2009 INFINITI QX56 display

C1801 VEHICLE HEIGHT SENSORSCS-9
< COMPONENT DIAGNOSIS >
C
DF
G H
I
J
K L
M A
B
SCS
N
O P
COMPONENT DIAGNOSIS
C1801 VEHICLE HEIGHT SENSOR
DescriptionINFOID:0000000003772312
The vehicle height sensor operates on a 5 volt referenc e signal from the suspension control unit. The suspen-
sion control unit also provides ground to the height sensor. Depending on vehicle height, the height sensor
signal should have between 0.2V and 4.8V.
DTC LogicINFOID:0000000003772313
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000003772314
1.CHECK HEIGHT SENSOR OPERATION
CONSULT-III
1. Turn ignition switch ON
2. Select "HEIGT SEN" of AIR L EVELIZER data monitor test item.
Is the HEIGHT SEN voltage within the given range?
YES >> Height sensor is operating normally.
NO >> Refer to SCS-22, "
Diagnosis Procedure".
DTCDisplay contents of CON-
SULT-III Diagnostic item is detected when ...
Probable malfunction location
C1801 VEHICLE HEIGHT SEN-
SOR Vehicle height sensor voltage is less than 0.2V
or greater than 4.8V for more than 60 seconds. • Height sensor power/ground supply. Refer to
SCS-18, "
HEIGHT SENSOR : Diagnosis
Procedure".
• Height sensor signal circuit. Refer to SCS-
22, "Component Function Check".
HEIGHT SEN : 0.2V - 4.8V
Revision: December 20092009 QX56

SCS-10
< COMPONENT DIAGNOSIS >
C1802 COMPRESSOR RELAY
C1802 COMPRESSOR RELAY
DescriptionINFOID:0000000003772315
The compressor motor relay is controlled by the suspension control unit. The suspension control unit supplies
voltage to the coil side of the relay to activate it. T he compressor motor relay, when activated, supplies power
to the suspension air compressor.
DTC LogicINFOID:0000000003772316
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000003772317
1.CHECK COMPRESSOR MOTOR RELAY OPERATION
CAUTION:
The "COMPRESSOR" active test will remain ON until it is turned off using CONSULT-III. Allowing the
compressor to run for an extended period of time may cause damage to the air levelizer system com-
ponents due to excessive air pressure.
CONSULT-III
1. Turn ignition ON.
2. Select "COMPRESSOR" of AIR LEVELIZER active test items.
3. While operating test item, check that the suspension air compressor turns ON.
Does the suspension air compressor operate properly?
YES >> Compressor motor relay and suspension air compressor are operating normally.
NO >> Refer to SCS-20, "
Diagnosis Procedure".
DTCDisplay contents of CON-
SULT-III Diagnostic item is detected when ...
Probable malfunction location
C1802 COMPRESSOR RELAY • Driving transistor for the compressor
relay is
OFF and monitor voltage continues at a high
level for more than 10 seconds.
• Driving transistor for the compressor relay is
ON and monitor voltage continues at a low
level for more than 5 seconds. Compressor motor relay. Refer to
SCS-20,
"Component Function Check".
ON : Compressor turns ON
OFF : Compressor turns OFF
Revision: December 20092009 QX56

C1803 EXHAUST SOLENOIDSCS-11
< COMPONENT DIAGNOSIS >
C
DF
G H
I
J
K L
M A
B
SCS
N
O P
C1803 EXHAUST SOLENOID
DescriptionINFOID:0000000003772318
The exhaust valve solenoid controls the vent function of the suspensi on control system. The exhaust valve
solenoid is built into the suspension air compressor. The suspension control unit supplies voltage to the
exhaust valve solenoid to activate it.
DTC LogicINFOID:0000000003772319
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000003772320
1.CHECK EXHAUST SOLENOID OPERATION
CAUTION:
While operating this active test, the suspension control system wil l vent air pressure and the vehicle
ride height will lower. Ensure th e area around the vehicle is free from obstructions before beginning
test.
CONSULT-III
1. Ensure the suspension control system has air pressure and is not drooping in the rear.
2. Select "EXHAUST SOLENOID" of AIR LEVELIZER active test items.
3. While operating test item, check that the exhaust va lve solenoid opens to vent air from the system. The
vehicle should lower when the exhaust valve solenoid is activated.
Does the system vent properly?
YES >> Exhaust valve solenoid is operating normally.
NO >> Refer to SCS-23, "
Description".
DTCDisplay contents of CON-
SULT-III Diagnostic item is detected when ...
Probable malfunction location
C1803 EXHAUST SOLENOID • Driving transistor for the exhaust valve sole-
noid is OFF and monitor voltage continues at
a high level for more than 10 seconds.
• Driving transistor for the exhaust valve sole-
noid is ON and monitor voltage continues at
a low level for more than 5 seconds. Open or short circuit in the exhaust valve sole-
noid control circuit. Refer to
SCS-23, "
Compo-
nent Function Check".
ON : Air vents and vehicle ride height lowers
OFF : No air vents and vehicle ride height remains constant
Revision: December 20092009 QX56

SCS-12
< COMPONENT DIAGNOSIS >
C1804 HEIGHT ADJUSTING MALFUNCTION (COMPRESSOR)
C1804 HEIGHT ADJUSTING MA LFUNCTION (COMPRESSOR)
DescriptionINFOID:0000000003772321
The compressor motor relay is controlled by the sus pension control unit. The suspension control unit supplies
voltage to the coil side of the relay to activate it. T he compressor motor relay, when activated, supplies power
to the suspension air compressor.
DTC LogicINFOID:0000000003772322
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000003772323
1.CHECK COMPRESSOR MOTOR RELAY OPERATION
CAUTION:
The "COMPRESSOR" active test will remain ON until it is turned off using CONSULT-III. Allowing the
compressor to run for an extended period of time may cause damage to the air levelizer system com-
ponents due to excessive air pressure.
CONSULT-III
1. Turn ignition ON.
2. Select "COMPRESSOR" of AIR LEVELIZER active test items.
3. While operating test item, check that the suspension air compressor turns ON.
Does the suspension air compressor operate properly?
YES >> Compressor motor relay and suspension air compressor are operating normally.
NO >> Refer to SCS-20, "
Diagnosis Procedure".
DTCDisplay contents of CON-
SULT-III Diagnostic item is detected when ...
Probable malfunction location
C1804 VEHICLE HEIGHT AD-
JUSTING MALFUNC-
TION (COMPRESSOR) Continuous compressor relay ON time is more
than 120 seconds.
Compressor motor relay. Refer to
SCS-20,
"Component Function Check".
ON : Compressor turns ON
OFF : Compressor turns OFF
Revision: December 20092009 QX56

C1805 HEIGHT ADJUSTING MALFUNCTION (EXH SOLENOID)
SCS-13
< COMPONENT DIAGNOSIS >
C
D F
G H
I
J
K L
M A
B
SCS
N
O P
C1805 HEIGHT ADJUSTING MALF UNCTION (EXH SOLENOID)
DescriptionINFOID:0000000003772324
The exhaust valve solenoid controls the vent function of the suspensi on control system. The exhaust valve
solenoid is built into the suspension air compressor. The suspension control unit supplies voltage to the
exhaust valve solenoid to activate it.
DTC LogicINFOID:0000000003772325
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000003772326
1.CHECK EXHAUST SOLENOID OPERATION
CAUTION:
While operating this active test, the suspension control system wil l vent air pressure and the vehicle
ride height will lower. Ensure th e area around the vehicle is free from obstructions before beginning
test.
CONSULT-III
1. Ensure the suspension control system has air pressure and is not drooping in the rear.
2. Select "EXHAUST SOLENOID" of AIR LEVELIZER active test items.
3. While operating test item, check that the exhaust va lve solenoid opens to vent air from the system. The
vehicle should lower when the exhaust valve solenoid is activated.
Does the system vent properly?
YES >> Exhaust valve solenoid is operating normally.
NO >> Refer to SCS-23, "
Description".
DTCDisplay contents of CON-
SULT-III Diagnostic item is detected when ...
Probable malfunction location
C1805 VEHICLE HEIGHT AD-
JUSTING MALFUNC-
TION (EXHAUST
SOLENOID) Continuous exhaust valve solenoid ON time is
more than 120 seconds.
Short to power in the exhaust valve solenoid
control circuit. Refer to
SCS-23, "
Component
Function Check".
ON : Air vents and vehicle ride height lowers
OFF : No air vents and vehicle ride height remains constant
Revision: December 20092009 QX56

SCS-14
< COMPONENT DIAGNOSIS >
C1806 VEHICLE HEIGHT SENSOR LOCKING MALFUNCTION
C1806 VEHICLE HEIGHT SENSOR LOCKING MALFUNCTION
DescriptionINFOID:0000000003772327
The vehicle height sensor operates on a 5 volt referenc e signal from the suspension control unit. The suspen-
sion control unit also provides ground to the height sensor.
DTC LogicINFOID:0000000003772328
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000003772329
1.CHECK HEIGHT SENSOR OPERATION
CONSULT-III
1. Turn ignition switch ON
2. Select "HEIGT SEN" of AIR LEVELIZER data monitor test item.
Is the HEIGHT SEN voltage within the given range?
YES >> Height sensor is operating normally.
NO >> Refer to SCS-22, "
Diagnosis Procedure".
DTCDisplay contents of CON-
SULT-III Diagnostic item is detected when ...
Probable malfunction location
C1806 VEHICLE HEIGHT SEN-
SOR LOCKING MAL-
FUNCTION Output sensor voltage variation
±0.02V is more
than 100 seconds when vehicle height range is
normal. • Height sensor power/ground supply. Refer to
SCS-18, "
HEIGHT SENSOR : Diagnosis
Procedure".
• Charging system malfunction. Refer to CHG-
8, "Inspection Procedure".
HEIGHT SEN : 0.2V - 4.8V with no more than ± 0.02V
variation
Revision: December 20092009 QX56

C1807 SENSOR 5V MALFUNCTIONSCS-15
< COMPONENT DIAGNOSIS >
C
DF
G H
I
J
K L
M A
B
SCS
N
O P
C1807 SENSOR 5V MALFUNCTION
DescriptionINFOID:0000000003772330
The vehicle height sensor operates on a 5 volt referenc e signal from the suspension control unit. The suspen-
sion control unit also provides ground to the height sensor.
DTC LogicINFOID:0000000003772331
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000003772332
1.POWER SUPPLY CIRCUIT CHECK
1. Disconnect height sensor connector C8.
2. Turn the ignition switch ON.
3. Check voltage between the height sensor connector C8 terminal 1 and ground.
Is 5V present?
YES >> System is working normally.
NO >> Check harness or connector for open or short. If OK, replace the suspension control unit. Refer to RSU-26, "
Removal and Installation".
DTCDisplay contents of CON-
SULT-III Diagnostic item is detected when ...
Probable malfunction location
C1807 SENSOR 5V MALFUNC-
TION Sensor reference voltage is less than 0.8V or
more than 6V for 20 seconds. • Height sensor power/ground supply. Refer to
SCS-18, "
HEIGHT SENSOR : Diagnosis
Procedure".
• Charging system malfunction. Refer to CHG-
8, "Inspection Procedure".
(+)
(-) Voltage
Connector Terminal
C8 1 Ground 5V
ALEIA0026GB
Revision: December 20092009 QX56

SCS-16
< COMPONENT DIAGNOSIS >
C1808 INTEGRAL TIME MALFUNCTION SUPPLYING AIR
C1808 INTEGRAL TIME MALFUNCTION SUPPLYING AIR
DescriptionINFOID:0000000003772333
The suspension air compressor is supplied power by the compressor motor relay. The suspension control unit
supplies power to the compressor motor relay in order to activate the relay and subsequently activate the sus-
pension air compressor.
DTC LogicINFOID:0000000003772334
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000003772335
1.CHECK COMPRESSOR MOTOR RELAY OPERATION
CAUTION:
The "COMPRESSOR" active test will remain ON until it is turned off using CONSULT-III. Allowing the
compressor to run for an extended period of time may cause damage to the air levelizer system com-
ponents due to excessive air pressure.
CONSULT-III
1. Turn ignition ON.
2. Select "COMPRESSOR" of AIR LEVELIZER active test items.
3. While operating test item, check that the suspension air compressor turns ON.
Does the suspension air compressor operate properly?
YES >> Compressor motor relay and suspension air compressor are operating normally.
NO >> Refer to SCS-20, "
Diagnosis Procedure".
DTCDisplay contents of CON-
SULT-III Diagnostic item is detected when ...
Probable malfunction location
C1808 INTEGRAL TIME MAL-
FUNCTION SUPPLYING
AIR A suspension air compressor ON request has
been in effect for 180 seconds and the suspen-
sion air compressor has not activated during
that time. • Compressor motor relay. Refer to
SCS-20,
"Diagnosis Procedure".
• Suspension air compressor. Refer to SCS-
17, "SUSPENSION AIR COMPRESSOR :
Diagnosis Procedure".
ON : Compressor turns ON
OFF : Compressor turns OFF
Revision: December 20092009 QX56
