finisher. Refer to INT-11, "Removal and Installation".
2. Remove the rear door tweeter screws (A).
3. Remove the rear door tweeter (1).
Installation
Installation is in the reverse order of removal.
WKIA1492E
ALNIA0269ZZ
Revision: April 20092010 QX56

AV-176
< ON-VEHICLE REPAIR >[AUDIO SYSTEM]
BACK DOOR SPEAKER
BACK DOOR SPEAKER
Removal and InstallationINFOID:0000000005146362
REMOVAL
1. Remove the back door lower finisher. Refer to INT-21, "Removal and Installation".
2. Remove the back door speaker screws (A).
3. Pull out the back door speaker (1), disconnect the back door speaker connector and remove the back door speaker (1).
INSTALLATION
Installation is in the reverse order of removal.
ALNIA0421ZZ
Revision: April 20092010 QX56

AV
SUBWOOFERAV-177
< ON-VEHICLE REPAIR > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
SUBWOOFER
Removal and InstallationINFOID:0000000005146363
SUBWOOFER (BOSE SYSTEM)
Removal
1. Remove the front seat LH. Refer to SE-51, "Removal and Installation".
2. Disconnect the subwoofer connector.
3. Remove the subwoofer bolts.
4. Remove the subwoofer.
Installation
Installation is in the reverse order of removal.
WKIA1496E
