QUICK REFERENCE INDEX
AGENERAL INFORMATIONGIGeneral Information
BENGINEEMEngine Mechanical
LUEngine Lubrication System
COEngine Cooling System
ECEngine Control System
FLFuel System
EXExhaust System
STRStarting System
ACCAccelerator Control System
CHYBRIDHBCHybrid Control System
HBBHybrid Battery System
HBRHybrid Brake System
DTRANSMISSION & DRIVE-
LINETMTransaxle & Transmission
DLNDriveline
FAXFront Axle
RAXRear Axle
ESUSPENSIONFSUFront Suspension
RSURear Suspension
SCSSuspension Control System
WTRoad Wheels & Tires
FBRAKESBRBrake System
PBParking Brake System
BRCBrake Control System
GSTEERINGSTSteering System
STCSteering Control System
HRESTRAINTSSBSeat Belt
SBCSeat Belt Control System
SRSRS Airbag
SRCSRS Airbag Control System
IVENTILATION, HEATER &
AIR CONDITIONERVTLVentilation System
HAHeater & Air Conditioning System
HACHeater & Air Conditioning Control System
JBODY INTERIORINTInterior
IPInstrument Panel
SESeat
ADPAutomatic Drive Postioner
APAdjustable Pedal
KBODY EXTERIOR,
DOORS, ROOF & VEHICLE
SECURITYDLKDoor & Lock
SECSecurity Control System
GWGlass & Window System
PWCPower Window Control System
RFRoof
EXTExterior
BRMBody Repair Manual
LDRIVER CONTROLSMIRMirrors
EXLExterior Lighting System
INLInterior Lighting System
WWWiper & Washer
DEFDefogger
HRNHorn
MELECTRICAL & POWER
CONTROLPWOPower Outlet
BCSBody Control System
LANLAN System
PCSPower Control System
CHGCharging System
PGPower Supply, Ground & Circuit Elements
NDRIVER INFORMATION &
MULTIMEDIAMWIMeter, Warning Lamp & Indicator
WCSWarning Chime System
SNSonar System
AVAudio, Visual & Navigation System
OCRUISE CONTROLCCSCruise Control System
PMAINTENANCEMAMaintenance
All rights reserved. No part
of this Service Manual may
be reproduced or stored in a
retrieval system, or transmit-
ted in any form, or by any
means, electronic, mechani-
cal, photo-copying, record-
ing or otherwise, without the
prior written permission of
Nissan North America, Inc.
Edition: April 2009
Revision: April 2009
Publication No. SM0
E-1J60U0

ADP-158
< ECU DIAGNOSIS >
BCM (BODY CONTROL MODULE)
19 V/WRemote keyless entry
receiver (power sup-
ply) Output OFF Ignition switch OFF
20 G/W Remote keyless entry
receiver (signal) Input OFFStand-by (keyfob buttons re-
leased)
When remote keyless entry
receiver receives signal from
keyfob (keyfob buttons
pressed)
21 G NATS antenna amp. Input OFF
→
ON Ignition switch (OFF
→ ON)Just after turning ignition switch
ON: Pointer of tester should
move for approx. 1 second, then return to battery voltage.
22 W/V BUS — —Ignition switch ON or power
window timer operates
23 G/O Security indicator
lamp Output OFF
Goes OFF
→ illuminates (Ev-
ery 2.4 seconds) Battery voltage
→ 0V
25 BR NATS antenna amp. Input OFF
→
ON Ignition switch (OFF
→ ON)Just after turning ignition switch
ON: Pointer of tester should
move for approx. 1 second, then return to battery voltage.
26 Y/L Rear wiper auto stop
switch 2 Input ONRise up position (rear wiper
arm on stopper)
0V
A Position (full clockwise stop
position) 0V
Forward sweep (counterclock-
wise direction) Fluctuating
B Position (full counterclock-
wise stop position) Battery voltage
Reverse sweep (clockwise di-
rection) Fluctuating
27 W/R Compressor ON sig-
nal Input ONA/C switch OFF
5V
A/C switch ON 0V
Te r m i n a l
Wire
color Signal name Signal
input/
output Measuring condition
Reference value or waveform
(Approx.)
Ignition
switch Operation or condition
LIIA1893E
LIIA1894E
LIIA1895E
PIIA2344E
Revision: April 20092010 QX56

BCM (BODY CONTROL MODULE)ADP-161
< ECU DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
58 W/R Optical sensor Input ONWhen optical sensor is illumi-
nated
3.1V or more
When optical sensor is not illu-
minated 0.6V or less
59 G Front door lock as-
sembly LH actuator
(unlock) Output OFF
OFF (neutral)
0V
ON (unlock) Battery voltage
60 G/B Turn signal (left) Output ON Turn left ON
61 G/Y Turn signal (right) Output ON Turn right ON
62 R/W Step lamp LH and RH Output OFF ON (any door open)
0V
OFF (all doors closed) Battery voltage
63 L Interior room/map
lamp Output OFFAny door
switchON (open)
0V
OFF (closed) Battery voltage
65 V All door lock actuators
(lock) Output OFFOFF (neutral)
0V
ON (lock) Battery voltage
66 G/Y Front door lock actua-
tor RH, rear door lock
actuators LH/RH and
back door lock actua-
tor (unlock) Output OFF
OFF (neutral)
0V
ON (unlock) Battery voltage
67 B Ground Input ON—0V
68 W/L Power window power
supply (RAP) Output —Ignition switch ON
Battery voltage
Within 45 seconds after igni-
tion switch OFF Battery voltage
More than 45 seconds after ig-
nition switch OFF 0V
When front door LH or RH is
open or power window timer
operates 0V
69 W/R Power window power
supply
Output —
—Battery voltage
70 W/B Battery power supply Input OFF —Battery voltage
Te r m i n a l
Wire
color Signal name Signal
input/
output Measuring condition
Reference value or waveform
(Approx.)
Ignition
switch Operation or condition
SKIA3009J
SKIA3009J
Revision: April 20092010 QX56

DOOR MIRROR REMOTE CONTROL SWITCHADP-177
< ON-VEHICLE REPAIR >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
DOOR MIRROR REMOTE CONTROL SWITCH
Removal and InstallationINFOID:0000000005147595
The door mirror remote control switch is part of the power window switch assembly. Refer to INT-11, "Removal
and Installation" for removal and installation of door mirror remote control switch.
Revision: April 20092010 QX56

AV
AV CONTROL UNITAV-115
< ECU DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
72
(B) 71 MIC signal
InputIgnition
switch ON ——
79
(G/R) Ground
IGN ON or START power
supply InputIgnition
switch ON or
START —
Battery voltage
80
(G) Ground Parking brake signal Input Ignition
switch ON Parking brake ON
0V
Parking brake OFF Battery voltage
81
(G/W) Ground Reverse signal
InputIgnition
switch
ON R position
Battery voltage
Other than R position 0V
82
(W/R) Ground
Vehicle speed signal (8-
pulse) InputIgnition
switch
ON When vehicle speed is ap-
prox. 40 km/h (25MPH)
84
(BR) —Rear view camera control
signal
Input —
— —
86
(B) Ground Ground
—Ignition
switch ON —0
V
87
(B) Ground Ground
—Ignition
switch
ON —0
V
92
(L/W) —
AV communication signal 2
(H) Input/
Output ——
—
93
(B/P) —AV communication signal 2
(L) Input/
Output ——
—
94
(W/L) —AV communication signal 1
(H) Input/
Output ——
—
95
(P/B) —
AV communication signal 1
(L) Input/
Output ——
—
96
(L) —CAN–H Input/
Output ——
—
97
(P) —C

AN–L Input/
Output ——
—
121 (B) Ground Antenna amp. ON signal Output Ignition
switch ACC —
Battery voltage
122 (B) — Amplified window antenna
signal
Input —
— —
123 — GPS antenna signal — —— —
124 — Shield — —— —
125 — Satellite antenna signal Input Ignition
switch ACC ——
Te r m i n a l
(Wire color) Description
ConditionReference value
(Approx.)
+ – Signal nameInput/
Output
SKIA6649J
Revision: April 20092010 QX56

BCS
BCS-1
ELECTRICAL & POWER CONTROL
C
DE
F
G H
I
J
K L
B
SECTION BCS
A
O P
N
CONTENTS
BODY CONTROL SYSTEM
BCM
BASIC INSPECTION ....... .............................
3
INSPECTION AND ADJUSTMENT ................ .....3
ADDITIONAL SERVICE WHEN REPLACING
CONTROL UNIT .................................................... ......
3
ADDITIONAL SERVICE WHEN REPLACING
CONTROL UNIT : Description ..................................
3
ADDITIONAL SERVICE WHEN REPLACING
CONTROL UNIT : Special Repair Requirement .......
3
CONFIGURATION ................................................. ......3
CONFIGURATION : Description ...............................3
CONFIGURATION : Special Repair Requirement ......4
FUNCTION DIAGNOSIS .. .............................5
BODY CONTROL SYSTEM ........................... .....5
System Description ............................................. ......5
Component Parts Location ........................................6
COMBINATION SWITCH READING SYSTEM
.....
7
System Diagram .................................................. ......7
System Description ...................................................7
Component Parts Location ......................................10
SIGNAL BUFFER SYSTEM ...............................12
System Diagram .................................................. ....12
System Description .................................................12
POWER CONSUMPTION CONTROL SYS-
TEM ....................................................................
13
System Diagram .................................................. ....13
System Description .................................................13
Component Parts Location ......................................15
DIAGNOSIS SYSTEM (BCM) ............................16
COMMON ITEM ..................................................... ....16
COMMON ITEM : CONSULT-III Function (BCM -
COMMON ITEM) .....................................................
16
BCM ....................................................................... ....16
BCM : CONSULT-III Function (BCM - BCM) ...........17
DOOR LOCK .......................................................... ....17
DOOR LOCK : CONSULT-III Function (BCM -
DOOR LOCK) ..........................................................
17
REAR WINDOW DEFOGGER ............................... ....17
REAR WINDOW DEFOGGER : CONSULT-III
Function (BCM - REAR DEFOGGER) .....................
18
BUZZER ................................................................. ....18
BUZZER : CONSULT-III Function (BCM - BUZZ-
ER) ..........................................................................
18
INT LAMP ............................................................... ....18
INT LAMP : CONSULT-III Function (BCM - INT
LAMP) ......................................................................
19
MULTIREMOTE ENT ............................................. ....20
MULTIREMOTE ENT : CONSULT-III Function
(BCM - MULTIREMOTE ENT) .................................
20
HEADLAMP ........................................................... ....21
HEADLAMP : CONSULT-III Function (BCM -
HEAD LAMP) ...........................................................
22
WIPER .................................................................... ....23
WIPER : CONSULT-III Function (BCM - WIPER) ....23
FLASHER ............................................................... ....24
FLASHER : CONSULT-III Function (BCM -
FLASHER) ...............................................................
24
AIR CONDITIONER ............................................... ....24
AIR CONDITIONER : CONSULT-III Function
(BCM - AIR CONDITIONER) ...................................
24
INTELLIGENT KEY ................................................ ....25
INTELLIGENT KEY : CONSULT-III Function
(BCM - INTELLIGENT KEY) ....................................
25
Revision: April 20092010 QX56

BCS
BODY CONTROL SYSTEMBCS-5
< FUNCTION DIAGNOSIS > [BCM]
C
D
E
F
G H
I
J
K L
B A
O P
N
FUNCTION DIAGNOSIS
BODY CONTROL SYSTEM
System DescriptionINFOID:0000000005146384
OUTLINE
• BCM (Body Control Module) controls the various electrical components. It inputs the information required to
the control from CAN communication and the signal received from each switch and sensor.
• BCM has combination switch reading function for reading the operation status of combination switches (light,
turn signal, wiper and washer) in addition to a function fo r controlling the operation of various electrical com-
ponents. It also has the signal transmission function as the passed point of signal and the power consump-
tion control function that reduces the power consumption with the ignition switch OFF.
• BCM is equipped with the diagnosis function that perfo rms the diagnosis with CONSULT-III and various set-
tings.
BCM control function list
System Refer to
Combination switch reading system BCS-7, "
System Diagram"
Signal buffer systemBCS-12, "System Diagram"
Power consumption control systemBCS-13, "System Diagram"
Auto light systemEXL-11, "System Diagram"
Turn signal and hazard warning lamp systemEXL-15, "System Diagram"
Headlamp systemEXL-14, "System Diagram"
Front fog lamp systemEXL-14, "System Diagram"
Daytime running light system (if equipped)EXL-9, "System Diagram"
Interior room lamp control systemINL-6, "System Diagram"
Step lamp systemINL-6, "System Diagram"
Interior room lamp battery saver systemINL-6, "System Diagram"
Front wiper and washer systemWW-4, "System Diagram"
Rear wiper and washer systemWW-8, "System Diagram"
Warning chime systemWCS-4, "WARNING CHIME SYSTEM : System Diagram"
Door lock system DLK-14, "DOOR LOCK AND UNLOCK SWITCH : System Diagram"
(NATS) Nissan anti-theft systemSEC-14, "System Diagram"
Vehicle security systemSEC-18, "System Diagram"
Rear window defogger systemDEF-4, "System Diagram"
Intelligent Key systemSEC-10, "System Diagram"
Power window systemPWC-5, "SystemDiagram"
RAP (retained accessory power) systemBCS-27, "RETAINED PWR : CONSULT-III Function (BCM - RETAINED
PWR)"
TPMS (tire pressure monitoring system)
BCS-30, "AIR PRESSURE MONITOR : CONSULT-III Function"
Revision: April 20092010 QX56

BCS-16
< FUNCTION DIAGNOSIS >[BCM]
DIAGNOSIS SYSTEM (BCM)
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT-III Fu
nction (BCM - COMMON ITEM)INFOID:0000000005146394
APPLICATION ITEM
CONSULT-III performs the following functions via CAN communication with BCM.
SYSTEM APPLICATION
BCM can perform the following functions for each system.
NOTE:
It can perform the diagnosis modes except the following for all sub system selection items.
BCM
Diagnosis mode Function Description
WORK SUPPORT Changes the setting for each system function.
SELF-DIAG RESULTS Displays the diagnosis results judged by BCM. Refer to BCS-54, "
DTCIndex".
CAN DIAG SUPPORT MNTR Monitors the reception status of CAN communication viewed from BCM.
DATA MONITOR The BCM input/output signals are displayed.
ACTIVE TEST The signals used to activate each device are forcibly supplied from BCM.
ECU IDENTIFICATION The BCM part number is displayed.
CONFIGURATION • Enables to read and save the vehicle specification.
• Enables to write the vehicle specification when replacing BCM.
System
Sub system selection item Diagnosis mode
WORK SUPPORT DATA MONITOR ACTIVE TEST
BCM BCM ×
Door lock DOOR LOCK ×××
Rear window defogger REAR DEFOGGER ×
Warning chime BUZZER ××
Interior room lamp timer INT LAMP ×××
Remote keyless entry system MULTI REMOTE ENT ××
Exterior lamp HEAD LAMP ×××
Wiper and washer WIPER ×××
Turn signal and hazard warning lamps FLASHER ××
Air conditioner AIR CONDITONER ×
Intelligent Key system INTELLIGENT KEY ×
Combination switch COMB SW ×
Immobilizer IMMU ××
Interior room lamp battery saver BATTERY SAVER ×××
Back door open TRUNK ××
RAP (retained accessory power) RETAINED PWR ×××
Signal buffer system SIGNAL BUFFER ××
TPMS (tire pressure monitoring sys-
tem) AIR PRESSURE MONITOR
×××
Vehicle security system THEFT ALM ×××
Panic alarm system PANIC ALARM ×
Revision: April 20092010 QX56
