Keys, Doors and Windows 2-3
If there is a decrease in the RKE
operating range:
.Check the distance.
The transmitter may be
too far from the vehicle.
.Check the location. Other
vehicles or objects may be
blocking the signal.
.Check the transmitter's battery.
See“Battery Replacement” later
in this section.
.If the transmitter is still not
working correctly, see your
dealer or a qualified technician
for service.
Remote Keyless Entry
(RKE) System Operation
The Remote Keyless Entry (RKE)
transmitter functions work up to 9 m
(30 feet) away from the vehicle.
There are other conditions which
can affect the performance of the
transmitter. See Remote Keyless
Entry (RKE) System on page 2‑2.
LOCK: Press to lock all the doors.
The parking lamps may flash and
the horn may chirp.
If a door is open or ajar when LOCK
is pressed, the doors lock, but the
theft-deterrent system does not arm
until the open door is closed.
Pressing LOCK may arm the
content theft-deterrent system.
See Anti-Theft Alarm System
on
page 2‑9for additional information. UNLOCK:
Press to unlock only the
driver's door. The interior lamps
come on, the parking lamps may
flash, and the horn may sound.
Press UNLOCK again within
three seconds to unlock all the
doors.
Pressing UNLOCK may disarm the
content theft-deterrent system.
See Anti-Theft Alarm System
on
page 2‑9for additional information.
Different feedback choices can be
programmed through the Driver
Information Center (DIC). See
“Remote Keyless Entry Feedback”
under Driver Information Center
(DIC) on page 5‑18.
L (Panic): Press to activate the
alarm. The horn sounds and the
headlamps and taillamps flash for
up to 30 seconds. To turn the alarm
off press Lagain, start the vehicle
or wait 30 seconds.

2-4 Keys, Doors and Windows
Programming Transmitters to
the Vehicle
Only RKE transmitters
programmed to this vehicle will
work. If a transmitter is lost or
stolen, a replacement can be
purchased and programmed through
your dealer. When the replacement
transmitter is programmed to this
vehicle, all remaining transmitters
must also be reprogrammed.
Any lost or stolen transmitters
will no longer work once the new
transmitter is programmed. Each
vehicle can have up to four
transmitters programmed to it.
Battery Replacement
The battery in the transmitter is
weak and should be changed if it
does not work at the normal range
in any location.
Notice:When replacing the
battery, do not touch any of the
circuitry on the transmitter. Static
from your body could damage the
transmitter. To replace the battery:
1. Separate the transmitter with a
flat, thin object inserted into the
notch on the side.
2. Remove the old battery. Do not use a metal object.
3. Insert the new battery. Replace with a CR2032 or equivalent
battery.
4. Snap the transmitter back together.
Door Locks
{WARNING
Unlocked doors can be
dangerous.
.Passengers, especially
children, can easily open the
doors and fall out of a moving
vehicle. When a door is
locked, the handle will not
open it. The chance of being
thrown out of the vehicle in
a crash is increased if the
doors are not locked. So, all
passengers should wear
safety belts properly and the
doors should be locked
whenever the vehicle is
driven.
(Continued)

Keys, Doors and Windows 2-5
WARNING (Continued)
.Young children who get into
unlocked vehicles may be
unable to get out. A child can
be overcome by extreme heat
and can suffer permanent
injuries or even death from
heat stroke. Always lock the
vehicle whenever leaving it.
.Outsiders can easily enter
through an unlocked door
when you slow down or stop
your vehicle. Locking your
doors can help prevent this
from happening.
There are several ways to lock and
unlock the vehicle. From the outside, use the key in the
driver's door or use the Remote
Keyless Entry (RKE) transmitter.
From the inside, use the manual
lock levers or power door lock
switch.
Power Door Locks
Driver side shown
The power door lock switches are
located on the driver and the front
passenger doors.
Press L (Lock) to lock all the doors
at once. To unlock all the doors,
press U (Unlock).

2-6 Keys, Doors and Windows
Automatic Door Locks
With an automatic transmission,
the vehicle is pre-programmed to
automatically lock the doors when
shifted out of P (Park). All doors
unlock when the vehicle is shifted
back into P (Park).
With a manual transmission, the
vehicle is pre-programmed to
automatically lock the doors when
the vehicle speed reached 15 mph
(24 km/h). Removing the key from
the ignition unlocks the doors.
To program the automatic door
locks, see“Automatic Door Locks”
under Driver Information Center
(DIC) on page 5‑18.
Lockout Protection
This feature protects against locking
the key in the vehicle when it is in
the ignition. A chime sounds as an alert to
indicate that the key has been left in
the ignition. When the power door
lock switch is pressed, a door is
open, and the key is in the ignition
all of the doors lock and then the
driver's door unlocks.
Safety Locks
Each rear door can be locked so it
cannot be opened from the inside.
The rear door security lock is
located on the inside edge of each
rear door.To engage a security lock:
1. Open one of the rear doors.
2. Use the ignition key to turn the
lock toward the front of the
vehicle.
3. Close the door.
4. Repeat these steps on the other rear door.
To open a rear door when the
security lock is set, unlock the door
and open the door from the outside.
To disengage a security lock:
1. Open one of the rear doors.
2. Use the ignition key to turn the lock to the vertical position.
3. Close the door.
4. Repeat these steps on the other rear door.

Keys, Doors and Windows 2-7
Doors
Tailgate
Tailgate (H3T)
{WARNING
It is extremely dangerous to ride
on the tailgate, even when the
vehicle is operated at low speeds.
People riding on the tailgate
can easily lose their balance
and fall in response to vehicle
maneuvers. Falling from a moving
vehicle may result in serious
injuries or death. Do not allow
people to ride on the tailgate.
Be sure everyone in your vehicle
is in a seat and using a safety
belt properly.
Open the tailgate by pulling up on
the outside handle while pulling the
tailgate down.
When putting the tailgate up, be
sure it latches securely.Removing the Tailgate
To remove the tailgate:
1. Open the tailgate fully and
remove the retainer clip from the
driver's side hinge.
It is recommended that the
retainer clip be stored in a safe
place, like the glove box.

2-8 Keys, Doors and Windows
2. Lift up slightly on the entiretailgate assembly.
Remove the retaining cables
from both sides of the pickup
box by pulling the clips away
from the bolt heads while
pushing the cable bracket
forward. When the larger part of
the hole on the bracket is over
the bolt, slide the bracket off of
the bolt.
3. With the tailgate partially down, lift up on the passenger's side
and pull the tailgate toward you,
then move the tailgate to the
right to release the driver's side.
Reverse the procedure to reinstall
the tailgate. Make sure it is secure. To partially lower the tailgate:
1. With the tailgate fully open, lift
up slightly on the entire tailgate
assembly.
Tailgate Partially Down
2. Remove the retaining cable from the passenger side of the pickup
box by pulling the clip away from
the bolt head while pushing the
cable bracket forward.
When the larger part of the hole
on the bracket is over the bolt,
slide the bracket off of the bolt. 3. Slide the lower end fitting onto
the front bolt. The tailgate will
now stay in the partially opened
position.
4. Repeat Steps 2 and 3 for the driver side.
When closing the tailgate the
bracket cannot be in the partially
opened position. It must be
anchored on the rear bolt using
the top position on the bracket.
Swing-gate (H3)
To lock or unlock the swing‐gate,
use the power door lock switch or
the Remote Keyless Entry (RKE)
transmitter.
{WARNING
Make sure the swing‐gate is
completely closed. Driving with
the swing‐gate open could injure
pedestrians or damage the
vehicle.

Keys, Doors and Windows 2-9
To open the swing‐gate, use the
door handle to pull the swing-gate
rearward slightly so it opens
automatically.
Vehicle Security
Vehicle theft is big business,
especially in some cities. This
vehicle has theft-deterrent features,
however, they do not make it
impossible to steal.
Anti-Theft Alarm System
This vehicle has a content
theft-deterrent alarm system.
The security light is located on the
instrument panel cluster.
To arm the system:
1. Close all the doors.
2. Lock the doors with the RemoteKeyless Entry (RKE) transmitter.
The security light flashes. If the lock button on the RKE
transmitter is pressed, but a door is
open, the doors lock, the lights may
flash and the horn may sound.
Close the open door to arm the
system.
The alarm goes off if a locked door
is not opened using the RKE
transmitter, or by OnStar
®.
A pre-alarm sounds the horn at
reduced intensity for 10 seconds.
Then, the front turn signal lamps
flash for two minutes, and the horn
sounds for two minutes. The alarm
then turns off to save battery power.
Start the engine to turn off the
alarm.
The theft-deterrent system does
not activate if the doors are locked
with the key, the manual door lock,
or power door lock switch. The
system can only be activated using
the RKE transmitter, or by OnStar.
See the OnStar Owner's Guide for
additional information. The vehicle
can be started with the correct key if
the alarm has been set off.

2-10 Keys, Doors and Windows
To avoid setting off the alarm by
accident:
.Lock the vehicle with the manual
door lock lever, the power door
lock switch, or the key, after the
doors are closed.
.Unlock the doors by pressing
the unlock button on the RKE
transmitter or by contacting
OnStar. Unlocking a door any
other way activates the alarm.
Press unlock on the RKE
transmitter, start the vehicle with
the correct key, or have OnStar
unlock the doors to turn the alarm
off. The alarm does not stop if a
door is unlocked any other way.
Testing the Alarm
To test the alarm:
1. From inside the vehicle, lock the doors with the RKE transmitter.
2. Unlock the door with the manual door lock and open the door.
The pre-alarm should sound
followed by the full alarm about
10 seconds later.
3. Press the unlock button on the RKE transmitter or start the
engine to turn the alarm off.
If the alarm does not sound but the
lights flash, check to see if the horn
works. The horn fuse could be
blown. To replace the fuse, see
Fuses and Circuit Breakers
on
page 10‑39.
If the alarm does not sound or the
front turn signal lamps do not flash,
see your dealer for service.
Immobilizer
See Radio Frequency Statementon
page 13‑16for information
regarding Part 15 of the Federal
Communications Commission (FCC)
Rules and RSS-210/211 of Industry
Canada.
Immobilizer
Operation (U.S.)
Passlock®is a passive
theft-deterrent system that enables
fuel if the vehicle is started with a
valid key. If an incorrect key is used
or the ignition lock cylinder is
tampered with, the fuel system is
disabled and the vehicle does not
start.
The security light turns off
approximately five seconds after
the engine is started. See Security
Light on page 5‑17.
