2010.5 Citroen C3 DAG Owner's Manual

FAMILIARISATION Rear parking sensors
This system provides a warning when
reversing by detecting obstacles located
behind the vehicle.


 118
Stop & Start
This system puts the engine temporar-
ily into standby during stops in the traf-
fi c (red lights, traffi c jams, etc...). The
engine restarts automatically as soon
as you want to move off. The Stop &
Start system reduces fuel consumption
and exhaust emissions, and provides
the comfort of complete silence when
stationary.


 111 Temporary puncture repair kit
This kit is a complete system consisting
of a compressor and sealant cartridge,
to allow the temporary repair of a tyre.


 127
Zenith windscreen
This large windscreen provides incompa-
rable visibility and light in the passenger
compartment.


 6
EXTERIOR

FAMILIARISATION
Remote control key Fuel tank

1. Opening the fuel fi ller fl ap.

2. Opening and hooking the fuel fi ller
cap.

A. Unfolding/Folding the key.

B. Unlocking the vehicle.


 60


 69

A. Interior release lever.

B. Exterior safety catch.

C. Bonnet stay.


 121
Bonnet
ACCESS

Other functions...

C. Normal locking of the vehicle
Vehicle location. Tank capacity:
- approximately 50 litres (petrol),
- approximately 48 litres (Diesel).

FAMILIARISATION
ZENITH WINDSCREEN
System comprising a panoramic tinted
glass area to increase lighting and vi-
sion in the cabin.
Fitted with a manual blind to improve
thermal comfort and sun visors to avoid
dazzle.
 To open the blind, take it by its cen-
tral grip A , then pull it backwards
and guide it to the desired position.

 To close the blind, take it by its cen-
tral grip A , then pull it forwards and
guide it to the desired position.
 Lower the sun visors to avoid dazzle.
Do not attach or hang heavy
objects to the blind or its guide
rails.
Blind Sun visors
Before moving the blind, the sun visors
must be in the folded position.

FAMILIARISATION
INTERIOR
Interior mood lighting
This subdued passenger compart-
ment lighting improves visibility inside
the vehicle in low lighting conditions. It
comprises 4 lamps, located in the au-
tomatic day/night mirror support, in the
footwells and in the lower dashboard
storage compartment.


 79
Gear shift indicator
Associated with the manual gearbox,
this system suggests when to change
up to obtain optimum fuel consumption.


 104 Scented air freshener
The scented air freshener diffuses the
selected fragrance throughout the pas-
senger compartment from its location in
the ventilation system.


 54
Digital air conditioning
After setting the desired level of com-
fort, the system then automatically con-
trols this level according to the ambient
conditions.


 51
Audio and communication systems
This equipment benefi ts from the lat-
est technology: MP3 compatible Audio
system, USB port, Bluetooth hands-free
system, MyWay with 16/9 colour screen,
auxiliary inputs, Hi-Fi audio system.

MyWay


 169

Audio system


 201

FAMILIARISATION
INSTRUMENTS AND CONTROLS

1. Cruise control/speed limiter
switches.

2. Headlamp height adjustment.

3. Steering wheel adjustment control.

4. Lighting and direction indicators
control stalk.

5. Instrument panel.

6. Driver's airbag.
Horn.

7. Gear lever.

8. 12 V accessory socket
USB port/auxiliary socket.

9. Heated seat control.

10. Bonnet release lever.

11. Door mirror controls.
Electric window controls.
Rear doors and electric windows deactivation control.

12. Fusebox.

13. Stop & Start button.
Electronic stability programme button (ESP/ASR).

14. Front door window demisting/
defrosting vent.

15. Speaker (tweeter).

16. Windscreen demisting/defrosting
vent.

FAMILIARISATION
INSTRUMENTS AND CONTROLS

1. Steering lock and ignition.

2. Audio equipment steering wheel
controls.

3. Wipers/screenwash/trip computer
control stalk.

4. Microphone.

5. Scented air freshener.

6. Central locking button.

7. Multifunction screen.

8. Hazard warning lamps switch.

9. Central adjustable air vents.

10. Sunshine sensor
Hi-Fi audio system central speaker.

11. Passenger's airbag.

12. Side adjustable air vent.

13. Glove box/Passenger's airbag
deactivation/Audio/video sockets.

14. Parking brake.

15. Central armrest with storage.

16. Upper and lower storage.

17. MyWay or Audio system.

18. Heating/air conditioning controls.

FAMILIARISATION Front seats
SITTING COMFORTABLY

1. Forwards-backwards adjustment.
2. Height adjustment.
3. Seat back angle adjustment.


 55

FAMILIARISATION
Other adjustments

4. Head restraint height adjustment.


 56 Steering wheel adjustment

1. Release the adjustment mechanism.

2. Height and reach adjustment.

3. Lock the adjustment mechanism.


 59 For reasons of safety, these op-
erations must only be carried out
with the vehicle stationary.

Other functions...
Heated seats.
SITTING COMFORTABLY
