2008 TOYOTA SEQUOIA Navigation Manual

OTHER FUNCTIONS
170
This system has a function which dis-
plays the voice recognition help
screen. You can see the command list
and operating guide on it.
(a) Command List
1. If the “Operating Guide” screen is
displayed, touch “Command List” on
the upper side of the screen.
5U5194F
2. Select the desired category by
touching the buttons on the right side of
the “Command List” screen.
3. You can scroll through the list of the
command list by touching “
” or
“
”.
Touch “OK” after you check it.(b) Operating Guide
1. If the “Command List” screen is dis-
played, touch “Operating Guide” on the
upper side of the screen.
5U5195F
2. Select the desired category by
touching the buttons on the right side of
the “Operating Guide” screen.
3. You can scroll through the list of the
operating guide by touching “
” or
“
”.
Touch “OK” after you check it.
Help screen

OTHER FUNCTIONS
171
The brightness or contrast of the
screen can be adjusted depending on
the brightness of your surroundings.
You can also turn the display off.
XS00308
1. To display the “Display” screen,
push the “DISP” button.
5U5196F
Contrast and brightness adjustment
2. Touch the desired button to adjust
contrast and brightness.
“Contrast” “+”:
Strengthens the contrast of the screen.
“Contrast” “”:
Weakens the contrast of the screen.
“Brightness” “+”:
Brightens the screen.
“Brightness” “”:
Darkens the screen.
3. After adjusting the screen, touch
“OK”.If your vehicle is equipped with the rear
seat entertainment system, the rear
screen turns on or off when “Rear” is
touched.
The screen goes off when “Screen Off” is
touched. To turn the display screen back
on, push any button such as “INFO”, etc.
The selected screen appears.
INFORMATION
When you do not touch any touch
screen button on the screen for 20
seconds the “Display” screen goes
off.
Screen adjustment

OTHER FUNCTIONS
172
5U5197F
Color and tone adjustment (with rear
seat entertainment system)
1. Touch the desired button to adjust
color and tone.
You can adjust the color and the tone while
the DVD video and video CD are being
played.
“Color” “R”:
Strengthens the red color of the screen.
“Color” “G”:
Strengthens the green color of the screen.
“Tone” “+”: Strengthens the tone of the
screen.
“Tone” “”: Weakens the tone of the
screen.
2. After adjusting the screen, touch
“OK”.
The rear screen turns on or off when
“Rear” is touched.
The screen turns off when “Screen Off” is
touched. To turn the screen back on, push
any button such as “INFO”, etc. The se-
lected screen appears.
INFORMATION
When you do not touch any touch
screen button on the screen for 20
seconds the “Display” screen goes
off.
5U5198F
Depending on the position of the head-
light switch, the screen changes to ei-
ther day mode or night mode.
To display the screen in the day mode even
with the headlight switch on, touch “Day
Mode” on the adjustment screen for
brightness and contrast control.
If the screen is set in the day mode with the
headlight switch turned on, this condition is
memorized in the system even with the en-
gine turned off.

OTHER FUNCTIONS
173
XS00303
1. Push the “INFO” button to display
the “Information” screen.
5U5199aF
2. Touch “Screen Setting”.You can select a function that enables
automatic return to the navigation
screen from the audio screen.
5U5200F
Select “ON” or “OFF” and then touch
“OK”.
“ON”:The navigation screen automati-
cally returns from the audio
screen 20 seconds after the end
of audio operation.
“OFF”:The audio screen remains on.
Screen setting(a) Automatic transition

OTHER FUNCTIONS
174
You can select a color of the touch
screen buttons.
5U5201F
Select “Green” or “Orange” and then
touch “OK”.If the vehicle is equipped with the rear
seat entertainment system, the rear
seat entertainment system can be
locked to prevent rear passengers from
operating the entertainment system.
5U5202F
Select “ON” or “OFF” and then touch
“OK”.
“ON”: The rear passengers cannot oper-
ate the rear seat entertainment system.
Only front passengers can operate the
system.
“OFF”: Both the front and rear passen-
gers can operate the rear seat entertain-
ment system.
(b) Switch color
(c) Rear system lock
(with rear seat
entertainment system)

OTHER FUNCTIONS
175
The following personal data can be de-
leted or returned to their default set-
tings:
Information
Maintenance conditions
Maintenance information “off” set-
ting
Navigation system
Memory points
Areas to avoid
Previous points
Route trace
User selection settings
Handsfree system
Phone book data
Dialed numbers and received calls
Speed dial
Bluetooth phone data
Security code
This function is available only when the
vehicle is not moving.
5U5203F
1. Touch “Delete personal data”.
The “Delete personal data” screen ap-
pears.
5U5204F
2. Touch “Delete”.
The “Confirmation to delete all personal
data” screen appears.
5U5205F
3. Touch “Yes”.
Delete personal data

OTHER FUNCTIONS
176
You can set a beep sound off.
XS00303
1. Push the “INFO” button.
5U5206aF
2. Touch “Beep Off”.
“Beep Off” is highlighted.
To set the beep sound on, touch “Beep
Off” again.The language of the touchscreen but-
tons, popup messages and the voice
guidance can be changed.
XS00303
1. Push the “INFO” button.
5U5207aF
2. Touch “Language”.
Beep settingSelect a language

OTHER FUNCTIONS
177
5U5B01F
3. Touch “English”, “Français” or
“Español” to select a language.
If a screen other than for the navigation
system is displayed, the current screen
would change to the “CAUTION” screen
by pushing the “MAP/VOICE”, “DEST” or
“MENU” button.
4. Touch “OK”.
The language is changed and the screen
returns to the map display.
