2010 HUMMER H3 Owners Manual

Service and Maintenance 11-13
Maintenance Record (cont'd)
DateOdometer
Reading Serviced By Services Performed

11-14 Service and Maintenance
Maintenance Record (cont'd)
DateOdometer
Reading Serviced By Services Performed

Technical Data 12-1
Technical Data
Vehicle Identification
Vehicle IdentificationNumber (VIN) . . . . . . . . . . . . . . 12-1
Service Parts Identification Label . . . . . . . . . . . . . . . . . . . . . . . 12-1
Vehicle Data
Capacities andSpecifications . . . . . . . . . . . . . . 12-2
Engine Drive Belt Routing . . . 12-4
Vehicle Identification
Vehicle Identification
Number (VIN)
This legal identifier is in the front
corner of the instrument panel, on
the left side of the vehicle. It can be
seen through the windshield from
outside. The VIN also appears on
the Vehicle Certification and Service
Parts labels and certificates of title
and registration.
Engine Identification
The eighth character in the VIN
is the engine code. This code
identifies the vehicle's engine,
specifications, and replacement
parts. See “Engine Specifications”
under Capacities and Specifications
on page 12‑2for the vehicle's
engine code.
Service Parts
Identification Label
This label, on the inside of the glove
box, has the following information:
.Vehicle Identification
Number (VIN)
.Model designation
.Paint information
.Production options and special
equipment
Do not remove this label from the
vehicle.

12-2 Technical Data
Vehicle Data
Capacities and Specifications
The following approximate capacities are given in English and metric. Please refer toRecommended Fluids and
Lubricantson page 11‑8for more information.
Capacities and Specifications
Application Capacities
Metric English
Air Conditioning Refrigerant R134a For the air conditioning system refrigerant charge
amount, see the refrigerant caution label located under the hood. See your dealer for more information.
Cooling System 3.7L L5 Engine 9.5 L 10.0 qt
5.3L V8 Engine 13.5 L 14.3 qt
Engine Oil with Filter 3.7L L5 and 5.3L V8 Engines 5.7 L 6.0 qt
Fuel Tank H3 87.1 L 23.0 gal
H3T 102.2 L 27.0 gal

Technical Data 12-3
Capacities and Specifications (cont'd)
ApplicationCapacities
Metric English
Transfer Case 1.5 L 1.6 qt
Transmission 3.7L L5 and 5.3L V8, Automatic Transmission
(Pan Removal and Filter Replacement) 4.7 L 5.0 qt
3.7L L5, Manual Transmission (Drain and Refill) 2.4 L 2.5 qt
Wheel Nut Torque 140 Y100 lb ft
All capacities are approximate. When adding, be sure to fill to the approximate level, as recommended in this
manual.
Engine Specifications
Engine VIN CodeTransmission Spark Plug Gap
3.7L L5 EAutomatic
Manual 1.01 mm (0.040 in)
5.3L V8 PAutomatic 1.01 mm (0.040 in)

12-4 Technical Data
Engine Drive Belt Routing
3.7L L5 Engine
5.3L V8 Engine

Customer Information 13-1
Customer
Information
Customer Information
Customer SatisfactionProcedure . . . . . . . . . . . . . . . . . . 13-1
Customer Assistance Offices . . . . . . . . . . . . . . . . . . . . . 13-3
Customer Assistance for Text Telephone (TTY) Users . . . . . 13-4
Online Owner Center . . . . . . . . 13-4
Roadside Service . . . . . . . . . . . . 13-5
Scheduling Service Appointments . . . . . . . . . . . . . . 13-8
Courtesy Transportation Program . . . . . . . . . . . . . . . . . . . . 13-8
Collision Damage Repair . . . 13-10
Service Publications Ordering Information . . . . . . 13-12
Reporting Safety Defects
Reporting Safety Defects tothe United States
Government . . . . . . . . . . . . . . . 13-13
Reporting Safety Defects to the Canadian
Government . . . . . . . . . . . . . . . 13-14
Reporting Safety Defects to General Motors . . . . . . . . . . . 13-14
Vehicle Data Recording and
Privacy
Vehicle Data Recording andPrivacy . . . . . . . . . . . . . . . . . . . . 13-15
Event Data Recorders . . . . . . 13-15
OnStar
®. . . . . . . . . . . . . . . . . . . . 13-16
Navigation System . . . . . . . . . 13-16
Radio Frequency Identification (RFID) . . . . . . . 13-16
Radio Frequency Statement . . . . . . . . . . . . . . . . . 13-16
Customer Information
Customer Satisfaction
Procedure
Your satisfaction and goodwill are
important to your dealer and to
HUMMER. Normally, any concerns
with the sales transaction or the
operation of the vehicle will be
resolved by the dealer's sales or
service departments. Sometimes,
however, despite the best intentions
of all concerned, misunderstandings
can occur. If your concern has not
been resolved to your satisfaction,
the following steps should be taken:
STEP ONE: Discuss your concern
with a member of dealership
management. Normally, concerns
can be quickly resolved at that level.
If the matter has already been
reviewed with the sales, service or
parts manager, contact the owner
of the dealership or the general
manager.

13-2 Customer Information
STEP TWO:If after contacting a
member of dealership management,
it appears your concern cannot be
resolved by the dealership without
further help, call the HUMMER
Consumer Relations Manager at
1-866-HUMMER6 (486-6376),
Customer Assistance prompt.
In Canada, call GM of Canada
Customer Communication Centre
at 1-800-263-3777 (English),
or 1-800-263-7854 (French).
We encourage you to call the
toll-free number in order to give your
inquiry prompt attention. Have the
following information available to
give the Customer Assistance
Representative:
.Vehicle Identification Number
(VIN). This is available from the
vehicle registration or title, or
the plate at the top left of the
instrument panel and visible
through the windshield.
.Dealership name and location
.Vehicle delivery date and
present mileage
When contacting HUMMER, please
remember that your concern will
likely be resolved at a dealer's
facility. That is why we suggest you
follow Step One first if you have a
concern.
STEP THREE —U.S. Owners:
Both HUMMER and your dealer are
committed to making sure you are
completely satisfied with your new
vehicle. However, if you continue to
remain unsatisfied after following
the procedure outlined in Steps One
and Two, you can file with the Better
Business Bureau (BBB) Auto Line
Program to enforce any additional
rights you may have. The BBB Auto Line Program is an
out of court program administered
by the Council of Better Business
Bureaus to settle automotive
disputes regarding vehicle repairs or
the interpretation of the New Vehicle
Limited Warranty. Although you may
be required to resort to this informal
dispute resolution program prior to
filing a court action, use of the
program is free of charge and your
case will generally be heard within
40 days. If you do not agree with the
decision given in your case, you
may reject it and proceed with any
other venue for relief available
to you.
