2010 FORD F150 Raptor Supplement Manual

95,000 miles (152,000 km)
❑Change engine oil and replace oil filter❑Rotate tires, inspect tires for wear and measure tread depth❑Inspect the wheels and related components for abnormal
noise, wear, looseness, or drag
❑Perform multi-point inspection (recommended)
DEALERVALIDATION:
RO#: P&A C
ODE:
D
ATE:MILEAGE:
100,000 miles (160,000 km)
❑Change engine oil and replace oil filter❑Inspect accessory drive belt(s), replace if necessary❑Replace spark plugs❑Rotate tires, inspect tires for wear and measure tread depth❑Inspect the wheels and related components for abnormal
noise, wear, looseness, or drag
❑Perform multi-point inspection (recommended)
DEALERVALIDATION:
RO#: P&A C
ODE:
D
ATE:MILEAGE:
105,000 miles (168,000 km)
❑Change engine oil and replace oil filter❑Replace engine coolant (see Engine Coolant Change Interval
on page 33 and Coolant Change Record on page 56)
❑Rotate tires, inspect tires for wear and measure tread depth❑Inspect the wheels and related components for abnormal
noise, wear, looseness, or drag
❑Inspect brake pads/shoes/rotors/drums, brake lines & hoses
and parking brake system
❑Inspect engine cooling system and hoses❑Inspect steering linkage, ball joints, suspension, half shafts,
driveshafts and U-joints
❑Perform multi-point inspection (recommended)
DEALERVALIDATION:
RO#: P&A C
ODE:
D
ATE:MILEAGE:
Scheduled Maintenance Guide
49
2010 F-150(f12)
Supplement, 1st Printing
USA(fus)

110,000 miles (176,000 km)
❑Change engine oil and replace oil filter❑Rotate tires, inspect tires for wear and measure tread depth❑Inspect the wheels and related components for abnormal
noise, wear, looseness, or drag
❑Perform multi-point inspection (recommended)
DEALERVALIDATION:
RO#: P&A C
ODE:
D
ATE:MILEAGE:
115,000 miles (184,000 km)
❑Change engine oil and replace oil filter❑Rotate tires, inspect tires for wear and measure tread depth❑Inspect the wheels and related components for abnormal
noise, wear, looseness, or drag
❑Perform multi-point inspection (recommended)
DEALERVALIDATION:
RO#: P&A C
ODE:
D
ATE:MILEAGE:
120,000 miles (192,000 km)
❑Change engine oil and replace oil filter❑Replace engine air filter❑Change automatic transmission fluid and filter❑Rotate tires, inspect tires for wear and measure tread depth❑Inspect accessory drive belt(s), replace if necessary❑Inspect the wheels and related components for abnormal
noise, wear, looseness, or drag
❑Inspect brake pads/shoes/rotors/drums, brake lines & hoses
and parking brake system
❑Inspect engine cooling system and hoses❑Inspect exhaust system and heat shields❑Inspect steering linkage, ball joints, suspension, half shafts,
driveshafts and U-joints
❑Perform multi-point inspection (recommended)
DEALERVALIDATION:
RO#: P&A C
ODE:
D
ATE:MILEAGE:
Scheduled Maintenance Guide
50
2010 F-150(f12)
Supplement, 1st Printing
USA(fus)

125,000 miles (200,000 km)
❑Change engine oil and replace oil filter❑Rotate tires, inspect tires for wear and measure tread depth❑Inspect the wheels and related components for abnormal
noise, wear, looseness, or drag
❑Perform multi-point inspection (recommended)
DEALERVALIDATION:
RO#: P&A C
ODE:
D
ATE:MILEAGE:
130,000 miles (208,000 km)
❑Change engine oil and replace oil filter❑Rotate tires, inspect tires for wear and measure tread depth❑Inspect the wheels and related components for abnormal
noise, wear, looseness, or drag
❑Perform multi-point inspection (recommended)
DEALERVALIDATION:
RO#: P&A C
ODE:
D
ATE:MILEAGE:
135,000 miles (216,000 km)
❑Change engine oil and replace oil filter❑Rotate tires, inspect tires for wear and measure tread depth❑Inspect the wheels and related components for abnormal
noise, wear, looseness, or drag
❑Inspect brake pads/shoes/rotors/drums, brake lines & hoses
and parking brake system
❑Inspect engine cooling system and hoses❑Inspect steering linkage, ball joints, suspension, half shafts,
driveshafts and U-joints
❑Perform multi-point inspection (recommended)
DEALERVALIDATION:
RO#: P&A C
ODE:
D
ATE:MILEAGE:
Scheduled Maintenance Guide
51
2010 F-150(f12)
Supplement, 1st Printing
USA(fus)

140,000 miles (224,000 km)
❑Change engine oil and replace oil filter❑Rotate tires, inspect tires for wear and measure tread depth❑Inspect the wheels and related components for abnormal
noise, wear, looseness, or drag
❑Perform multi-point inspection (recommended)
DEALERVALIDATION:
RO#: P&A C
ODE:
D
ATE:MILEAGE:
145,000 miles (232,000 km)
❑Change engine oil and replace oil filter❑Rotate tires, inspect tires for wear and measure tread depth❑Inspect the wheels and related components for abnormal
noise, wear, looseness, or drag
❑Perform multi-point inspection (recommended)
DEALERVALIDATION:
RO#: P&A C
ODE:
D
ATE:MILEAGE:
150,000 miles (240,000 km)
❑Change engine oil and replace oil filter❑Replace engine air filter❑Replace engine coolant (see Engine Coolant Change Interval
on page 33 and Coolant Change Record on page 56)
❑Replace transfer case fluid❑Replace front differential fluid❑Replace accessory drive belts if not replaced in the last
100,000 miles (160,000 km)
❑Rotate tires, inspect tires for wear and measure tread depth❑Inspect the wheels and related components for abnormal
noise, wear, looseness, or drag
❑Inspect brake pads/shoes/rotors/drums, brake lines & hoses
and parking brake system
❑Inspect engine cooling system and hoses❑Inspect exhaust system and heat shields❑Inspect steering linkage, ball joints, suspension, half shafts,
driveshafts and U-joints
❑Perform multi-point inspection (recommended)
DEALERVALIDATION:
RO#: P&A C
ODE:
D
ATE:MILEAGE:
Scheduled Maintenance Guide
52
2010 F-150(f12)
Supplement, 1st Printing
USA(fus)

ITEMS NEEDING SPECIAL ATTENTION
If you operate your Ford/Lincoln/Mercury vehicleprimarilyin one of the
more demandingSpecial Operating Conditionslisted below, you will
need to have some items maintained more frequently. If you only
occasionallyoperate your vehicle under these conditions, it is not
necessary to perform the additional maintenance. For specific
recommendations, see your Ford or Lincoln Mercury Dealership Service
Advisor or Technician.
Towing a trailer or using a camper or car-top carrier
Every 60,000 milesChange transfer case fluid
Extensive idling and/or low-speed driving for long distances
Inspect frequently, service as
requiredReplace cabin air filter
Every 200 hours of useChange engine oil
Every 5,000 milesInspect brake system
Lubricate control arm and steering ball joints if equipped
with zerk fittings
Every 60,000 milesReplace spark plugs
Change transfer case fluid
Operating in dusty conditions such as unpaved or dusty roads
Inspect frequently, service as
requiredReplace engine air filter
Replace cabin air filter (if equipped)
Every 5,000 miles or 6 monthsInspect and lubricate U-joints
Every 60,000 milesChange transfer case fluid
Scheduled Maintenance Guide
53
2010 F-150(f12)
Supplement, 1st Printing
USA(fus)

Off-road operation
Inspect frequently, service as
requiredReplace cabin air filter (if equipped)
Inspect and lubricate steering linkage ball joints and
U-joints if equipped with zerk fittings
Every 60,000 milesChange transfer case fluid
Use of E85 exclusively (flex fuel vehicles only)
Every 3,000 milesIf ran exclusively on E85, fill the tank full with regular
unleaded fuel.
Scheduled Maintenance Guide
54
2010 F-150(f12)
Supplement, 1st Printing
USA(fus)

SPECIAL OPERATING CONDITIONS LOG
Special Operating Conditions Log
DEALERVALIDATION:
RO#: P&A C
ODE:
DATE:MILEAGE:D
EALERVALIDATION:
RO#: P&A C
ODE:
DATE:MILEAGE:
D
EALERVALIDATION:
RO#: P&A C
ODE:
DATE:MILEAGE:D
EALERVALIDATION:
RO#: P&A C
ODE:
DATE:MILEAGE:
D
EALERVALIDATION:
RO#: P&A C
ODE:
DATE:MILEAGE:D
EALERVALIDATION:
RO#: P&A C
ODE:
DATE:MILEAGE:
D
EALERVALIDATION:
RO#: P&A C
ODE:
DATE:MILEAGE:D
EALERVALIDATION:
RO#: P&A C
ODE:
DATE:MILEAGE:
D
EALERVALIDATION:
RO#: P&A C
ODE:
DATE:MILEAGE:D
EALERVALIDATION:
RO#: P&A C
ODE:
DATE:MILEAGE:
Scheduled Maintenance Guide
55
2010 F-150(f12)
Supplement, 1st Printing
USA(fus)

In addition, there are several exceptions to the Normal Schedule. They
are listed below:
Current mileage goes here =>
Add 45,000 miles to the current miles + 45,000
Next change due at this mileage =>
Or
Today’s date goes here =>
Add 3 years + 00 / 00 / 03
Date of next change =>
whichever comes firstDealer Stamp
P & A CODE
R.O.#
Current mileage goes here =>
Add 45,000 miles to the current miles + 45,000
Next change due at this mileage =>
Or
Today’s date goes here =>
Add 3 years + 00 / 00 / 03
Date of next change =>
whichever comes firstDealer Stamp
P & A CODE
R.O.#
Normal Vehicle Axle Maintenance
❑Rear axles containing synthetic lubricant and light duty trucks equipped with Ford-design axles are lubricated for life. These
lubricants are not to be checked or changed unless a leak is suspected, service is required or the axle assembly has been
submerged in water. The axle and PTO lubricant should be changed anytime the axle and PTO have been submerged in
water. During extended trailer tow operation above 70°F ambient and wide open throttle for extended periods above
45 mph, non-synthetic rear axle lubricants should be replaced every 3,000 miles or 3 months, whichever occurs first. The
3,000 mile lube change interval may be waived if the axle was filled with 75W140 synthetic gear lubricant meeting Ford
specification WSL-M2C192-A, part number F1TZ-19580-B or equivalent. Add friction modifier C8AZ-19B546-A (EST-
M2C118-A) or equivalent for complete refill of Traction-Lok rear axles (see
Owner’s Guidefor quantity). The axle lubricant
should be changed anytime an axle has been submerged in water.
California Fuel Filter Replacement
❑If vehicle is registered in California, the California Air Resources Board has determined that the failure to perform this main-
tenance item will not nullify the emission warranty or limit recall liability prior to the completion of the vehicle’s useful life.
Ford Motor Company, however, urges you to have all recommended maintenance services performed at the specified inter-
vals and to record all vehicle service.
Scheduled Maintenance Guide
56
2010 F-150(f12)
Supplement, 1st Printing
USA(fus)
