2009 Hyundai Accent Owner's Manual

1
FEATURES OF YOUR HYUNDAI
1031
FEATURES OF YOUR HYUNDAI
103
E090200AMCTo increase cruise control set speed:Follow either of these procedures:
o Push the RES/+ switch and hold it.
Your vehicle will accelerate. Release
the switch at the speed you want.
o Push the RES/+ switch and release it
immediately. The cruising speed will
increase by 1 mph (1.6 km/h) each
time the RES/+ switch is operated in
this manner.
OMC039302
E090300AMCTo decrease the cruising speed:Follow either of these procedures:
o Push the -/SET switch and hold it. Your
vehicle will gradually slow down. Re-
lease the switch at the speed you want
to maintain.
o Push the -/SET switch and release it
immediately. The cruising speed will
decrease by 1 mph (1.6 km/h) each
time the -/SET switch is operated in
this manner.
OMC039301
NOTE:On steeper hills, with a Manual Transaxle,
the cruise control may be unable to main-
tain the set speed. The driver should
downshift as necessary. Press the
"RES/+" button to resume the cruise
control at the set speed in the new gear.
After cresting the hill, upshift, and press
the "RES/+" again. If the speed drops ~
9 mph below the set speed, the cruise
control will cancel. If it cancels, shift to
the appropriate gear, and press the
"RES/+" to resume the cruse control.

1FEATURES OF YOUR HYUNDAI
104
E090500AMCTo cancel cruise control, do one of
the following:o Press the brake pedal.
o Press the clutch pedal with a manual
transaxle.
o Shift into N (Neutral) with an automatic
transaxle.
o Press the CANCEL switch located on
the steering wheel.
o Decrease the vehicle speed lower than
the memory speed by 9 mph (15 km/h).
o Decrease the vehicle speed to less
than approximately 25 mph (40 km/h).
OMC039303
Each of these actions will cancel cruise
control operation (the SET indicator light
in the instrument cluster will go off), but it
will not turn the system off. If you wish to
resume cruise control operation, push
the RES/+ switch located on your steer-
ing wheel. You will return to your previ-
ously preset speed.
E090400AUNTo temporarily accelerate with the
cruise control on:If you want to speed up temporarily when
the cruise control is on, depress the ac-
celerator pedal. Increased speed will not
interfere with cruise control operation or
change the set speed.
To return to the set speed, take your foot
off the accelerator.

1
FEATURES OF YOUR HYUNDAI
1051
FEATURES OF YOUR HYUNDAI
105
AUX OUTLET(If Installed)You can use an aux outlet to connect an
audio device.NOTE:When using a portable audio device con-
nected to the power outlet, noise may
occur during playback. If this happens,
use the power source of the portable
audio device.
OMC029033A-1
E090600AMCTo resume cruising speed at more
than approximately 25 mph (40 km/h):If any method other than the CRUISE ON-
OFF switch was used to cancel cruising
speed and the system is still activated,
the most recent set speed will automati-
cally resume when the RES/+ switch is
pushed.
It will not resume, however, if the vehicle
speed has dropped below approximately
25 mph (40 km/h).
OMC039302E090700AUN
To turn cruise control off, do one of
the following:o Push the CRUISE ON-OFF button (the
CRUISE indicator light in the instru-
ment cluster will go off).
o Turn the ignition off.
Both of these actions cancel cruise con-
trol operation. If you want to resume cruise
control operation, repeat the steps pro-
vided in “To set cruise control speed” on
the previous page.

1FEATURES OF YOUR HYUNDAI
106
HEATING AND COOLING CONTROLB710A01TB-GAT(If Installed)1. Side Defroster Nozzle
2. Side Ventilator
3. Windshield Defroster Nozzle
4. Center Ventilator
B710B01MC-AATCenter Ventilator/Side Ventilator
B710A01MC
B710B01MC
The center ventilators are located in the
middle of the dashboard. The side venti-
lators are located on each side of dash-
board. To change the direction of the air
flow, move the knob in the center of the
vent up-and-down and side-to-side.
The vents are opened when the vent
knob is moved to "
" position. The
vents are closed when the vent knob is
moved to "
". Keep these vents clear of
any obstructions.

1
FEATURES OF YOUR HYUNDAI
1071
FEATURES OF YOUR HYUNDAI
107
HEATING AND VENTILA-
TIONB670A02A-GAT(If Installed)1. Temperature control
2. Air conditioning switch (If Installed)
3. Air intake control switch
4. Air flow control
5. Fan speed control
B670B01A-AATFan Speed Control
(Blower Control)This is used to turn the blower fan on or
off and to select the fan speed.
This blower fan speed, and therefore the
volume of air delivered from the system,
may be controlled manually by setting the
blower control between the "1" and "4"
positions.
B670A01MC-D
OMC025083B670C03A-AAT
Air Intake Control
B670C02MC
This is used to select fresh outside air or
recirculating inside air.
Fresh
Recirculation
With the "
" mode selected, air enters
the vehicle from outside and is heated or
cooled according to the other functions
selected.
With the "" mode selected, air from
within the passenger compartment is
drawn through the heating system and
heated or cooled according to the other
functions selected.

1FEATURES OF YOUR HYUNDAI
108
NOTE:It should be noted that prolonged opera-
tion of the intake air system in "
"
mode will give rise to misting of the
windshield and side windows and the air
within the passenger compartment will
become stale. In addition prolonged use
of the air conditioning with the ""
mode selected may result in the air within
the passenger compartment becoming
excessively dry.
B670D03MC-AATAir Flow ControlThis is used to direct the flow of air. Air
can be directed to the floor, instrument
panel outlets, or windshield. Five sym-
bols are used to represent Face, Bi-
Level, Floor, Floor-Defrost and Defrost air
position.
B670D01MC-D
Face-Level
Selecting the "Face" mode will cause air
to be discharged through the face level
vents.
B670D02MC

1
FEATURES OF YOUR HYUNDAI
1091
FEATURES OF YOUR HYUNDAI
109
Bi-Level
Air is discharged through the face vents
and the floor vents.
Floor-Level
Air is discharged through the floor vents,
windshield defroster nozzle, side defroster
nozzle and side ventilator.
Floor-Defrost Level
Air is discharged through the windshield
defroster nozzle, the floor vents, side
defroster nozzle and side ventilator.
In vehicles equipped with A/C, the A/C
will automatically be turned on in the
"Floor Defrost" mode.
B670D03MC
B670D04MCB670D05MC

1FEATURES OF YOUR HYUNDAI
110
Defrost-Level
Air is discharged through the windshield
defroster nozzle, side defroster nozzle,
side ventilator.
In vehicles equipped with A/C, the A/C
will automatically be turned on in the
"Defrost" mode.
B670D06MC
NOTE:In vehicles equipped with A/C, when
"Floor-Defrost" or "Defrost" modes are
selected, the A/C is automatically turned
on to help dry the air. Pushing the A/C
button will not turn off the A/C.
B670E02A-AATTemperature ControlThis control is used to adjust the degree
of heating or cooling desired.
Cool
Warm
B670E01MC
