2010.5 Peugeot 508 Owner's Manual

4
Familiarisation
Keyless Entry and Starting
This system allows you to unlock, lock and star t your vehicle while keeping the key on your person and in the defined zone around the vehicle.
This system measures the size of a space and advises whether parking is possible.
127
Exterior
Sto
This system puts the engine temporarily into standby during stops in the traffic (red lights, traffic jams, etc...). The engine restar ts automatically as soon as you want to move off. The Stop & Star t system reduces fuel consumption and exhaust emissions, and offers the comfor t of complete silence when stationary.
114

.
5
Familiarisation
Front and rear parking sensors
This system provides a warning when manoeuvering for wards and backwards by detecting obstacles located in front of or behind the vehicle.
125
Motorised tailgate (SW)
This system provides motorised opening and closing of the tailgate, by pressing a button.
53
Temporary puncture repair kit
This kit is a complete system consisting of a compressor and a sealant car tridge, to allow the temporary repair of a tyre.
170
Exterior

6
i
Familiarisation
Open
A. Unfolding/Folding the key. B. Unlocking the vehicle.
Remote control key
1. Opening the fuel filler flap.
Fuel tank
58
Unlocking
With the electronic key on your person and in the defined zone around the vehicle, pass your hand behind the door handle to unlock the vehicle, then pull on the handle to open the door.
Locking
With the electronic key in the defined zone around the vehicle, press with a finger on the door handle (at the markings) to lock the vehicle.
Keyless Entry and
Starting system
2. Opening and hooking the fuel filler cap. Tank capacity: approximately 72 litres (or 55 litres according to version).
Other functions...C. Normal locking of the vehicle Vehicle location.
39

.
7
Familiarisation
Interior
Interior mood lighting
This subdued passenger compar tment lighting improves visibility inside the vehicle in low lighting conditions.
Head-up display
This system projects speed and cruise control/speed limiter information onto a lightly smoked strip in the driver’s field of vision, so that they do not need to take their eyes off the road.
Digital air conditioning
After setting the desired level of comfor t, the system then automatically controls this level according to the exterior climatic
conditions. Manual
Audio and communication systems
These systems benefit from the latest technology: MP3 compatible audio systems, USB player, Bluetooth hands-free system, satellite navigation system with colour screen, auxiliary inputs, Hi-Fi audio system, ... Satellite navigation system
145
118
82
285
231
Audio system
85, 87
87
Dual-zone
Quad-zone
If your 508 is fitted with a JBLHi-Fi audio system, this is designed specifically for the passenger compar tment of your vehicle.

8
Familiarisation
Lighting of the indicator lamp indicates the state of the corresponding function.
Switch panels
Opening the boot.
Opening the fuel filler flap.
52, 53
Massage.
65
48
Alarm.
Programmable heating warning lamp.
58
93
Electric parking brake.
96
Star ting/stopping using the electronic key.
94
Deactivation of Stop & Star t.
115
Head-up display (on/off, settings).
118
Deactivation of parking sensors.
126
Parking space sensor.
127
Electric child lock.
156
Deactivation of the ESP/ASR system.
160
Adaptive lighting.
135

.
9
Familiarisation
Sitting comfortably
Front seats
61
Manual adjustments
1. Head restraint height and angle adjustment. 2. Backrest angle adjustment. 3. Seat cushion height adjustment. 4. Lumbar suppor t adjustment. 5. Seat for wards-backwards adjustment.
Electrical adjustment
1. Angle, seat height and seat for wards-backwards adjustment.
2. Backrest angle adjustment. 3. Lumbar suppor t adjustment.
62

10
Familiarisation
9. Fusebox. 10. Front door window demisting/defrosting vent. 11. Windscreen demisting/defrosting vent. 12. Steering lock and star ting with the key. 13. Star ting using the electronic key. 14. Audio equipment steering wheel controls. 15. Wiper/screenwash/trip computer stalk. 16. Central locking and hazard warning buttons. 17. Multifunction screen.
Instruments and controls
1. Cruise control/speed limiter controls. 2. Headlamp height adjustment. 3. Lighting and direction indicator stalk. 4. Instrument panel. 5. Driver's airbag. Horn. 6. Gear lever. 7. 12 V accessory socket USB por t /auxiliary socket. 8. Bonnet release lever.
18. Central adjustable air vents. 19. Passenger's airbag. 20. Side adjustable air vents. 21. Glove box /Passenger's airbag deactivation. 22. Electric parking brake. 23. Central armrest with storage. 24. Upper and lower storage. 25. Audio system. 26. Heating/air conditioning controls.

.
11
Familiarisation
