< ON-VEHICLE REPAIR >[FRONT FINAL DRIVE: M205]
CARRIER COVER
CARRIER COVER
Removal and InstallationINFOID:0000000004193544
REMOVAL
1. Remove the front final drive assembly. Refer to
DLN-215, "Removal and Installation".
2. Remove the carrier cover bolts and separate the carrier cover from the gear carrier using Tool.
CAUTION:
 Do not damage the mating surface.
 Do not insert flat-bladed screwdr iver, this will damage the
mating surface.
INSTALLATION
1. Apply 3 mm (0.12 in) bead of sealant to the mating surface of the carrier cover as shown.
 Use Genuine Silicone RTV or equivalent. Refer to GI-15,
"Recommended Chemical Products and Sealants".
CAUTION:
Remove any old sealant adheri ng to the mating surfaces.
Also remove any moisture, oil, or foreign material adhering
to the application and mating surfaces.
2. Install the carrier cover to the gear carrier. Tighten the bolts to the specified torque. Refer to DLN-217, "Disassembly and
Assembly".
3. Install the front final drive assembly. Refer to DLN-215,
"Removal and Installation".
CAUTION:
Fill the front final drive assembly with r ecommended differential gear oil. Refer to DLN-209,
"Checking Differential Gear Oil".
Tool number : KV10111100 (J-37228)
PDIA0699E
SDIA3204E
Revision: December 20092009 QX56

FRONT FINAL DRIVEDLN-221
< DISASSEMBLY AND ASSEMBLY > [FRONT FINAL DRIVE: M205]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
2. Remove the differential side shaft and differential side flange using suitable tool.
3. Remove the extension tube and O-ring from the gear carrier.
4. Place a small hole in the side oil seal case using suitable tool.
5. Remove the side oil seal using Tool as shown.
6. Remove the carrier cover bolts and separate the carrier cover from the gear carrier using Tool.
CAUTION:
 Do not damage the mating surface.
 Do not insert flat-bladed screw driver, this will damage the
mating surface.
BDIA0006E
SDIA3205E
LDIA0129E
Tool number : SP8P
LDIA0130E
Tool number : KV10111100 (J-37228)
PDIA0699E
Revision: December 20092009 QX56

DLN-222
< DISASSEMBLY AND ASSEMBLY >[FRONT FINAL DRIVE: M205]
FRONT FINAL DRIVE
7. For proper reinstallation, paint matching marks on one side of
the side bearing cap and gear carrier.
CAUTION:
 For matching marks, use paint. Do not damage side bear-
ing cap or gear carrier.
 Side bearing caps are line-board during manufacture. The
matching marks are used to re install them in their original
positions.
8. Remove the side bearing caps.
9. Remove the side bearing adjuster.
10. Lift the differential case assembly out of the gear carrier. CAUTION:
Keep side bearing outer races together with side bearing
inner races. Do not mix them up.
11. Remove side bearing inner race using Tools as shown. CAUTION:
 Do not remove side bearing inner race unless it is beingreplaced.
 Place copper plates between th e vise and the side bearing
inner race and drive gear to prevent damage.
 Engage puller jaws in groo ve to prevent damage to bear-
ing.
PDIA0700E
PDIA0701E
SDIA2230E
SPD527
Tool number A: ST33081000 ( — )
B: ST30021000 ( — )
SDIA2237E
Revision: December 20092009 QX56

DLN-224
< DISASSEMBLY AND ASSEMBLY >[FRONT FINAL DRIVE: M205]
FRONT FINAL DRIVE
2. Remove the drive pinion lock nut using suitable tool.
3. Put matching marks on the companion flange and drive pinion using paint.
CAUTION:
Use paint to make the matching marks. Do not damage the companion flange or drive pinion.
4. Remove the companion flange using suitable tool.
5. Press the drive pinion assembly (with rear inner bearing race and collapsible spacer) out of the gear carrier.
CAUTION:
Do not drop drive pinion assembly.
6. Remove the drive pinion rear bearing inner race and drive pinion height adjusting washer using Tool.
PDIA0702E
PDIA0703E
SDIA2234E
Tool number : ST30021000 ( — )
S-PD179
Revision: December 20092009 QX56

DLN-228
< DISASSEMBLY AND ASSEMBLY >[FRONT FINAL DRIVE: M205]
FRONT FINAL DRIVE
ASSEMBLY
Drive Pinion Assembly
1. Install drive pinion rear bearing outer race using Tools.
2. Install drive pinion front bearing outer race using Tools.
3. Select drive pinion height adjusting washer.
OLD DRIVE
PINION
MARKING NEW DRIVE PINION MARKING mm (in)
-10 (-4) -8 (-3) -5 (-2) -3 (-1) 0 (0) + 3 (+1) +5 (+2) +8 (+3) +10 (+4)
+10 (+4) +0.20
(+0.008) +0.18
(+0.007) +0.15
(+0.006) +0.13
(+0.005) +0.10
(+0.004) +0.08
(+0.003) +0.05
(+0.002) +0.02
(+0.001) 0
(0)
+8 (+3) +0.18
(+0.007) +0.15
(+0.006) +0.13
(+0.005) +0.10
(+0.004) +0.08
(+0.003) +0.05
(+0.002) +0.02
(+0.001) 0
(0) -0.02
(-0.001)
+5 (+2) +0.15
(+0.006) +0.13
(+0.005) +0.10
(+0.004) +0.08
(+0.003) +0.05
(+0.002) +0.02
(+0.001) 0
(0) -0.02
(-0.001) -0.05
(-0.002)
+3 (+1) +0.13
(+0.005) +0.10
(+0.004) +0.08
(+0.003) +0.05
(+0.002) +0.02
(+0.001) 0
(0) -0.02
(-0.001) -0.05
(-0.002) -0.08
(-0.003)
0 (0) +0.10
(+0.004) +0.08
(+0.003) +0.05
(+0.002) +0.02
(+0.001) 0
(0) -0.02
(-0.001) -0.05
(-0.002) -0.08
(-0.003) -0.10
(-0.004)
-3 (-1) +0.08
(+0.003) +0.05
(+0.002) +0.02
(+0.001) 0
(0) -0.02
(-0.001) -0.05
(-0.002) -0.08
(-0.003) -0.10
(-0.004) -0.13
(-0.005)
-5 (-2) +0.05
(+0.002) +0.02
(+0.001) 0
(0) -0.02
(-0.001) -0.05
(-0.002) -0.08
(-0.003) -0.10
(-0.004) -0.13
(-0.005) -0.15
(-0.006)
-8 (-3) +0.02
(+0.001) 0
(0) -0.02
(-0.001) -0.05
(-0.002) -0.08
(-0.003) -0.10
(-0.004) -0.13
(-0.005) -0.15
(-0.006) -0.18
(-0.007)
-10 (-4) 0
(0) -0.02
(-0.001) -0.05
(-0.002) -0.08
(-0.003) -0.10
(-0.004) -0.13
(-0.005) -0.15
(-0.006) -0.18
(-0.007) -0.20
(-0.008)
Tool number A: ST30901000 ( — )
B: KV40105230 ( — )
SDIA2251E
Tool number A: ST35271000 ( — )B: KV40104810 ( — )
SDIA2252E
Revision: December 20092009 QX56

FRONT FINAL DRIVEDLN-229
< DISASSEMBLY AND ASSEMBLY > [FRONT FINAL DRIVE: M205]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
4. Install the selected drive pinion height adjusting washer to the drive pinion. Press the drive pinion rear bearing inner race to it
using Tool.
CAUTION:
Do not reuse drive pinion rear bearing inner race.
5. Install the collapsible spacer to the drive pinion. CAUTION:
Do not reuse collapsible spacer.
6. Apply differential gear oil to the drive pinion rear bearing, and install the drive pinion assembly to the gear carrier.
7. Apply differential gear oil to the drive pinion front bearing, and install the drive pinion front bearing inner race to the drive pinion
assembly.
CAUTION:
Do not reuse drive pinion front bearing inner race.
8. Apply multi-purpose grease to the lips of the new front oil seal.
Then drive the new front oil seal in evenly using Tools.
CAUTION:
 Do not reuse front oil seal.
 Do not incline the new fron t oil seal when installing.
 Apply multi-purpose grease to th e lips of the new front oil
seal.
9. Install the companion flange to the drive pinion while aligning the matching marks. Tap the companion flange until fully seated
using suitable tool.Tool number : — (C-4040)
SDIA2253E
PDIA0708E
Tool number A: KV38100500 (J-25273)
B: KV38102200 ( — )
PDIA0717E
SDIA2266E
Revision: December 20092009 QX56

FRONT FINAL DRIVEDLN-231
< DISASSEMBLY AND ASSEMBLY > [FRONT FINAL DRIVE: M205]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
4. Install the pinion mate shaft and align the lock pin hole on the pinion mate shaft with the lock pin hole on the differential case.
5. Measure the side gear end play. If necessary, select the appro- priate side gear thrust washers. Refer to DLN-234, "Inspection
and Adjustment".
6. Drive a new lock pin into the pinion mate shaft until it is flush with the differential case using suitable tool.
CAUTION:
Do not reuse lock pin.
7. Align the matching mark of the differential case with the mark of the drive gear, then place the drive gear onto the differential
case.
8. Install and tighten the new drive gear bolts to the specified torque. Refer to DLN-217, "Disassembly and Assembly"
.
CAUTION:
 Make sure the drive gear back and threaded holes are
clean.
 Do not reuse drive gear bolts.
 Tighten new drive gear bolts in a crisscross pattern.
9. Press the new side bearing inner races to the differential case using Tools.
CAUTION:
Do not reuse side bearing inner races.
SDIA0195J
SPD030
SDIA2593E
SDIA2239E
Tool number A: KV38100300 (J-25523)
B: ST33081000 ( — )
SPD353
Revision: December 20092009 QX56

DLN-238
