ForewordThis Instruction manual and its corresponding supplements should be read carefully to familiarise yourself with
your vehicle.
Be si d e s t h e r eg u la r ca r e a n d ma i n te na n ce o f t h e ve h i cle , i t s co r r e c t ha n d l i n g wi ll co n t r i b u te to p r e se r v e i t s va lu e .
For safety reasons, note the information concerning accessories, modifications and parts change.
If selling the vehicle, give all of the onboard documentat ion to the new owner as this should be kept with the
