2009 FIAT SEDICI technical specifications

BEFORE DRIVING
STEERING COLUMN CONTROLS
INSTRUMENT PANEL
OTHER CONTROLS AND EQUIPMENT
OPERATING YOUR VEHICLE
DRIVING TIPS
VEHICLE LOADING AND TOWING
INSPECTION AND MAINTENANCE
EMERGENCY SERVICE
BODY WORK CARE
GENERAL INFORMATION
TECHNICAL SPECIFICATIONS
SUPPLEMENT
INDEXT T
A A
B B
L L
E E
O O
F F
C C
O O
N N
T T
E E
N N
T T
S S1
2
3
4
5
6
7
8
9
10
11
12
13
14
001-008 SEDICI LUM FL GB 1E 19-06-2009 13:27 Pagina 7

195
Refill with Oil and Check for Leaks
❒Pour oil through the filler hole and in-
stall the filler cap.
For the approximate capacity of the oil,
refer to the “Capacities” item in the
“SPECIFICATIONS” section.
❒Start the engine and look carefully for
leaks at the oil filter and drain plug. Run
the engine at various speeds for at least
5 minutes.
❒Stop the engine and wait about 5 min-
utes. Check the oil level again and add
oil if necessary. Check for leaks again.
IMPORTANT
❒When replacing the oil filter, it is rec-
ommended that you use a genuine
Fiat replacement filter. If you use an af-
termarket filter, make sure it is of
equivalent quality and follow the man-
ufacturer’s instructions.
❒Oil leaks from around the oil filter or
drain plug indicate incorrect installation
or gasket damage. If you find any leaks
or are not sure that the filter has been
properly tightened, have the vehicle in-
spected by your Fiat Dealership.
GEAR OIL
MANUAL TRANSAXLE OIL/
TRANSFER OIL (4WD)/
REAR DIFFERENTIAL OIL (4WD)
When adding gear oil, use gear oil with the
appropriate viscosity and grade as shown
in the chart below.
TUTELA XVI SAE 75W-90, API GL-4,
FIAT 9.55550-MZ4 Contractual Technical
Reference N° F808.G08, for gasoline en-
gine, manual transaxle gear oil.
TUTELA XVI SAE 75W-90, API GL-3, FIAT
9.55550-MZ4 Contractual Technical Refer-
ence N° F808.G08 for diesel engine, manual
transaxle gear oil.
Hypoid gear oil TUTELA W90/M -
DA SAE
80W-90 API GL-5for transfer oil and rear
differential oil (4WD).
Gasoline engine, manual transaxle
oil (API GL-4)
54G095
54G096
79JM023
Transfer oil (4WD)
Rear differential oil (4WD)
(API GL-5 Hypoid)
Gear Oil Level Check
To check the gear oil level, use the fol-
lowing procedure:
❒Park the vehicle on a level surface with
the parking brake applied. Then, stop
the engine.
❒Remove the oil filler plug (1) or (2).
❒Feel the inside of the hole with your fin-
ger. If the oil level comes up to the bot-
tom of the plug hole, the oil level is cor-
rect. If so, reinstall the plug. Diesel engine, manual transaxle oil
(API GL-3)
183-230 SEDICI LUM FL GB 1E 19-06-2009 11:00 Pagina 195

250
TECHNICAL SPECIFICATIONS
NOTE Technical specifications are subject to change M/T: Manual transaxle 2WD: 2-wheel drive
without notice A/T: Automatic transaxle 4WD: 4-wheel drive
ENGINE 1.6 16V2.0 Multijet
Code - type
Number and layout of cylinders
Piston bore and stroke
Total displacement
Compression ratio
Maximum power (EEC) kW
HP
corresponding ratio rpm
Maximum torque (EEC) Nm
kgm
corresponding ratio rpm
Fuel
FUEL FEED - IGNITION 1.6 16V2.0 Multijet
Fuel feed
Ignition
Modifications or repairs to the fuel feed system that are not carried out properly or do not take the system’s
technical specifications into account can cause malfunctions leading to the risk of fire.
WARNING
M16A (DOHC) - Euro 5
4 in line
78.0 x 83.0 mm (3.07 x 3.27 in.)
1,598 cm
3(97.5 cu. in)
10.5 : 1
88
120
6,000
156
15.9
4,400
Unleaded petrol 95 RON
(Specification EN228)D20AA - Euro 5
4 in line
83.0 x 90.4 mm (3.27 x 3.56 in.)
1,956 cm3(119.3 cu. in)
16.5 : 1
99.2
135
3,500
320
32.6
1,500
Diesel fuel for motor vehicles
(Specification EN590)
MPI electronic injection
Electronic Single SparkDirect injection with electronically
controlled Multijet Common Rail
Compression
249-254 SEDICI LUM FL GB 1E 19-06-2009 11:10 Pagina 250

261
– Fluid level check............................. 196
– Gearshift lever............................... 132
– If you cannot shift lever out
of “P” (Park)................................... 238
– Selector position indicator .......... 89
– Specific fluid.................................... 196
– Using the transaxle........................ 156
Battery ................................................. 213
– Replacement ................................... 214
Before driving....................................... 9
Bodywork care..................................... 239
Brakes
– ABS................................................... 162
– Brake fluid....................................... 205
– Brake pedal ..................................... 206
– Brakes.............................................. 205
– Braking ............................................. 161
– Parking brake lever.................130-207
– Technical specifications ................ 252
– Vacuum brake ................................ 161
Bulbs
– Replacement ................................... 221
– Type.................................................. 251
Capacities ............................................ 254
Catalytic converter.............................. 167Children
– Child-proof locks........................... 22
– Child restraint systems ................ 37
– Installation with Isofix type
anchorages...................................41-42
– Installation with lap-shoulder
seat belts......................................... 42
Cigar lighter .......................................... 95
Clock ...................................................... 90
Clutch..............................................131-208
– Pedal................................................. 208
Corrosion prevention......................... 240
CO
2emissions...................................... 27
Cruise Control ..................................... 69
Cup holder ............................................ 142
Daily inspection checklist ................ 150
Declaration of conformity ................. 256
Dimensions........................................... 253
Dipped beam headlights
– Bulb replacement........................... 222
– Control ............................................ 63
Doors
– Central door locking system....... 13
– Child-proof locks........................... 22
– Dead lock ........................................ 14
– Door locks ...................................... 12
ABS ...................................................... 162
Air bags ................................................. 47
– Front................................................ 48
– General warnings........................... 55
– How the system works ................ 52
– Servicing........................................... 54
– Side................................................... 50
Air cleaner............................................. 201
Air conditioning.............................100-104
Ashtray................................................... 95
Assist grips............................................ 140
Audio systems...................................... 110
– Antenna ........................................... 113
– Anti-theft system (SEC) ............... 122
– Cautions on handling .................... 111
– CD Changer................................... 118
– CD player........................................ 117
– Error display messages................. 125
– FM/MW/LW CD Player with
CD Changer control .................... 110
– General ............................................ 113
– Listening to a CD .......................... 112
– MP3/WMA Player.......................... 120
– Radio................................................ 114
– RDS (Radio Data System)............ 115
– Remote audio controls ................ 126
– Troubleshooting ............................ 124
Automatic Transaxle (AT) Fluid ....... 196
– Changing oil .................................... 197
I I
N N
D D
E E
X X
14
261-268 SEDICI LUM FL GB 1E 19-06-2009 11:12 Pagina 261

262
– Level check ..................................... 192
– Oil life monitoring......................... 89
– Specifications.................................. 191
Engine oil filter (change)..................... 194
Engine oil life monitoring ................... 89
ESP (Electronic Stability
Program)......................................92-164
Exhaust gas............................................ 150
External lights................................63-222
Fiat CODE (Immobilizer system) .... 11
Frame hooks........................................... 143
Front fog lights ........................................ 91
Fuel
– Average fuel consumption
(gauge)................................................ 87
– Capacities/refuelling...................10-254
– Consumption.................................... 247
– Driving range .................................... 88
– Fuel filter ............................................ 204
– Fuel filler cap ..................................... 132
– Fuel gauge .......................................... 84
– Fuel recommendation.................... 10
– Improving fuel economy ................ 168
– Instantaneous fuel consumption
(gauge).................................................... 85
Fuses.......................................................... 215
Gear oil
– Changing .......................................... 196– Level check ..................................... 195
– Specifications.................................. 195
Gearshift lever...................................... 132
General information............................ 245
Glove box.............................................. 94
Hazard warning lights ....................... 91
Head restraints..................................... 30
Headlight levelling switch ................... 94
Headlights
– Bulb replacement........................... 222
– Headlight levelling switch............. 94
Heated rear window........................... 93
Heating and air conditioning system .. 96
– Air outlet......................................... 96
– Automatic heating and air
conditioning system
(Climate Control).......................... 104
– Heating system............................... 97
– Maintenance.............................110-230
– Manual heating and air
conditioning system...................... 100
Horn ....................................................... 68
Identification data .............................. 246
Ignition switch ...................................... 58
Information display.............................. 85
Inspection and maintenance .............. 183
– Maintenance schedule................... 185
– Severe driving conditions............. 190 – Keyless Start system..................... 15
– Opening/closing............................. 12
Drive belt (servicing).......................... 191
Driving tips............................................ 169
– Driving on hills ............................... 170
– Driving on slippery roads ............ 171
– Highway driving.............................. 170
Emergency service ............................ 231
Engine
– Air cleaner ...................................... 201
– Engine coolant ................................ 198
– Engine oil and filter........................ 191
– If the engine is flooded................. 236
– If the engine overheats ................. 236
– If the starter does not operate... 236
– Jump starting................................... 233
– Oil consumption ............................ 151
– Serial number................................. 246
– Spark plugs...................................... 202
– Starting............................................. 152
– Technical specifications ................ 249
– Temperature gauge ....................... 85
Engine coolant ...................................... 198
Engine coolant temperature gauge .. 85
Engine hood .......................................... 140
Engine oil
– Changing oil and filter................... 193
– Consumption.................................. 151
261-268 SEDICI LUM FL GB 1E 19-06-2009 11:12 Pagina 262

264
– Inspection ........................................ 208
– Rotation........................................... 210
– Technical data................................ 253
Vehicle cleaning.................................. 242
Vehicle identification........................... 246
Vehicle loading and towing ......... 173-174
Ventilation.................................98-101-107
Warning and indicator lights ........... 74
Weights.................................................. 254
Wheels
– Changing .......................................... 212
– Technical data................................ 253
Windows
– Electric window controls............. 24
– Manual window controls ............. 24
Windshield defroster..............98-101-107
Windshield washer
– Control ............................................ 65
– Fluid.................................................. 201
Windshield wiper
– Blades............................................... 227
– Control ............................................ 65
2WD/4WD switch.......................92-159 Suspensions ........................................... 252
Symbols (battery)................................. 4
Tachometer ........................................ 83
Tailgate................................................... 23
Technical specifications...................... 249
Theft deterrent light ........................... 95
Thermometer....................................... 88
Tilt steering lock lever........................ 67
Tools...................................................... 144
Towing the vehicle
– Frame hooks................................... 143
– Instructions..............................174-179
Trailer towing....................................... 174
Transaxle (automatic) ......................... 156
– Changing oil .................................... 197
– Fluid level check............................. 196
– Specific fluid.................................... 196
Transaxle (manual).............................. 157
– Gear oil change .............................. 196
– Gearshift lever............................... 132
– Specification.................................... 195
– Using the transaxle........................ 157
Transmission......................................... 252
Trip meter............................................. 87
Turn signal............................................. 64
– Bulb replacement........................... 223
Tires
– Compact spare tire ....................... 211
261-268 SEDICI LUM FL GB 1E 19-06-2009 11:12 Pagina 264
