2009 SATURN VUE Owners Manual

Seats and Restraint
System............................... 1-1
Head Restraints
.............. 1-2
Front Seats
.................... 1-3
Rear Seats
.................... 1-9
Safety Belts
..................1-10
Child Restraints
.............1-23
Airbag System
..............1-42
Restraint System
Check
......................1-58
Features and Controls...... 2-1
Keys
............................. 2-2
Doors and Locks
............ 2-7
Windows
......................2-10
Theft-Deterrent
Systems
...................2-12
Starting and Operating
Your Vehicle
.............2-15
Mirrors
.........................2-29
Object Detection
Systems
...................2-31
OnStar
®System
............2-33Universal Home Remote
System
.....................2-37
Storage Areas
...............2-41
Sunroof
........................2-45
Instrument Panel............... 3-1
Instrument Panel
Overview
.................... 3-4
Climate Controls
............3-17
Warning Lights, Gages,
and Indicators
............3-26
Driver Information
Center (DIC)
.............3-42
Audio System(s)
............3-64
Driving Your Vehicle......... 4-1
Your Driving, the Road,
and the Vehicle
........... 4-1
Towing
........................4-32
Service and
Appearance Care............... 5-1
Service
.......................... 5-3
Fuel
.............................. 5-5
Checking Things Under
the Hood
..................5-10All-Wheel Drive
.............5-35
Headlamp Aiming
..........5-36
Bulb Replacement
.........5-39
Windshield Wiper Blade
Replacement
.............5-42
Tires
...........................5-43
Appearance Care
..........5-72
Vehicle Identication
......5-79
Electrical System
...........5-79
Capacities and
Specications
............5-86
Maintenance Schedule...... 6-1
Maintenance Schedule
..... 6-1
Customer Assistance
Information........................ 7-1
Customer Assistance and
Information
................. 7-1
Reporting Safety
Defects
.....................7-14
Vehicle Data Recording
and Privacy
................. 16
Index....................................i-1
2009 Saturn VUE Owner ManualM
ProCarManuals.com

SATURN, the SATURN Emblem,
and the name VUE are registered
trademarks of Saturn Corporation.
GENERAL MOTORS and GM
are registered trademarks of
General Motors Corporation.
This manual includes the latest
information at the time it was
printed. Saturn reserves the right
to make changes after that time
without further notice.
This manual describes features
that may or may not be on
your specic vehicle.Read this manual from beginning to
end to learn about the vehicle’s
features and controls. Pictures,
symbols, and words work together
to explain vehicle operation.
Keep this manual in the vehicle for
quick reference.
Canadian Owners
A French language copy of this
manual can be obtained from your
dealer/retailer or from:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207
1-800-551-4123
www.helminc.com
Propriétaires Canadiens
On peut obtenir un exemplaire de
ce guide en français auprès de
concessionnaire ou à l’adresse
suivante:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207
1-800-551-4123
www.helminc.com
About Driving Your
Vehicle
As with other vehicles of this type,
failure to operate this vehicle
correctly may result in loss of control
or an accident. Be sure to read the
“on-pavement” and “off-road” driving
guidelines which follow in this
manual in the section called “Your
Driving, the Road, and Your Vehicle”,
and specicallyOff-Road Driving on
page 4-13.
ii Preface
Litho in U.S.A.
Part No. 25812262 B Second Printing©2008 General Motors Corporation. All Rights Reserved.
ProCarManuals.com

Index
To quickly locate information about
the vehicle, use the index in the back
of the manual. It is an alphabetical
list of what is in the manual and the
page number where it can be found.
Safety Warnings and
Symbols
A circle with a slash through it is a
safety symbol which means “Do Not,”
“Do not do this” or “Do not let this
happen.”
A box with the word CAUTION is
used to tell about things that could
hurt you or others if you were to
ignore the warning.
{CAUTION
These mean there is something
that could hurt you or other people.
Cautions tell what the hazard is and
what to do to avoid or reduce the
hazard. Read these cautions.
A notice tells about something that
can damage the vehicle.
Notice:These mean there is
something that could damage
your vehicle.
Many times, this damage would not
be covered by the vehicle’s warranty,
and it could be costly. The notice
tells what to do to help avoid the
damage.
There are also warning labels on
the vehicle which use the same
words, CAUTION or Notice.
Vehicle Symbols
The vehicle has components and
labels that use symbols instead
of text. Symbols are shown along
with the text describing the operation
or information relating to a specic
component, control, message,
gage, or indicator.
M:This symbol is shown when
you need to see your owner manual
for additional instructions or
information.
*:This symbol is shown when
you need to see a service manual
for additional instructions or
information.
Preface iii
ProCarManuals.com

Vehicle Symbol Chart
Here are some additional symbols
that may be found on the vehicle
and what they mean. For more
information on the symbol, refer to
the index.
9:Airbag Readiness Light
#:Air Conditioning
!:Antilock Brake System (ABS)
g:Audio Steering Wheel
Controls or OnStar®
$:Brake System Warning Light
":Charging System
I:Cruise Control
B:Engine Coolant Temperature
O:Exterior Lamps
#:Fog Lamps
.:Fuel Gage
+:Fuses
i:Headlamp High/Low-Beam
Changer
j:LATCH System Child Restraints
*:Malfunction Indicator Lamp
::Oil Pressure
}:Power
/:Remote Vehicle Start
>:Safety Belt Reminders
7:Tire Pressure Monitor
F:Traction Control
M:Windshield Washer Fluid
iv Preface
ProCarManuals.com

Seats and
Restraint System
Head RestraintsHead Restraints....................1-2
Front SeatsManual Seats.......................1-3
Seat Height Adjuster..............1-4
Power Seat..........................1-4
Manual Lumbar.....................1-5
Heated Seats.......................1-5
Reclining Seatbacks..............1-6
Passenger Folding Seatback. . . .1-8
Rear SeatsSplit Folding Rear Seat..........1-9
Safety BeltsSafety Belts: They Are
for Everyone.....................1-10
How to Wear Safety
Belts Properly....................1-14
Lap-Shoulder Belt................1-19
Safety Belt Use During
Pregnancy........................1-23
Safety Belt Extender............1-23
Child RestraintsOlder Children.....................1-23
Infants and Young Children. . . .1-26
Child Restraint Systems........1-29
Where to Put the Restraint.....1-30
Lower Anchors and Tethers
for Children (LATCH)..........1-31
Securing a Child Restraint
in a Rear Seat Position......1-37
Securing a Child Restraint
in the Right Front Seat
Position............................1-39
Airbag SystemAirbag System....................1-42
Where Are the Airbags?.......1-45
When Should an Airbag
Inate?.............................1-47
What Makes an Airbag
Inate?.............................1-49
How Does an Airbag
Restrain?..........................1-49
What Will You See After
an Airbag Inates?.............1-50
Passenger Sensing System. . . .1-51
Servicing Your
Airbag-Equipped Vehicle.....1-56
Adding Equipment to Your
Airbag-Equipped Vehicle.....1-57
Restraint System CheckChecking the Restraint
Systems...........................1-58
Replacing Restraint System
Parts After a Crash............1-59
Seats and Restraint System 1-1
ProCarManuals.com

Head Restraints
The front and rear seats have
adjustable head restraints in the
outboard seating positions.
{CAUTION
With head restraints that are not
installed and adjusted properly,
there is a greater chance that
occupants will suffer a neck/spinal
injury in a crash. Do not drive
until the head restraints for all
occupants are installed and
adjusted properly.Adjust the head restraint so that the
top of the restraint is at the same
height as the top of the occupant’s
head. This position reduces the
chance of a neck injury in a crash.Pull the head restraint up to raise it.
To lower the head restraint, press
the button, located on the top
of the seatback, and push the
restraint down.
1-2 Seats and Restraint System
ProCarManuals.com

Push down on the head restraint
after the button is released to make
sure that it is locked in place.
The head restraints are not
designed to be removed.
Active Head Restraint System
The vehicle has an active head
restraint system in the front outboard
seating positions. The active head
restraints automatically tilt forward to
reduce the risk of neck injury if
the vehicle is hit from behind.
Front Seats
Manual Seats
{CAUTION
You can lose control of the vehicle
if you try to adjust a manual
driver’s seat while the vehicle is
moving. The sudden movement
could startle and confuse you, or
make you push a pedal when you
do not want to. Adjust the driver’s
seat only when the vehicle is not
moving.To move a manual seat forward or
rearward:
1. Lift the bar to unlock the seat.
2. Slide the seat to the desired
position and release the bar.
Try to move the seat with your body
to be sure the seat is locked in
place.
Seats and Restraint System 1-3
ProCarManuals.com

Seat Height Adjuster
If the vehicle has a manual driver
seat height adjuster, it is located
on the outboard side of the seat
near the front of the seat cushion.
To raise the seat, move the lever
upward repeatedly until the seat is
at the desired height. To lower
the seat, move the lever downward
repeatedly until the seat is at the
desired height.
Power Seat
a
:To adjust the seat:
Move the seat forward or rearward.Raise or lower the front or rear part
of the seat cushion.
